IQ Power Tools iQTS244 Instructions for use
iQ Power Tools
Routine Maintenance
iQTS244
888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
1
Table of Contents
IQTS244 PERIODIC MAINTENANCE 3
Cleaning Sliding Table Rollers and Frame Tracks 3
Check and Adjustment of Sliding Table Upper and Lower Rollers 5
Check and Adjust Sliding Table Travel 13
Check and Adjustment of Pivot Arm Squareness 19
Check and Adjustment of Table Louver and Vacuum Suction Clearance 25
Check for Vacuum Suction and Seal 29
Check and Adjustment of the Laser 31
888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
3
IQTS244 PERIODIC MAINTENANCE
Cleaning Sliding Table Rollers and Frame Tracks
1. Remove the sliding table from the track
and lay it on the stand with the rollers
facing up
2. Clean the rolling table wheels with
Scotch Brite
3. Clean the table track with Scotch Brite
888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
6
4. Depress the area still supported by
the table track to check for wobble
5. Pull the sliding table back to the table
stop
6. Depress the area still supported by the
table track to check for wobble. If the
table appears to be stable, No
Adjustment is required
888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
7
7. If the table is unstable and need
adjustment, Remove the rolling table
and place it on the stand with the
rollers facing up with the front
(POINTY END) of the table on the right
side
8. Place the long side of a square in the
valley of the larger lower guide rollers
9. Verify all three (3) lower guide rollers
are on the same plane by placing
straight edge in the valley of all three
(3) lower guide rollers and moving the
straight edge back and forth. Verify all
three (3) lower guide rollers rotate
simultaneously
NOTE: The CENTER lower guide roller is
the only adjustable wheel.
10. Loosen the Center lower guide roller
slightly so that the eccentric may be
adjusted and holds its position.
11. Adjust the eccentric to raise or lower
the center lower guide roller as needed
888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
8
12. Verify all three (3) lower guide rollers
are on the same plane by placing
straight edge in the valley of all three
(3) lower guide rollers and moving the
straight edge back and forth. Verify all
three (3) lower guide rollers rotate
simultaneously. Repeat previous step
until satisfied
13. Flip the rolling table so the front
(POINTY END) of the table is now on
the left side
14. Place the long side of a square in the
lower guide rollers
NOTE: the lower guide rollers are above the
upper rollers since the rolling table is
upside down
888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
9
15. Loosen All three (3) lower guide rollers
so the eccentrics may be adjusted, and
the wheel hold its position.
16. Adjust each lower roller so the lower
guide roller is at its lowest position
when the table is installed in the saw
stand
17. Verify all three (3) lower guide rollers
are on the same plane. Repeat previous
step until satisfied
18. Slide the sliding table into the saw
stand
888-274-7744 iQTS244
www.iqpowertools.com Repair Manual
10
19. Check the adjustment on each upper
guide rollers by attempting to roll the
wheel while applying some pressure on
top of the table. If the upper guide
roller spins freely, the eccentric will
need to be adjusted up. If the upper
guide roller does not turn, the eccentric
will need to be adjusted down. The
upper guide roller should contact the
upper end of the channel with slight
friction for proper adjustment. REPEAT
for ALL Six (6) sliding table upper
rollers
20. Push the sliding table forward to the
mechanical stop and check adjustment
by depressing rear section of the table.
Play should be very minimal
21. Pull the sliding table back to the table
stop and check adjustment by
depressing rear section of the table.
Play should be very minimal
