IoTecha CCS-ACL2 User manual
Copyright © 2020 IoTecha Corp. All rights reserved.
19.2kW Electric Vehicle
Smart Charger
Model: CCS-ACL2
Copyright © 2020 IoTecha Corp. All rights reserved.
NOTICE: This manual contains the latest information at the time of printing. The manufacturer reserves the right
to make changes to the product without further notice to the purchaser. Changes or modifications to this product
by any person or entity other than an authorized service facility will void the product warranty.
If you have questions about the use of this product, contact your customer service representative.
Copyright © 2020 IoTecha Corp. All rights reserved.
FCC Declaration of Conformity – Class B
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case users will
be required to correct the interference at their own expense.
Connections between the Harmonic equipment and other equipment must be made in a manner that is
consistent with maintaining compliance with FCC radio frequency emission limits. Modifications to this equipment
not expressly approved by Harmonic may void the authority granted to the user by the FCC to operate this
equipment and you may be required to correct any interference to radio or television communications at your
own expense.
Copyright © 2020 IoTecha Corp. All rights reserved.
RETURN FOR SERVICE
If you encounter operational or other problems with the charger, contact your local dealer. If the problem requires
return for service, please follow the dealer’s instructions for return of the product.
SAVE THESE INSTRUCTIONS
The purpose of this manual is to provide you with information necessary to safely operate this equipment. Keep this
manual for future reference.
Device Information Label
Copyright © 2020 IoTecha Corp. All rights reserved.
Contents
Installation Guide .............................................................................................. 1
IMPORTANT SAFETY INSTRUCTIONS ............................................................................................................... 2
Specification .......................................................................................................................................................... 8
Supported Electrical Connections ........................................................................................................................ 11
Unpacking ........................................................................................................................................................... 14
Preparation .......................................................................................................................................................... 15
Installation ........................................................................................................................................................... 21
User Guide ....................................................................................................... 43
IMPORTANT SAFETY INSTRUCTIONS ............................................................................................................. 44
The EV Charger .................................................................................................................................................. 48
Charging the vehicle ............................................................................................................................................ 50
Troubleshooting ................................................................................................................................................... 52
Fact Sheet ........................................................................................................ 53
EV Charger Fact Sheet ....................................................................................................................................... 54
Copyright © 2020 IoTecha Corp. All rights reserved.
1
Installation Guide
Copyright © 2020 IoTecha Corp. All rights reserved.
2
INSTRUCTIONS PERTAINING TO A RISK OF FIRE OR
ELECTRIC SHOCK
IMPORTANT SAFETY INSTRUCTIONS
Read this manual thoroughly and make sure you understand the procedures before you attempt to install
or operate this equipment.
This product is intended for charging electric vehicles only.
This product shall be installed, adjusted, and serviced by qualified electrical personnel.
Isolate the product from any electrical source before wiring or servicing it. Failure to follow this may lead to
severe bodily injury or death.
This product shall be installed by a qualified electrician, and installation must be in accordance with all
applicable local and national electrical codes and standards. Failure to observe this warning could result
in death or severe injury.
Copyright © 2020 IoTecha Corp. All rights reserved.
3
ELECTRIC SHOCK PREVENTION MEASURES
Do not expose the live part of this product and its cables.
This product must be grounded through a permanent wiring system or an equipment grounding conductor.
Install circuit breakers to reduce the severity of electric shock accidents.
Limit the authorized personnel responsible for handling switches on electrical appliances.
Do not touch this product with hands.
Do not use faulty or malfunctioning cables or breakers on this product.
ELECTRIC FIRE PREVENTION MEASURES
The cables and wires used to install this product must satisfy local laws and regulations.
This device must be run on a dedicated branch circuit in accordance with all regulations
Keep combustible material away from the installation area of this product.
Keep sufficient distance from any heat source.
Take care not to damage or overheat the wire coating of this product and its connections.
Copyright © 2020 IoTecha Corp. All rights reserved.
4
MOVING AND STORAGE INSTRUCTIONS
Storage/Moving/Transportation Temperature: -40°C to + 60°C
The tools for transportation shall satisfy all requirements to ensure the normal and safe operation of the
charger and to avoid personal injury.
Do not hold the unit by the front cover during transportation or it may be separated accidently.
If any damage is found before installation, stop the installation, and call your local dealer for assistance.
Store the charger disconnected and unplugged from the power source in a flat position. The internal parts
may carry electricity until it is unplugged from outlet.
Store it in a cool and dry place.
Do not store the changer along with or around metal objects.
Table of contents
