INVROHEAT IHWS2022-vs2 User manual
INVROHEAT
ROOM HEATER
Changing the world of heating
CHANGING THE WORLD OF HEATING
www.invroheat.com
IHWS2022-vs2 Wall Panel
Read carefully and keep as reference for future use
User Manual
ENGLISH
CHANGING THE WORLD OF HEATING
www.invroheat.com
2
SYMBOLS
This symbol indicates a hazard with a medium level of risk which, if not
avoided, could result in serious injury or death.
This symbol indicates danger to the life and health of persons due to
electrical voltage.
This symbol on the device indicates that it is prohibited to place objects
(such as towels, clothing, etc.) above or directly in front of the device. To
avoid overheating and risk of fire, the device must not be covered.
This symbol on the appliance indicates that the surfaces are hot during
and immediately after use. Hot surfaces must not be touched: risk of
burns.
This symbol on the device indicates that it is forbidden to spray the
device.
This symbol on the device indicates that the instructions in the manual
must be observed when installing and using the device.
CHANGING THE WORLD OF HEATING
www.invroheat.com 3
CONTENT
About the device
Warnings and Precautions
Technical information
Included parts
Device structure
Wall mounting instructions
Accessories
4
5
8
9
9
10
12
CHANGING THE WORLD OF HEATING
www.invroheat.com
4
ABOUT THE DEVICE
The appliance is designed to provide an efficient, comfortable and healthy heating
system for residential or commercial properties.
Infrared heating panels can reduce air circulation and help maintain a clean, quiet,
and dust-free environment.
Infrared panels are designed for indoor environments with normal heating needs.
They are ideal for homes, schools, hospitals and offices. They should not be used
outdoors or in large internal areas such as workshops or warehouses.
Infrared heating works differently from traditional heating. As a result of the
radiation, people are heated (such as by solar radiation) and it takes a while for
objects to give back heat (such as the earth does at night due to the warming
during the day). This means that most users have to get used to infrared as a heat
source.
Many suppliers of infrared panels finish their panels with an aluminum front.
Since infrared radiation is a form of light, this means that such devices no longer
actually emit infrared. The heat that is created is then actually contact heat that
leads to convection. Invroheat does not work that way and ensures that the film
used transmits infrared radiation and thus retains the actual effect. As a result, the
surface may show slight bumps. This is not dangerous and is normal. As soon as the
device is switched off, the bubbles disappear again. It will also decrease over time.
In this way we do deliver the best quality infrared radiation and you will actually
experience heat.
Invroheat’s range of infrared panels are available in a wide variety of sizes and
styles. Invroheat products are manufactured in the EU and meet European quality
standards.
CHANGING THE WORLD OF HEATING
www.invroheat.com 5
WARNINGS
Please read this manual carefully before using or installing the device.
Always keep the manual in the immediate vicinity of the device or the
place of use. Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result
to electric shock, fire, serious injury, or all of the above. Save all warnings
and instructions for future reference.
Do not install panels on the ceiling that are designed for wall mounting
only. Using panels in unspecified locations can cause panels to
overheat and pose a fire hazard.
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
the hazards involved. Children must not play with the appliance.
Cleaning and user maintenance must not be made by children without
supervision.
Children under the age of 8 must not connect, adjust or clean the
appliance or carry out maintenance.
Children under 3 years of age should be kept away unless continuously
supervised. Children from 3 years old and under 8 years old are only
allowed to switch on/off the appliance when it is placed or installed.
Do not use the device in closed rooms if people are present who
cannot leave the room independently and are not under constant
supervision.
Some parts of this product can become very hot and cause burns.
Do not install near curtains or other flammable materials. Particular
attention should be paid to the presence of children and vulnerable
adults. To avoid the possibility of injury, the following persons should
be particularly careful when using the heater: infants and children,
the elderly, the disabled, people with medical conditions, people with
sensitive skin, and people under the influence of alcohol, drugs, or
sleeping pills.
CHANGING THE WORLD OF HEATING
www.invroheat.com
6
Before use, remove any protective films (on the front and on the back).
Make sure the operating voltage is between 220-240V, 50Hz and the
power supply is strictly in accordance with IEC regulations. The device
must be grounded. Any outlet used with the device must be at least 5A.
Do not use the device in areas where contact with flammable or
potentially explosive materials such as dust, gas or vapor cannot be
avoided.
Do not use in rooms or environments with a corrosive atmosphere.
Place the device upright and stable.
Do not use the device when it is wet. If the device gets wet during
cleaning, let it dry before use.
Do not use the device with wet or damp hands.
Never insert fingers or objects into the device.
Do not transport the device during use.
Do not sit on the device.
This device is not a toy. Keep out of reach of children and animals. Do
not leave the device unattended during use.
Before each use of the device, check accessories and connecting parts
for possible damage. Do not use defective devices or device parts.
Make sure that all electrical cables outside the device are protected
against damage, e.g. by animals or furniture. Never use the device if
electrical cables or power connections are damaged. The electrical
connection must comply with the specifications in the technical
information chapter. Insert the plug into a properly secured socket. Do
not overload the outlet used to power the device.
Consider the output power, cable length, and intended use of the
device when considering using an extension cable. If an extension
cable is used, it must be unrolled completely. Do not coil the cable.
Avoid electrical overload. Do not create a hazard with trailing wires.
WARNINGS
CHANGING THE WORLD OF HEATING
www.invroheat.com 7
Before carrying out any maintenance, care or repair work on the device,
make sure that the device is disconnected from the power supply. Do
not use the cable to pull the plug out of the socket. Hold the plug by
the housing and pull.
Switch off the appliance and unplug it from the socket when the
appliance is not in use.
Do not use the device under any circumstances if you notice damage
to the plug or power cable. If the power cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard. Faulty power cables pose a serious
health risk.
When installing the device, take into account the minimum distances
from walls and other objects and the storage and operating conditions
specified in the installation instructions.
Never drill into the heater.
Do not use the device near curtains or other flammable materials.
Let the appliance cool down before touching it, transporting it or
carrying out maintenance work.
The device should be placed where the switches and controllers cannot
be touched by a person in a bath or shower.
Only use the device when you are present in the room.
WARNINGS
CHANGING THE WORLD OF HEATING
www.invroheat.com
8
TECHNICAL INFORMATION
REGARDING
Heating element
Heating method
Voltage
Surface temperature
Frame
IP-value
Protection against overheating
Power cable length
VALUE
Carbon crystal
Infrared radiation
220-240V / 50Hz
Wall panels: about 95-130 oC
Aluminum
IP20
Yes
2.5m
MODEL
IHWS2021
IHWS2022-vs2
...
SIZE (mm)
1000 x 600 x 48
915 x 610 x 26 excl. mounting
...
POWER (W)
650W
800W
...
POWER (A)
3.0
3.6
...
MOUNTING
Wall / Ceiling
Wall / Ceiling
Warning
Using panels in unspecified locations can cause panels to overheat and pose a fire hazard.
The panel can reach 130 degrees Celsius, but is equipped with an overheating thermostat.
CHANGING THE WORLD OF HEATING
www.invroheat.com 9
3
2
1
4 5
INCLUDED PARTS
1x Heating panel (A)
1x Wall mounting set
4x Screws (B)
4x Wall plugs (C)
1x Drilling template (D)
1x Manual (E)
The supplied kit should only be used for wall mounting.
Specialized ceiling mounting kits are available through Invroheat. Kits are available
for both direct and pendant installation. Purchase a suitable kit before installing to
the ceiling.
1. Aluminum frame
2. Insulation plate
3. Heating element with IR-coating
4. Mounting brackets
5. Power cable
DEVICE STRUCTURE
E
CHANGING THE WORLD OF HEATING
www.invroheat.com
10
INSTRUCTIONS FOR WALL MOUNTING
These instructions only apply to wall mounting. For ceiling mounting, please refer
to our website.
The appliance is not suitable for installation in the bathroom, even if this is done by
a specialized installer.
Choose the mounting position, taking into account the minimum distances to
surrounding walls, ceilings or (fixed) objects.
Minimum distances must be observed. Mounting closer than recommended will
result in a fire hazard.
Stick the drilling template on the wall. Drill the holes with a 6 mm drill.
Minimum distances
- Front: 300mm
- Left: 100mm
- Right: 100mm
- Top: 500mm
