Invacare InTouch 1143199 Operation manual

Owner’s Operator and Maintenance Manual

DEALER: This manual MUST be given to

the user of this product.

USER: BEFORE using this product, read this

manual and save for future reference.

For more information regarding

Invacare products, parts, and services,

please visit www.invacare.com

InTouch™Propel™Back

InTouch™Propel™Back 2Part No 1143199

 WARNING

DO NOT OPERATE THIS EQUIPMENT WITHOUT FIRST READING

AND UNDERSTANDING THIS MANUAL. IF YOU ARE UNABLE TO

UNDERSTAND THE WARNINGS, CAUTIONS AND

INSTRUCTIONS CONTACT A QUALIFIED DEALER OR INVACARE

TECHNICAL SUPPORT BEFORE ATTEMPTING TO USE THIS

EQUIPMENT - OTHERWISE INJURY OR DAMAGE MAY RESULT.

NOTE:Updatedversionsofthismanualareavailableonwww.invacare.com.

SPECIAL NOTES

Part No 1143199 3InTouch™Propel™Back

SPECIAL NOTES

Signalwordsareusedinthismanualandapplytohazardsorunsafepracticeswhich

couldresultinpersonalinjuryorpropertydamage.Refertothetablebelowfor

definitionsofthesignalwords.

NOTICE

THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO

CHANGE WITHOUT NOTICE.

MAINTENANCE

Maintenance MUST be performed ONLY by qualified personnel.

Invacare products are specifically designed and manufactured for use in conjunction

with Invacare accessories. Accessories designed by other manufacturers have not

been tested by Invacare and are not recommended for use with Invacare products.

SIGNAL WORD MEANING

DANGER Danger indicates an imminently hazardous situation which,

if not avoided, will result in death or serious injury.

WARNING Warning indicates a potentially hazardous situation which, if

not avoided, could result in death or serious injury.

CAUTION Caution indicates a potentially hazardous situation which, if

not avoided, may result in property damage.

TABLE OF CONTENTS

InTouch™Propel™Back 4Part No 1143199

TABLE OF CONTENTS

SPECIAL NOTES ................................................................................3

SECTION 1—GENERAL GUIDELINES ...................................................7

Important Information...............................................................................................................................7

Seating Pressure Warning.........................................................................................................................7

Installation Warnings..................................................................................................................................7

Maximum Weight Rating...........................................................................................................................8

SECTION 2—INSTALLING ..................................................................9

Installation Overview.................................................................................................................................9

Installing Mounting Hardware..................................................................................................................9

Installing/Removing the Propel Back ................................................................................................... 11

Adjusting the Propel Back Width......................................................................................................... 12

Installing/Removing the Propel Back Cushion................................................................................... 13

Installing the Cushion ......................................................................................................................... 13

SECTION 3—OPERATION ................................................................ 14

Adjusting the Propel Back Depth and Angle ..................................................................................... 14

SECTION 4—MAINTENANCE ........................................................... 15

Replacing Upholstery .............................................................................................................................. 15

Replacing Cushion ................................................................................................................................... 15

Cleaning Instructions .............................................................................................................................. 16

Back Assembly ..................................................................................................................................... 16

Cover ..................................................................................................................................................... 16

Foam....................................................................................................................................................... 16

LIMITED WARRANTY ..................................................................... 17

The benefits of registering:

1. Safeguard your investment.

2. Ensure long term maintenance and servicing of your purchase.

3. Receive updates with product information, maintenance tips, and industry news.

4. Invacare can contact you or your provider, if servicing is needed on your product.

5. It will enable Invacare to improve product designs based on your input and needs.

- or -

Complete and mail the form on the next page

Part No 1143199 5InTouch™Propel™Back

Name _______________________________________________________________

Address _____________________________________________________________

City ___________________ State/Province __________

Zip/Postal Code ________

Email ___________________________________ Phone No. _________________

Invacare Model No. ______________________ Serial No. __________________

Purchased From _________________________Date of Purchase:___________

1. Method of purchase: (check all that apply)

❏ Medicare ❏ Insurance ❏Medicaid ❏ Other __________________________

2. This product was purchased for use by: (check one)

❏ Self ❏ Parent ❏ Spouse ❏ Other

3. Product was purchased for use at:

❏ Home ❏ Facility ❏ Other

4. I purchased an Invacare product because:

❏ Price ❏ Features (list features) _________________________________________

5. Who referred you to Invacare products? (check all that apply)

❏Doctor ❏ Therapist ❏ Friend ❏Relative ❏Dealer/Provider ❏Other_________

❏ Advertisement (circle one): TV, Radio, Magazine, Newspaper ❏ No Referral_____

6. What additional features, if any, would you like to see on this product?

__________________________________________________________________________

7. Would you like information sent to you about Invacare products that may be available for a

particular medical condition? ❏Yes ❏No

If yes, please list any condition(s) here and we will send you information by email and/or mail about

any available Invacare products that may help treat, care for or manage such condition(s):

__________________________________________________________________________

8. Would you like to receive updated information via email or regular mail about the Invacare

home medical products sold by Invacare's dealers? ❏Yes ❏No

9. What would you like to see on the Invacare website?

__________________________________________________________________________

10. Would you like to be part of future online surveys for Invacare products? ❏ Yes ❏ No

11. User's Year of birth: ______________________________________________________

If at any time you wish not to receive future mailings from us, please contact us at Invacare Corporation,

CRM Department, 39400 Taylor Parkway, Elyria, OH 44035, or fax to 877-619-7996 and we will remove

you from our mailing list.

To find more information about our products, visit www.invacare.com.

PRODUCT REGISTRATION FORM

Complete and mail this form

Cut Along Line

Fold

here

Fold

here

InTouch™Propel™Back 6Part No 1143199

Fold

here

Fold

here

Cut Along Line

Invacare Product Registration Form

Please Seal with

Tape Before Mailing

SECTION 1—GENERAL GUIDELINES

Part No 1143199 7InTouch™Propel™Back

SECTION 1—GENERAL GUIDELINES

 WARNING

SECTION 1 - GENERAL GUIDELINES contains important information for the safe

operation and use of this product. DO NOT use this product or any available

optional equipment without first completely reading and understanding these

instructions and any additional instructional material such as Owner’s Manuals, Ser-

vice Manuals or Instruction Sheets supplied with this product or optional equip-

ment. If you are unable to understand the Warnings, Cautions or Instructions,

contact a healthcare professional, dealer or technical personnel before attempting

to use this equipment - otherwise, injury or damage may occur.

Important Information

Thebestwaytoavoidproblemsrelatedtopressuresoresistounderstandtheircauses

andyourroleinaskinmanagementprogram.

Yourtherapistandphysicianshouldbeconsultedifyouhaveanyquestionsregarding

weightrelief,self‐examinationofskin,orindividuallimitationsandneeds.

Allseatingsystemsshouldbeselectedcarefully.Workingwithyourtherapist,physician

andequipmentsupplieristhebestwaytoassurethataseatingsystemchoicematches

yourindividualneeds.

Astheneedsoftheindividualbecomemorecomplex,thePropelBackevaluation

becomesmoreimportant.

ThePropelBackisnotdesignedforusewithtilt‐in‐spaceand/orreclinemodel

wheelchairs.

Seating Pressure Warning

Skinconditionshouldbecheckedfrequentlyaftertheinstallationanduseofanynew

seatingsystem.

Installation Warnings

Afteranyadjustments,repairorserviceandbeforeuse,makesurethatallattaching

hardwareistightenedsecurely.

DONOTinstallthePropelBackassemblyontobackcaneswithanoutsidediameter

greaterthan1‐inchorlessthan.86‐inch‐otherwiseinjuryordamagemayoccur.

EnsurethePropelBackisproperlysecuredtothewheelchairbeforeusing.

ThePropelBackMUSTberestingflushagainstthetabsonthecanemountingbrackets.

BothrightandleftbacklatchesMUSTbefullyengaged.

SECTION 1—GENERAL GUIDELINES

InTouch™Propel™Back 8Part No 1143199

 WARNING

The position of the Propel Back is directly related to the wheelchair’s stability. It

may be necessary to reposition the front casters, rear wheels, back angle, and/or

seat depth before use. Use EXTREME caution when using a new seating position.

Maximum Weight Rating

16 - 21-INCH WIDTH

MAXIMUM WEIGHT RATING 300 lbs

SECTION 2—INSTALLING

Part No 1143199 9InTouch™Propel™Back

SECTION 2—INSTALLING

WARNING

Check ALL fasteners periodically to ensure that mechanical connections and

attaching hardware are tightened securely - otherwise injury or damage may occur.

DO NOT continue to use this product if problems are discovered. Corrective

maintenance can be performed at or arranged through your equipment supplier.

The Propel Back is not designed for use with tilt-in-space and/or recline model

wheelchairs.

Installation Overview

NOTE:Forthisprocedure,refertoFIGURE2.1.

1. Removeanyexistingbackupholsteryorbacksystemfromthechairbefore

installation.RefertoOwner’sManualshippedwithwheelchair.

2. Installmountinghardware.RefertoInstallingMountingHardwareonpage 9.

3. InstallPropelBackontothewheelchair.RefertoInstalling/RemovingthePropelBack

onpage 11.

4. Makeanynecessarydepthand/orangleadjustments.RefertoAdjustingthePropel

BackDepthandAngleonpage 14andAdjustingthePropelBackWidthonpage 12.

FIGURE 2.1 Installation Overview

Installing Mounting Hardware

NOTE:Forthisprocedure,refertoFIGURE2.2onpage10.

NOTE:Canebracketsadjusttofit7/8”to1”backcanes.Noadditionalhardwareisrequired.

1. Positionthecanemountingbracketontothebackcaneatthedesiredheight.

STEP 2

STEP 3

STEP 4

SECTION 2—INSTALLING

InTouch™Propel™Back 10 Part No 1143199

NOTE:Ensurethatthebacktabispositionedtowardstheinsideofthewheelchairandtheround

endispointingupward.

2. Securethecanemountingbracketandwedgeblockstothebackcanewiththetwo

mountingboltsandhexnuts.Handtightensecurely.

NOTE:Somewheelchairshaveadjustablebackcanesthatareboth7/8”and1”.Ensurethewedge

blocksarecompletelyoneitherthe7/8”or1”sectionandnotstraddlingthetwo.RefertoDetail

“A”inFIGURE2.2.

NOTE:Itmaybenecessarytoraiseorlowerthebackcanestoachievethedesiredbracket

placement.RefertoOwner’sManualshippedwithwheelchair.

3. RepeatSTEPS1and2fortheothercanemountingbracket.

NOTE:CanemountingbracketsMUSTbeparalleltoeachother.

4. Usingthewrenchsuppliedor7/16socketwrench,securelytightenthemounting

bolts.

NOTE:DONOTtightenthemountingboltsuntilthebackheighthasbeenadjustedcorrectly.

NOTE:Checkthealignmentofthemountingbracketsbeforetightening.

FIGURE 2.2 Installing Mounting Hardware

Hex Nut

Mounting

Bolts

Back Cane

Cane

Mounting

Bracket

Back Tab

Wedge

Block

Wedge

Block

Hex Nut

Inside of

Wheelchair

Outside of

Wheelchair

DETAIL “A” -

ADJUSTABLE BACK

CANES

7/8” section

1” Section

NOTE:Measure

samedistanceon

bothsides.

This manual suits for next models

Table of contents

Languages:

Other Invacare Mobility Aid manuals

Invacare

Invacare TDX Spree Instruction Manual

Invacare

Invacare Storm Series Instruction Manual

Invacare

Invacare WALKING TUTOR WT 200 User manual

Invacare

Invacare 2218 Assembly instructions

Invacare

Invacare Deluxe Three-Position IH6065 User manual

Invacare

Invacare Aquatec Ocean E-VIP User manual

Invacare

Invacare Lima H263 User manual

Invacare

Invacare Articulating/Elevating Legrest User manual

Invacare

Invacare Recline User manual

Invacare

Invacare 1110154 User manual

Invacare

Invacare Tracer SX5 Recliner Instruction manual

Invacare

Invacare BUZZ HMV Manual

Invacare

Invacare H140 User manual

Invacare

Invacare Silhouette 3002801 User manual

Invacare

Invacare 2GT Instruction Manual

Invacare

Invacare SEAT RIGIDIZER Assembly instructions

Invacare

Invacare MB-54 Assembly instructions

Invacare

Invacare Adjustable Back Upholstery Manual

Invacare

Invacare Solara/Spree GT 1134808 User manual

Invacare

Invacare Matrx MX1 User manual

Invacare

Invacare Force Manual

Invacare

Invacare Dolomite Brass User manual

Invacare

Invacare Dolomite Melody Series User manual

Invacare

Invacare Stileo H170 User manual

Popular Mobility Aid manuals by other brands

Alber

Alber Scalamobil iQ operating instructions

Ferno

Ferno CCT-PX user manual

HEPRO

HEPRO Gripo user manual

Otto Bock

Otto Bock Pheon 3R62 Instructions for use

NRS Healthcare

NRS Healthcare M11090 User instructions

Medline

Medline MDS86835DSHEC User Instructions & Warranty

Guldmann

Guldmann Twin Turner II user manual

Drive

Drive ROOMBA Operation manual

Gate

Gate Balder operating instructions

Decon wheel

Decon wheel TNS Notos Assembly instructions

ExoAtlet

ExoAtlet ExoAtlet-II user manual

Rhythm Healthcare

Rhythm Healthcare B3800F manual

AMF-BRUNS

AMF-BRUNS PROTEKTOR installation manual

Drive DeVilbiss Healthcare

Drive DeVilbiss Healthcare OTTER Instructions for use

Rhythm Healthcare

Rhythm Healthcare C500U Assembly and Fitting Instructions

Lumex

Lumex RJ4200A manual

Rebotec

Rebotec Jumbo user manual

Rehaforum MEDICAL

Rehaforum MEDICAL PR50548 manual
