Intersoft Electronics UDR600 User manual
USB Data Recorder - UDR600 and UDR765
User Manual
Edition: 2
Date: 20-Dec-12
Status: Released Issue
USB Data Recorder - UDR600 and UDR765 Edition Date: 20-Dec-12
DOCUMENT CHARACTERISTICS
General
USB Data Recorder - UDR600 and UDR765
User Manual
Edition 2
Edition Date 20-December-2012
Status Released Issue
Keywords User manual USB Data Recorder UDR600 UDR765
Abstract This user manual describes the use of the UDR600 and the UDR765.
Contact Information
Author Elke Vanuytven
Editor Elke Vanuytven
Contact Person Niels Van Hoef
Tel +32 14 23 18 11
E-mail Address [email protected]
Document Control Information
Document Name IE-UM-00170-002 UDR600-UDR765 User Manual.odt
Path C:\Documents and Settings\elke\Desktop\RASS-S User
Manuals\UDR600-765\
Host System Mac OS X 10.5.6
Software OpenOffice.org 3.0.1
Size 821021Bytes
IE-UM-00170-002 UDR600-UDR765 User Manual.odt 2/22
USB Data Recorder - UDR600 and UDR765 Edition Date: 20-Dec-12
DOCUMENT CHANGE RECORD
Revision Date Reasons for change Pages
Affected
Approved
by
001 10-Mar-10 New document All EV
002 19-Dec-12 Use of UDR765 is added to original UDR600
manual
All EV
IE-UM-00170-002 UDR600-UDR765 User Manual.odt 3/22
USB Data Recorder - UDR600 and UDR765 Edition Date: 20-Dec-12
TABLE OF CONTENTS
1. TECHNICAL MANUAL UDR600-UDR765.......................................................................8
1.1. General Introduction...........................................................................................................................8
1.2. Key Features.......................................................................................................................................8
1.3. Supported Protocols..........................................................................................................................8
1.4. Hardware Description.........................................................................................................................9
1.4.1. UDR600........................................................................................................................................9
1.4.2. UDR765......................................................................................................................................11
2. UDR DATA RECORDING BIT OR SERIAL PROTOCOL RECORDING.......................................12
2.1. Introduction.......................................................................................................................................12
2.2. Recording Software..........................................................................................................................12
2.2.1. Getting Started............................................................................................................................12
2.2.2. Making a Recording....................................................................................................................13
2.3. Conversion Software........................................................................................................................15
2.3.1. Convert Bit Recording.................................................................................................................15
2.3.1.1. Single Conversion....................................................................................................................15
2.3.1.2. Batch Conversion....................................................................................................................17
2.3.2. Convert Data Recording.............................................................................................................18
2.3.2.1. Single Conversion....................................................................................................................18
2.3.2.2. Batch Conversion....................................................................................................................19
3. DATA ANALYSIS.........................................................................................................19
4. ANNEXES.................................................................................................................20
4.1. Annex 1 UDR600 Data Recording Connection Diagram...............................................................20
4.2. Annex 2 UDR765 Data Recording Connection Diagram...............................................................21
4.3. Annex 3 Configuration List UDR600.............................................................................................22
4.4. Annex 4 Configuration List UDR765.............................................................................................22
IE-UM-00170-002 UDR600-UDR765 User Manual.odt 4/22
USB Data Recorder - UDR600 and UDR765 Edition Date: 20-Dec-12
TABLE OF FIGURES
Figure 1: UDR Control software..................................................................................................................11
Figure 2: UDR Recording.............................................................................................................................13
Figure 3: Convert Bit Recording software..................................................................................................14
Figure 4: PPI Dis lay....................................................................................................................................15
Figure 5: Hexadecimal dis lay of converted data.....................................................................................16
Figure 6: Batch Process section of Convert software..............................................................................16
Figure 7: Convert Radar Data software......................................................................................................17
Figure 8: Hexadecimal dis lay of converted data.....................................................................................18
Figure 9: Data Recording Connection Diagram.........................................................................................19
TABLE OF TABLES
Table 1: UDR600 Connectors........................................................................................................................9
Table 2: Serial Data 1/2 DB15 connectors in layout................................................................................10
Table 3: RS 232 C Receivers (com atible with RS232C standard)...........................................................10
Table 4: RS 232 C Drivers (com atible with RS232C standard)...............................................................10
Table 5: RS422 Receivers (com atible with RS422 standard)..................................................................10
Table 6: RS422 Drivers (com atible with RS422 standard)......................................................................10
IE-UM-00170-002 UDR600-UDR765 User Manual.odt 5/22
USB Data Recorder - UDR600 and UDR765 Edition Date: 20-Dec-12
CONVENTIONS USED
Note: This icon to the left of bold italicized text denotes a note, which alerts you to
im ortant information.
Caution: This icon to the left of bold italicized text denotes a caution, which alerts you to the
ossibility of data loss or a system crash.
Warning: This icon to the left of bold italicized text denotes a warning, which alerts you to t
he ossibility of damage to you or your equi ment.
IE-UM-00170-002 UDR600-UDR765 User Manual.odt 6/22
G
%
M
USB Data Recorder - UDR600 and UDR765 Edition Date: 20-Dec-12
GLOSSARY OF TERMS
ACP Azimuth Change Pulse
ARP Azimuth Reference Pulse
CPU Computer Processing Unit
FL Flight Level unit of altitude (expressed in 100’s of feet)
FRUIT False Replies Unsynchronized In Time unwanted SSR replies
received by an interrogator which have been triggered by other
interrogators
GPS Global Positioning System
ICD Interface Control Document
IE Intersoft Electronics
I/O Input/Output
IP Internet Protocol
LAN Local Area Network
MSSR Monopulse Secondary Surveillance Radar
Plot extractor Signal-processing equipment which converts receiver video into
digital target reports suitable for transmission by land lines
PPI Plan Position Indicator
PSR Primary Surveillance Radar
Radar Radio Detection And Ranging
Radome Radio-transparent window used to protect an antenna principally
against the effects of weather
RASS-R Radar Analysis Support Systems – Real-time measurements
RASS-S Radar Analysis Support Systems – Site measurements
RDP Radar Data Processing (system)
SAC System Area Code
SIC System Identification Code
SSR Secondary Surveillance Radar
TCP Transmission Control Protocol
TIS-B Traffic Information Services Broadcast
UTC Coordinated Universal Time
IE-UM-00170-002 UDR600-UDR765 User Manual.odt 7/22
USB Data Recorder - UDR600 and UDR765 Edition Date: 20-Dec-12
1. TECHNICAL MANUAL UDR600-UDR765
1.1. General Introduction
A vital part of the radar chain is the data processing unit with at its output a data stream containing radar
plots or tracks in a specific format. The most common format is ASTERIX some radars use other formats
like RDIF AIRCAT CD etc. If we want to analyse this data it must first be recorded and converted into a
uniform format that can be displayed and analysed by dedicated RASS software tools. Generally the data is
produced on serial lines because it needs to be transmitted to one or more remote centres. This serial link
can use protocols like HDLC LAP-B or X25. Other formats use a unique protocol such as the 13-bit
formatted CD.
The USB Data Recorder (UDR600 or UDR765) allows to record 2 lines of serial radar data passively (spy-
mode). We currently support unnumbered HDLC or LAP-B connections and a wide range of radar data
formats (such as ASTERIX RDIF Aircat EUROCONTROL CD ...). Tools are provided to analyse the
recorded data for protocol errors or convert the data directly into a display format.
Since the UDR only allows to record passively the connection itself is spied upon by the UDR. If more than
two channels are required multiple UDRs can be "stacked". The additional inputs azimuth and time make it a
real radar evaluation tool. This allows for example evaluating the extraction delay.
The recordings made by the UDR can then be converted into a suitable data format for further evaluation:
this can be a SASS-C compatible format or the RASS-S data format (.S4). Furthermore since the full
communication protocol is recorded together with the radar data an analysis of the line quality and
communication protocol syntax is possible.
1.2. Key Features
•Passive recording of a multitude of radar protocols: ASTERIX RDIF EC ECKlu Alenia Aircat
AustroControl BMIL CD xxx ERICSSON FPS SVE Toshiba TRS
•Simultaneous recording of 1 or 2 lines
•Possibility to connect a GPS for UTC time of recording
1.3. Supported Protocols
The UDR600 and UDR765 can handle 4 basic protocols in passive mode meaning that the UDR “spies” on
the data without participating to the actual protocol:
•U-HDLC: Passive recording of HDLC based protocols including LAP-B and X25.3 Passive
monitoring (E.g. ASTERIX RDIF)
•LINK 1: Passive recording of Military LINK 1 protocol
•SYNC 13: Passive recording of most bit protocols as implemented on US radars (CD1 CD2 ASR9
etc...)
•BISYNC: Aircat 500: passive recording of Thales specific protocol TVT2 military protocol
Using the Bit Recording function the following protocols are supported:
◦AIRCAT 500
◦ALENIA
◦AUSTRO
◦BMIL
◦ERICSSON
◦EUROCONTROL
◦FPS 117
IE-UM-00170-002 UDR600-UDR765 User Manual.odt 8/22
USB Data Recorder - UDR600 and UDR765 Edition Date: 20-Dec-12
◦HUGHES
◦SVE
◦TOSHIBA
◦CUSTOMER SPECIFIC
1.4. Hardware Description
The UDR600 and UDR765 has 2 serial communication channels for active and passive recording. They can
handle transmission speeds up to 128 Kb/s. Two electrical standards are supported: RS232 (single ended)
and RS422 (differential). The serial data is fed to the recorder using a female DB15 connectors (alike X.21
connections). The unit is supplied with 2 RS232 Probe modules for connection of the DB15 to DB25
standard RS232 connection. A whole range of synchronous protocols is supported and others can be
programmed upon request.
1.4.1. UDR600
The UDR600 connectors are described in the following table:
Table 1: UDR600 Connectors
Name Specification Connector Type Value
CH1/2 Serial Data 1/2 2x DB15 female Synchronous serial input
RS232/RS422
Radar Timing
ACP/ARP
Radar Timing ACP/ARP signals DB15HD female TTL
USB Data USB data USB USB2.0
GPS GPS450 interface for UTC time stamping RJ45 Intersoft proprietary
GPS Power In Connector for power supply for GPS450
IE-UM-00170-002 UDR600-UDR765 User Manual.odt 9/22
USB Data Recorder - UDR600 and UDR765 Edition Date: 20-Dec-12
The pin layout of the Serial Data 1/2 DB15 connectors is shown in the table below:
Table 2: Serial Data 1/2 DB15 connectors pin layout
Name DB15(f)
Gnd 1 8
TxD+ 9
TxD- 2
RxD+ 11
RxD- 4
RxC+ 13
RxC- 6
TrxC+ 14
TrxC- 7
TxC+ /
TxC- /
-10Volt 12
+10Volt 5
+5Volt (USB4.2V) 15
The specifications of the serial inputs/outputs are listed in the following tables:
Table 3: RS 232 C Receivers compatible with RS232C standard)
Input resistance 3kΩ min. 5kΩ typ. 7kΩ max.
Low threshold 1.2V typ. 0.8 min.
High threshold 1.7V typ. 3.0 max.
Impedance 5kΩ typ. (+15V to -15V)
Table 4: RS 232 C Drivers compatible with RS232C standard)
High Level Output +5V min. +15V max.
Low Level Output -15V min. -5V max.
Short Circuit Current ± 100mA
Power off Impedance 300Ω
Slew Rate RL=3K CL=50pF 30V/µs
Table 5: RS422 Receivers compatible with RS422 standard)
Input resistance common mode 15kΩ typ. (-7 to +12V)
Receiver sensitivity ± 0.2V typ.
Common mode range -7.0V min. +7.0V max.
Table 6: RS422 Drivers compatible with RS422 standard)
Short Circuit Current 150mA
Transition Time 40ns max. (10-90%)
Output Current 28mA min. (RL=54Ω)
IE-UM-00170-002 UDR600-UDR765 User Manual.odt 10/22
