InstantPot Duo User manual
Getting Started Guide
Full manual and instruction videos available at www.instantpot.com.sg
Welcome
Initial Set-up
Cooker Parts Overview
Getting Started
Venting Methods
Initial Test Run (Water Test)
More Controls and Smart Programmes
Contact Information
DUOTM
Multi-Use Pressure Cooker
Getting Started GuideGetting Started Guide
www.instantpot.com.sgwww.instantpot.com.sg
Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 1Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 1 2020-06-30 2:12 PM2020-06-30 2:12 PM
Welcome to the world of Instant cooking.
Hello! Thank you for welcoming us into your kitchen.
Having families ourselves, we developed the Instant Pot™DUO™to allow busy families and
professionals alike to cook healthy, delicious meals more easily and in less time.
We have partnered with chefs, authors and bloggers to compile a collection of recipes that
we hope you enjoy!
Happy Cooking!
Robert J. Wang
Founder and Chief Innovation Ofcer
Download Free App:
Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 2Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 2 2020-06-30 2:12 PM2020-06-30 2:12 PM
1
Initial Set-up
• Remove all packaging material from in and around the
cooker,and verify that all parts are accounted for.
• Use only the Instant Pot DUO lid with the Instant Pot DUO
cooker base when pressure cooking. Using any other pressure
cooking lids may cause damage and/or injury.
• Read all Important Safeguards in the included Safety,
Maintenance and Warranty booklet before use. Failure to do
so may result in property damage and/or personal injury.
• Place the cooker on a stable, level surface, away from
externalheat sources.
• Follow the Care and Cleaning instructions in the included
Safety,Maintenance and Warranty booklet to wash the cooker
before cooking.
• Do not remove safety warning stickers from lid, serial number
from bottom, or rating label from back of cooker base.
CAUTION Never use the cooker on a hob. Do not place appliance on or in close
proximity to a hot gas or electric burner, or a heated oven; heat from
an external source will damage the appliance.
Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 1Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 1 2020-06-30 2:12 PM2020-06-30 2:12 PM
2 |
Cooker Parts Overview
Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 2Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 2 2020-06-30 2:12 PM2020-06-30 2:12 PM
Open
Close
Cooker Parts Overview | 3
Cooker Parts Overview
Top of Lid
Bottom of Lid
Inner Pot
Cooker Base
Images are for reference only. Refer to actual product.
Open
Close
Steam Release Valve
Float Valve
Lid Fins
Locking Pin
Anti-Block Shield
Silicone Cap
(bottom of fl oat valve)
Lid Position Marker
Steam Release Pipe
(beneath Anti-Block Shield)
Sealing Ring Rack
Sealing Ring
Condensation Rim
Cooker Handles
Outer Pot
Heating Element
Base Power Socket
Handle
Control Panel
Stainless Steel Exterior
Stainless Steel Inner Pot
Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 3Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 3 2020-06-30 2:12 PM2020-06-30 2:12 PM
Getting Started
Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 4Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 4 2020-06-30 2:12 PM2020-06-30 2:12 PM
Getting Started | 5
1Open and Close Lid
When cooker is plugged in, it will play a jingle when the lid is opened and closed.
Open Close
Open: Grip handle and turn lid anti-clockwise
until symbol on lid is aligned with
symbol on rim of cooker base. Lift lid up and
off cooker base.
Close: Grip handle and align the symbol
on lid with on rim of cooker base.
Lower lid into track, then turn lid clockwise
until symbol on lid lines up
with indicator on base.
*Note: Always check lid for damage prior to cooking.
OpenClose
Open
Close
Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 5Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 5 2020-06-30 2:12 PM2020-06-30 2:12 PM
6 | Getting Started
2Check Sealing Ring and Sealing Ring Rack
Remove: Pull sealing ring out from behind sealing ring rack.
Inspect sealing ring rack. It should be centred in the lid and an
even height all the way around.
Sealing ring must be installed before use.
Install: Place sealing ring over sealing ring rack and press into
place. Ensure entire sealing ring is snug behind sealing ring rack.
After closing the lid, the sealing ring creates an airtight seal
between lid and cooker base.
The sealing ring is an integral part of product safety. Replace your sealing ring every 12-18
months or when deformation or damage is noticed.
Remove
Install
Incorrect
CAUTION Always check for cuts or deformations in sealing ring prior to cooking. Only
use authorised Instant Pot sealing rings. Failure to follow these instructions
may cause food to discharge, which may lead to personal injury or property
damage.
CAUTION Sealing rings may stretch over time. Do not use a stretched or damaged
sealing ring. If puckering occurs, replace sealing ring.
Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 6Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 6 2020-06-30 2:12 PM2020-06-30 2:12 PM
Getting Started | 7
3Remove and Install Float Valve
The oat valve has 2 positions. It pops up to indicate
when the cooker is pressurised, and lowers into the
lid when the cooker is depressurised.
Refer to “Venting Methods” section in this Guide for information on
releasing pressure.
Remove: Place one nger on at top of oat valve.
Turn lid over. Detach silicone cap from bottom side
of oat valve. Remove oat valve from top of lid. Do
not discard oat valve or silicone cap.
The oat valve and silicone cap must be installed
before use to seal in pressurised steam.
Install: Drop oat valve into oat valve hole on top
of lid. Place one nger on the at top of oat valve.
Turn lid over. Attach silicone cap to bottom of
oatvalve.
Depressurised
Top Bottom
Pressurised
CAUTION While oat valve is up, contents of cooker are pressurised. Do not touch the oat valve while the cooker is
pressurised. Do not attempt to remove the lid while the cooker is pressurised.
Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 7Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 7 2020-06-30 2:12 PM2020-06-30 2:12 PM
8 |
| Getting Started
4Remove and Install Anti-Block Shield
Remove: Grip lid and press rmly against side of anti-block shield (pressing towards side of lid and
up) until it pops off the prongs underneath.
Anti-block shield must be installed before use and cleaned frequently.
Install: Place anti-block shield over prongs and press down until it snaps into position.
Anti-block shield prevents food particles from coming up through the steam release pipe, assisting
with pressure regulation.
Remove Install
Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 8Duo 60-SS_GSG-ENGLISH-Singapore_2020-06-30.indd 8 2020-06-30 2:12 PM2020-06-30 2:12 PM
