iLive IAT60 User manual
LED Light Strip
User’s Guide for Model IAT60 v2413-01
Back of TV or Monitor
Fold at corners as shown.
Features
• Length: 6.5 ft/2M
• Width: .4 in/10mm
• 32 LEDs total (5050 RGB LED)
• 5V USB power input
• Self adhesive, double sided backing
Includes
• USB cable with built-in remote receiver
• Remote control with CR 2025 battery included
Installation
1. Clean the surface to which you’re going to attach the light strip. The example shown below represents the
back of a TV or computer monitor.
2. Peel the backing strip o the adhesive tape on the LED strip.
3. Press and hold the LED strip to the surface.
4. Connect the USB cable to a USB port on the TV or monitor, or a USB power adapter (not Included).
5. Use the remote to change LED color, brightness, and ash settings.
• The remote receiver does not need to be visible or have direct line of sight with the remote, and can be
fully hidden behind your TV, monitor, etc.
• You may cut the strip to t smaller areas. Using scissors, cut on the visible line between LEDs.
Connect USB plug
to an available USB
outlet or a USB power
adapter (not included)
The remote receiver is built
into the USB power cable.
Remote Control
Remote Battery
Power ON/OFFBrightness Adjustment Up/Down
Color Selection
Press to select dierent colors.
R
Press for red lights only.
G
Press for green lights only.
B
Press for blue lights only.
W
Press for white lights only.
Flash 3
The LEDs will quickly change
between 3 colors.
Slow
The LEDs will slowly change
between 3 colors.
Fade
The LEDs will slowly change
between 7 colors.
Flash 7
The LEDs will quickly change
between 7 colors.
Customer Support
Customer Service: 1-888-999-4215 | Email Support: prodinfo@
For Warranty Information and the most up-to-date version of
this User’s Guide, go to www.iLiveElectronics.com
To download this User’s Guide in English, Spanish, or French, or
to get answers to frequently asked questions, visit the support
section at: www.iLiveElectronics.com
Para descargar este Manual del Usuario en inglés, español y
francés, o para obtener respuestas a preguntas frecuentes,
visite la sección de apoyo en: www.iLiveElectronics.com
Pour télécharger ce guide de l’utilisateur en anglais, espagnol
ou français, ou pour obtenir des réponses à des questions
fréquemment posées, consultez la rubrique d’assistance sur:
www.iLiveElectronics.com
Copyright © 2019 Digital Products
International (DPI, Inc.) All other trademarks
appearing herein are the property of their
respective owners. Specications are subject
to change without notice.
Safety Warnings
• WARNING: To prevent re or shock hazards, do not expose this
unit to rain or moisture.
• WARNING : Where the mains plug or appliance coupler is used
as the disconnect device, such disconnect device shall remain
readily operable.
• Only use with the included power supply or a UL/ETL certied
power supply of the same specications.
WARNING: This product can expose you to chemicals
including lead, which is known to the State of California to
cause cancer and birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov.
This product meets and complies with all Federal
regulations.
Made
Green
