IKEA KULINARISK User manual
KULINARISK
AU
ENGLISH
Please refer to the chapter IKEA GUARANTEE for contact details of
the after sales customer service centre.
ENGLISH 4
Contents
Safety information 4
Conditions of Use 5
Safety instructions 6
Installation 8
Product description 9
Control panel 9
Before first use 11
Daily use 12
Clock functions 16
Automatic programmes 17
Using the accessories 18
Additional functions 20
Hints and tips 21
Care and cleaning 23
Troubleshooting 26
Technical data 27
Energy efficiency 28
Environmental concerns 29
IKEA guarantee 29
Subject to change without notice.
Safety information
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible if
an incorrect installation and use causes injuries and damages.
Always keep the instructions with the appliance for future
reference.
Children and vulnerable people safety
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
•Children between 3 and 8 years of age and persons with
very extensive and complex disabilities shall be kept away
unless continuously supervised.
•Children of less than 3 years of age should be kept away
unless continuously supervised.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of it
appropriately.
ENGLISH 4
•Keep children and pets away from the appliance when it
operates or when it cools down. Accessible parts are hot.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user maintenance of
the appliance without supervision.
General Safety
•Only a qualified person must install this appliance and
replace the cable.
•WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements.
•Always use oven gloves to remove or put in accessories or
ovenware.
•Before maintenance cut the power supply.
•Ensure that the appliance is switched off before replacing the
lamp to avoid the possibility of electric shock.
•Do not use a steam cleaner to clean the appliance.
•Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the glass door since they can scratch the surface,
which may result in shattering of the glass.
•If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service Centre
or similarly qualified persons to avoid an electrical hazard.
•To remove the shelf supports first pull the front of the shelf
support and then the rear end away from the side walls.
Install the shelf supports in the opposite sequence.
•Use only the food sensor (core temperature sensor)
recommended for this appliance.
Conditions of Use
This appliance is intended to be used in
household and similar applications such as:
• Farm houses
ENGLISH 5
• By clients in serviced apartments, holiday
apartments and other residential type
environments.
Safety instructions
Installation
Warning! Only a qualified
person must install this
appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not pull the appliance by the handle.
• Keep the minimum distance from other
appliances and units.
• Install the appliance in a safe and
suitable place that meets installation
requirements.
Electrical connection
Warning! Risk of fire and electric
shock.
• All electrical connections should be made
by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable.
Should the mains cable need to be
replaced, this must be carried out by our
Authorised Service Centre.
• Do not let mains cables touch or come
near the appliance door, especially
when the door is hot.
• The shock protection of live and
insulated parts must be fastened in such
a way that it cannot be removed without
tools.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains
plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you disconnect
the appliance from the mains at all poles.
The isolation device must have a contact
opening width of minimum 3 mm.
Use
Warning! Risk of injury, burns
and electric shock or explosion.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay unattended
during operation.
• Deactivate the appliance after each use.
• Be careful when you open the appliance
door while the appliance is in operation.
Hot air can release.
ENGLISH 6
• Do not operate the appliance with wet
hands or when it has contact with water.
• Do not apply pressure on the open door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully. The
use of ingredients with alcohol can cause
a mixture of alcohol and air.
• Do not let sparks or open flames to come
in contact with the appliance when you
open the door.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
Warning! Risk of damage to the
appliance.
• To prevent damage or discoloration to
the enamel:
– do not put ovenware or other objects
in the appliance directly on the
bottom.
– do not put aluminium foil directly on
the bottom of cavity of the
appliance.
– do not put water directly into the hot
appliance.
– do not keep moist dishes and food in
the appliance after you finish the
cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel or stainless
steel has no effect on the performance of
the appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• This appliance is for cooking purposes
only. It must not be used for other
purposes, for example room heating.
• Always cook with the oven door closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make sure
the door is never closed when the
appliance is in operation. Heat and
moisture can build up behind a closed
furniture panel and cause subsequent
damage to the appliance, the housing
unit or the floor. Do not close the
furniture panel until the appliance has
cooled down completely after use.
Steam Cooking
Warning! Risk of burns and
damage to the appliance.
• Released Steam can cause burns:
– Do not open the appliance door
during the steam cooking operation.
– Open the appliance door with care
after the steam cooking operation.
Care and Cleaning
Warning! Risk of injury, fire, or
damage to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains plug
from the mains socket.
• Make sure the appliance is cold. There is
a risk that the glass panels can break.
• Replace immediately the door glass
panels when they are damaged. Contact
the Authorised Service Centre.
• Be careful when you remove the door
from the appliance. The door is heavy!
• Clean regularly the appliance to prevent
the deterioration of the surface material.
• Fat and food remaining in the appliance
can cause fire.
• If you use an oven spray, obey the safety
instructions on the packaging.
Internal lighting
Warning! Risk of electric shock.
• The type of light bulb or halogen lamp
used for this appliance is for household
appliances only. Do not use it for house
lighting.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same
specifications.
ENGLISH 7
Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
Disposal
Warning! Risk of injury or
suffocation.
• Disconnect the appliance from the mains
supply.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
• Remove the door to prevent children and
pets to get closed in the appliance.
•Packaging material:
The packaging material is recyclable.
Plastic parts are marked with
international abbreviations such as PE,
PS, etc. Dispose of the packaging
material in the containers provided for
this purpose at your local waste
management facility.
Installation
Warning! Refer to Safety
chapters.
Assembly
Refer to the Assembly Instructions
for the installation.
Electrical installation
Warning! Only a qualified
person must do the electrical
installation.
The manufacturer is not
responsible if you do not follow
the safety precautions from the
Safety chapters.
This oven is only supplied with a main
cable.
Cable
Cable types applicable for installation or
replacement:
H07 RN-F, H05 RN-F, H05 RRF, H05 VV-F,
H05 V2V2-F (T90), H05 BB-F
For the section of the cable refer to the total
power on the rating plate. You can also
refer to the table:
Total power (W) Section of the cable
(mm²)
maximum 1380 3 x 0.75
maximum 2300 3 x 1
maximum 3680 3 x 1.5
The earth cord (green / yellow cable) must
be 2 cm longer than phase and neutral
cables (blue and brown cables).
ENGLISH 8
Product description
General overview
1 2
5
4
6
10
11
1
2
3
4
3
9
8
7
1Control panel
2Electronic programmer
3Water drawer
4Socket for the core temperature sensor
5Grill
6Lamp
7Rating plate
8Fan
9Steam generator with cover
10 Shelf support, removable
11 Shelf positions
Accessories
•Wire shelf x 1
For cookware, cake tins, roasts.
•Baking tray x 1
For cakes and biscuits.
•Core temperature sensor x 1
To measure how far the food is cooked.
•Sponge x 1
For absorbing the remaining water from
the steam generator.
Warning! Remove the sponge
from the cavity before
cooking. Do not use the
sponge when the appliance is
hot.
Control panel
Electronic programmer
1 112 4 63 9 105 7 8
Symbol Function Comment
1ON / OFF To turn on and off the oven.
ENGLISH 9
Symbol Function Comment
2
Heating Functions
or Assisted Cook-
ing
Press once to enter to the Heating Functions Menu.
Press again to switch to Assisted Cooking. To turn
on or off the light, press for 3 seconds.
3Back key To go back one level in the menu. To show the
main menu, press the symbol for 3 seconds.
4Temperature se-
lection
To set the temperature or show the current tem-
perature in the oven.
5Favourites To save and access your favourite programmes.
6- Display Shows the current settings of the oven.
7Up key To move up in the menu.
8Down key To move down in the menu.
9
Time and addi-
tional functions
To set different functions. When a heating function
operates, press the symbol to set the timer or the
functions: Function Lock, Favourites, Heat + Hold,
Set + Go. You can also change the settings of the
core temperature sensor.
10 Minute Minder To set the function: Minute Minder.
11 OK To confirm the selection or setting.
Display
A
DE
B C
A. Heating function
B. Time of day
C. Heat-up indicator
D. Temperature
E. Duration time or end time of a function
ENGLISH 10
Other manuals for KULINARISK
44
This manual suits for next models
2
Table of contents
Other IKEA Oven manuals
IKEA
IKEA OV10 User manual
IKEA
IKEA KULINARISK 704.210.59 User manual
IKEA
IKEA KULINARISK User manual
IKEA
IKEA SMAKSAK User manual
IKEA
IKEA Forneby User manual
IKEA
IKEA VALFRI User manual
IKEA
IKEA SMAKSAK User manual
IKEA
IKEA KULINARISK User manual
IKEA
IKEA MIRAKULOS User manual
IKEA
IKEA KULINARISK 203.008.75 User manual
IKEA
IKEA GÖRLIG User manual
IKEA
IKEA KULINARISK User manual
IKEA
IKEA GÖRLIG User manual
IKEA
IKEA ANRATTA 604.117.20 User manual
IKEA
IKEA FINSMAKARE User manual
IKEA
IKEA NUTID OV 9 User manual
IKEA
IKEA 704.168.21 User manual
IKEA
IKEA Forneby User manual
IKEA
IKEA BRÄNDBO User manual
IKEA
IKEA FINSMAKARE User manual
