iFootage HL1 C4 User manual
HL1 C4 RGBW
Handy Light User Manual
3DK1455001
Thank you for purchasing this iFootage product. This manual provides
important user information for the Anglersh HL1 C4 Handy Light. Please read
the manual carefully before operating the equipment and keep the manual
safe for future reference.
The Anglersh HL1 C4 is a portable, exible,RGBW handy light and features
colour temperature, HSI, special eects and multi-light control. It's the perfect
light for Smartphone recording, interior and exterior video recording, vlogging,
Youtube presenting, wedding and event photography and much more.
CONTENTS
FEATURES 1
PRECAUTIONS 2
COMPONENT DESCRIPTION 3
USER GUIDE 4
APP OVERVIEW 13
BLUETOOTH INTRODUCTION 12
MODE SELECTION 8
LIST OF ITEMS 15
PRODUCT PARAMETERS 15
NOTES 16
MAINTENANCE 17
1
1. The colour temperature range is 2700K~10000K. A CRI RA value of 95 is
achieved when the colour temperature range is between 2700K and 7500K.
2. A customized TIR lens improves LED energy consumption.
3. The rotating lights ensure more realistic shadows.
4. Quickly move between spot light and soft light functions.
5. The rear of the handy light is magnetic allowing the light to be attached to
metal surfaces.
6. The Handy Light is convenient, compact and portable - small enough to t in
your pocket.
7. The light has CCT, HSI, numerous special eects options and can be controlled
using the Lumix APP via Bluetooth to access RGBW, colour co-ordinates XY,
paper colour GEL, keyframes and multi-light control modes.
8 Built-in SOS light signal.
9. Low battery prompt: Battery display ashes to provide low battery warning.
Battery level is constantly shown on the display.
10. Overheat protection: if the product is in use or charging and the temperature
is too high - the 'Overheat Warning' will appear.
FEATURES
2
PRECAUTIONS
1. Do not expose to water or other liquids. This product is not dustproof or
waterproof.
2. Please ensure that you do not apply pressure to the OLED screen as this may
result in permanent screen damage.
3. Do not look directly into the LED bead lights as this may impair vision.
4. When the product is not in use for an extended period of time, it is recom-
mended that it should be discharged and recharged to a minimum of 60%
power in order to preserve the life of the battery.
5. This product's battery contains potentially harmful materials and needs to be
disposed of appropriately. Please follow your local waste management guide-
lines when recycling or disposing of the battery.
1
2
3
4
5
6
78
9
1Display
2On/Off Power Button
3Type-C Charging Port
4SET Button
5Back Cover
71/4”Thread
6Soft cover (detachable)
8“＋”Key / Previous
9“－”Key / Next
3
COMPONENT DESCRIPTION
4
Functions: User operation instructions
Key features
USER GUIDE
1. To turn on the HL1 C4, press and hold the power button for 3 seconds, then
release the power button when the screen lights up.
2. To turn o the HL1 C4, press and hold the power button for 3 seconds, then
release the power button when the screen turns o.
3. To temporarily switch the light o, press once and press again to switch the light
back on.
1. Press and hold the SET button to select an operational mode. Press again to
select the chosen mode.
2. Press the SET button to select the parameter.
On/O Power Button
SET Button
Type-C Charging Port
“＋”Key / Previous
“- ”Key / Next
On/O Power Button
SET Button
Type-C Charging Port
Power input connector. Input voltage 5V, current 1A.
5
USER GUIDE
“ ＋” Key / Previous,“ －”Key / Next
1. The value of the corresponding parameter is adjusted.
2. Use "+" and "- " to adjust parameters.
The main display interface shows colour temperature, HSI, special eects,
Bluetooth reset, and additional settings (colour temperature, HSI, eects,
green/ magenta, saturation and brightness are all adjustable).
Display
Example: Automatic switching between
battery life time and device ID
code
Main Interface Colour parameter
interface
Colour parameter interface
Bluetooth
Connection
Indicator
Power Level
Indicator (Low
Power Flashing)
Colour temperature
6
Soft Cover
When the soft cover is removed the light will create a spot light eect. With the
soft cover attached the light will create a soft light or diused eect.
Once removed, the soft cover can be safely housed on the back case.
USER GUIDE
For diused lighting please use the soft cover
For a spot light eect, please remove the soft cover
7
1/4”thread
The base of the light has a 1/4" thread designed for attaching to most accessories.
Built-in magnets in the back case
USER GUIDE
Magnets have been located in the back casing so that the lights can be
securely attached to metal objects.
Metal shelving
For example:
8
CCT Mode
When CCT mode is selected:
Use the "+,-" button ->
to adjust parameter value
Press the SET
button to
select
The adjustable parameters within colour temperature mode are: colour
temperature range of 2700K ~ 10000K. Brightness range of 0% ~ 100% and a
green/magenta range of -1 ~ +1.
Press and hold the SET button -> Press the SET
button to select the parameters -> Select special
eects mode using "+,-"
Mode Selection
Press to switch
On/Off
