iCoo iGuard 35 User manual
• This child restraint is certified for use in motor vehicles and
aircraft.
• Please read all instructions in this manual and on product labels
before use.
• Keep instructions for future use. Store instructions on back of
carrier or in base.
i
• Failure to follow these instructions and product labels can
result in serious injury or death in a crash.
• Read all instructions before use of the infant carrier.
WARNING
Instructions for use
EN
EN
3
TABLE OF CONTENTS
USE RECCOMMENDATIONS 7
REGISTRATION 8
WARNING + GENERAL SAFETY
INFORMATION 9
OVERVIEW OF BASE 15
OVERVIEW OF INFANT CARRIER 17
CHOOSING A VEHICLE
SEATING LOCATION 20
DETERMINING THE BEST
INSTALLATION METHOD 22
OVERVIEW OF LATCH 24
OVERVIEW OF VEHICLE SEAT
BELT SYSTEMS 26
UNSAFE VEHICLE SEAT BELT
SYSTEMS + SEATING 28
BASE INSTALLATION WITH LATCH 29
PROPER INSTALLATION - LATCH 33
EN
4
TABLE OF CONTENTS
REMOVING BASE FROM
VEHICLE - LATCH 34
BASE INSTALLATION WITH
VEHICLE SEAT BELT 36
SECURING THE BASE WITH
VEHICLE SEAT BELT 39
SECURING THE BASE WITH
VEHICLE LAP/SHOULDER BELT 39
SECURING THE BASE WITH
VEHICLE LAP BELT ONLY 42
PROPER INSTALLATION - VEHICLE
SEAT BELT 45
REMOVING BASE FROM THE
VEHICLE - VEHICLE SEAT BELT 46
ATTACHING THE INFANT
CARRIER TO THE BASE 47
RELEASING THE INFANT CARRIER
FROM BASE 48
CARRIER INSTALLATION WITHOUT
BASE 49
EN
5
CARRIER INSTALLATION WITH
VEHICLE LAP/SHOULDER BELT 51
INSTALLATION WITH LOCKING CLIP 54
CARRIER INSTALLATION WITH
VEHICLE LAP BELT ONLY 55
CHECK FOR PROPER INSTALLATION
- CARRIER WITHOUT BASE 57
AIRCRAFT INSTALLATION 58
INFANT INSERT 60
CROTCH STRAP POSITIONING 59
SHOULDER STRAP HEIGHT
ADJUSTMENT 63
SECURING YOUR CHILD 68
PINCH TEST 72
CARRY HANDLE ADJUSTMENT 73
TUCK AWAY CANOPY 74
IMPORTANT CHECKS 76
ATTACHING TO A STROLLER 78
TABLE OF CONTENTS
EN
6
RELEASING FROM A STROLLER 80
SEAT PAD REMOVAL INFORMATION 81
SEAT PAD INSTALLATION INFORMATION 82
CLEANING 83
IMPORTANT INFORMATION/
WARRANTY 84
CUSTOMER SERVICE 86
TABLE OF CONTENTS
EN
7
Children should remain rear-facing for as long as
possible within the maximum weight and height
limits for the car seat. Discontinue use of this
child restraint when either the child‘s weight or
height exceeds the specied limits below.
This child restraint is for use by children who
meet BOTH requirements below:
WEIGHT REQUIREMENTS:
4-35 lbs (1.8 - 15.9 kg)
Infant Insert is required for use with smaller
infants weighing 4 - 11 lbs (1.8 - 5.0 kg).
HEIGHT REQUIREMENTS:
32 inches (81.3 cm) or less.
The top of the child’s
head should not be less
than 1 inch from the top
of the seat back.
Shoulder straps must be
through the shoulder strap
slots at or just below the top of
the child‘s shoulders.
Chest clip must be at
armpit level and shoulder
straps should be snugly
adjusted around the child.
USE RECOMMENDATIONS
X
EN
8
REGISTER YOUR CAR SEAT
Child restraints could be recalled for safety
reasons. You must register this restraint to be
reached in a recall. Send your name, address,
email address if available, and the restraint’s
model number and manufacturing date to:
iCoo GmbH, 212A Wilkinson Road, Brampton,
Ontario L6T 4M4
or call 1-877-428-2545 or register online at
www.iguard35.com/register.
For recall information, call the U.S. Government’s
Vehicle Safety Hotline at 1–888–327–4236
(TTY: 1–800–424–9153)
, or go to
http://www.NHTSA.gov.
NOTICE OF EXPIRATION
Discontinue use of this child restraint after
7 years from the date of manufacture or after a
crash. For date of manufacture, refer to labels on
bottom of Carrier and Base.
Serial Number:
Date of Purchase:
Model Number:
Model Name:
Date of Manufacture:
REGISTRATION
EN
9
WARNING
DEATH OR SERIOUS INJURY CAN OCCUR
• Failure to follow the warnings and informa-
tion in these instructions and on product
labels could result in serious injury to your
child or other vehicle occupants.
• According to accident statistics, children
are safer when properly restrained in the
rear vehicle seating positions than in the
front seating positions.
• Child restraint systems should be securely
belted to the vehicle, even when they are
not occupied, since in a crash an unse-
cured child restraint system may injure
other occupants.
• Use only in rear-facing position when
using it in the vehicle.
WARNING
DO NOT place rear-facing
child seat on front seat with
an active frontal airbag.
DEATH OR SERIOUS
INJURY can occur.
The back seat is the safest
place for children 12 and
under.
WARNING + GENERAL SAFETY INFORMATION
EN
10
WARNING
• NEVER place this child restraint on a front
seat with an active frontal AIRBAG. An air-
bag can strike a rear-facing infant restraint
with enough force to crack the shell and
seriously injure or kill an infant. Refer to
the vehicle owner’s manual before instal-
ling this child restraint in a seating position
with side airbags.
• Snugly adjust the belts provided with this
child restraint around your child.
• Use only with children who weigh between
4 and 35 lbs (1.8 -15.9 kg) and whose
height is 32 inches (81.3 cm) or less.
• Infant insert must be used with infants 11
lbs. (5.0 kg) or less.
• Secure this child restraint with the
vehicle‘s child restraint anchorage system
(LATCH) if available or with a vehicle seat
belt.
• SUFFOCATION HAZARD: Infant carrier
can roll over on soft surfaces and suffo-
cate child. NEVER place carrier on beds,
sofas, or other soft surfaces.
WARNING + GENERAL SAFETY INFORMATION
