Iceco JP Series User manual
JP30/40/50
If there are any problems, please email us:
official@icecofreezer.com
Catalogue
Catalogue
1 1
-----------------------
What's Inside
2 2
---------------------------
Operation
3 5
--------------
Care And Maintenance
4 6
- - - - - - - - - - - -
Error Codes & Solutions
5 8
- - - - - - - - - - -
Warranty & Return Policy
6 9
- - - - - - - - - - - -
Troubleshooting (Q & A)
7 14
- - - - - - - - - - - - - - - -
Safety Instructions
What's Inside
Refrigerator x1 Insulated Protective
Cover x1
12/24V DC Cigarette
Lighter Plug Cable x1
12 Feet Cigarette
Extension Cable x1
01
1
110V AC Wall
Outlet Cable x1 Wired Basket x1
Operation
2
APower (Press & Hold to turn on/off)
BCompressor Speed
(MAX/ECO Mode)
CTemp. Setting DOWN
DTemp. Setting UP
02
2.1 MAX & ECO Mode
With the unit turned on (Press & Hold A / Power
Button), you can press the MAX/ECO Button B
to toggle between MAX or ECO compressor
speed for the fridge.
03
2.2 Switch Between °C to °F
With the unit turned on, press and hold C & D
switch between Celsius & Fahrenheit
04
2.4 Triple Battery Protection Operation
Push the triple battery protection button up and
down to adjust the HIGH, MED or LOW gear.
NOTE: Details of Battery Protection Mode could
be found in Page 11.
05
Care And Maintenance
3
3.1 Cleaning
Please use a wet cloth and warm water mixed
with gentle non-abrasive detergents to clean
the interior and exterior of your fridge.
3.2 DOs and DON'Ts
Please power off and unplug the unit before
cleaning
Please use non-abrasive detergent to
cleaning the interior/exterior of the fridge
Please don't scrap the interior of the fridge to
defrost/de-ice the fridge
Please don't pressure-wash/spray the fridge
with a running water hose
06
Error Codes & Solutions
4
Error Code
※ The cooling fan overloads with more
than 1 A of current.
E2
Motor start error
※ The motor of compressor is blocked or
the pressure difference in the refrigeration
system is too high.
E3
Minimum motor speed error
※ The compressor overloads and the
motor can not maintain its minimun speed
1850 rpms.
E4
Thermal cut-out of electronic unit
※ Thermal cut-out error If the refrigeration
system overloads, or the ambient
temperature is too high, the thermal sensor
is overheated.
E5
※ The DC voltage is below the protection
setting and the battery protection mode is
activated.
E1
07
Solutions
If this error code appears when the fridge is
operating on 12V DC, please try to lower the
battery protection setting and see if the error
is resolved. The battery protection mode may
be triggered prematurely on certain vehicles
due to small wiring imperfections, contributing
to a measured DC voltage drop at compressor
start-up. Lowering the battery protection
setting may resolve this issue.
Please also try to take a voltage reading of your
battery to make sure it is not
depleted/discharged.
If possible, please connect the AC power cord to
try if the refrigerator appears E1 code.
Please contact us directly if the error persists.
