8 ICE i20NBL / i20NBTL / i20NBTL-OB / i24BTL
OPERATOR MANUAL
FILLING THE SOLUTION TANK
machine components, item #18) at the rear of
components, item #7)located under the recovery
sure that the recovery tank is empty.
Fill the solution tank to the "60L" level on the
solution tank sight gauge. When using the bucket
NOTE:
materials into solution tank. this can cause an
cleaning chemicals. Contact your janitorial
supply distributor for recommendations on
proper chemicals.
WARNING: Do not operate machine
unless you have read and understand this
manual.
1.
lowering the squeegee lift lever(see machine
components, item #33).
2.
on the scrub head lift pedal(see machine
components, item #26).
3. Swiping the ID card (see machine components,
item #3) to turn on the machine.
4. Check the battery meter (see Panel
components, item #2), if the battery is very low,
there will be a Fault code & message on the
LED display screen(see Fault code section),
and the Fault indicator will blink continuously
accompany an audible alarm. please DO NOT
continue to operate the machine and recharge
the batteries immediately.
5.
control button (see Panel components, item #6,
the control handle bail is pulled.
6. Turn on the vacuum motor switch(see Panel
components, item #10).
7. i20NBL: Pull the control handle bail(see
machine components, item #2) backwards to
start scrubbing by moving the machine forward.
The drive model i20NBTL / i24BTL: Pull the
control handle bail(see machine components,
item #2) backwards to start scrubbing. The
machine will automatically propel forward.
To reverse the drive model, simply push the
control handle bail forward. the speed can be
adjusted, Adjust the speed control button (see
Panel components, item #13, 15) to a desired
scrubbing speed.
NOTE:
8. When more brush pressure is needed for heavily
soiled areas simply lift the down pressure
lever(see machine components, item #25).
9. To stop scrubbing, release the control handle
bail, raise the scrub head and the squeegee
assembly.
WARNING: Fire Or Explosion Hazard. Do
Not Pick Up Flammable Materials Or Reactive
Metals.
1. Go slow on inclines and slippery surfaces. Do
not operate the machine on inclines that exceed
5% (3°).
2. Do not keep the machine in the same position
with pad / brush spinning, keep the machine
3. If the squeegee assembly leaves streaks on the
the blades down with a damp cloth. Pre-sweep
4. Pour a recommended defoamer into the
recovery tank if excessive foam appears.
WARNING: Do not allow foam to enter
damage will result. Foam will not activate the
5. Occasionally check the battery meter(see Panel
components, item #2). when the bettery is very
low, stop scrubbing and recharge the batteries.
WARNING: When battery is very low, do
not continue to operate the machine. Battery
damage may result.
6. When the solution tank runs empty, raise the
down and continue to vacuum until all the dirty
water is picked up.
NOTE: See TANK DRAINING
MACHINE OPERATION
WHILE OPERATING MACHINE
