IBM ThinkPad i Series User manual

Get user manuals: See SafeManuals.com

Note: Before using this information and the product it supports, be sure to read the general information under

“Safety information” on page vii, and “Notices” on page 134. For ergonomics information, see the

Online

User's Guide

First Edition (March 2000)

The following paragraph does not apply to the United Kingdom or any country where such provisions are

inconsistent with local law:

INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS PUBLICATION "AS IS" WITHOUT ANY

WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE LIMITED

WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow

disclaimers or express or implied warranties in certain transactions; therefore, this statement may not apply to you.

This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the

information herein; these changes will be incorporated in new editions of the publication. IBM may make improvements

or changes in the products or the programs described in this publication at any time.

Requests for technical information about IBM products should be made to your IBM Authorized Dealer or your IBM

Marketing Representative.

Users — Documentation related to restricted rights — Use, duplication, or disclosure is subject to restrictions set forth

in GSA ADP Schedule Contract with IBM Corp.

Get user manuals: See SafeManuals.com

Thank you for choosing an IBM ThinkPad i Series 1200/1300

computer

We at IBM have developed this ThinkPad computer to meet both your technical requirements and your high expec-

tations. To help us continue to build products that address your mobile computing needs, please take a moment to

complete the ThinkPad Registration.

ThinkPad ThinkPad

 Copyright IBM Corporation 1999 iii

Get user manuals: See SafeManuals.com

Functional highlightsSlim and compact design with core technology The slim and

compact design of the ThinkPad i Series 1200/1300

brings ease-of-use and portability to your computing

needs.

High-speed processor The Intel high-speed processor enables

high-speed data processing and provides advanced per-

formance.

Large-capacity hard disk drive The large-capacity hard disk drive

can respond to a wide variety of your business demands.

Large color LCD The large TFT (thin-film transistor) or HPA (high

performance addressing) display provides clear and bril-

liant text and graphics.

Nickel metal hydride battery pack The large-capacity battery pack

extends the operating time of your computer, further

enhancing its portability.

Audio with 3D Stereo Sound Your computer is equipped with

internal audio record and playback capabilities including

3D audio from two speakers. When you enable the 3D

stereo feature, sounds will appear to be generated all

around you.

The audio feature supports the following:

Wave audio recording and playback of up to 16 bits,

stereo, and 48 KHz sampling.

Music CD playback.

For more information on using the audio function, see the

Online User's Guide

ThinkPad Modem The ThinkPad modem enables you to send or

receive data and faxes over a telephone line.

For more information on using the ThinkPad modem, see

the

Online User's Guide

Get user manuals: See SafeManuals.com

Functional highlights

TrackPoint with Enhanced Controls Your computer has an

enhanced TrackPoint function that enables you to make

selections merely by pressing on the TrackPoint. A new

center button, the Internet Scroll Bar, converts the

TrackPoint into a scroll controlling device or a magnifying

glass on the screen.

For more information on using the TrackPoint, see

“TrackPoint” on page 9.

PC Card Support Your computer provides a PC Card slot that

accepts a 16–bit PC Card, CardBus Card, or Zoomed

Video Card.

For more information on installing PC Cards, see

“Inserting a PC Card” on page 70.

Easy Launch buttons Your computer is equipped with four

customizable buttons that allow you to connect to the

Internet or to run programs at a single press of a button.

For more information on customizing the Easy Launch

buttons, see “Easy Launch buttons Customization Utility”

on page 33.

Get user manuals: See SafeManuals.com

About this book

About this book This book contains information that will help you operate the IBM

ThinkPad i Series 1200/1300 computer. Be sure to read the

ThinkPad i Series 1200/1300 Setup Guide

and Chapter 1 of this

book before using the computer.

Chapter 2. "Extending the

features of your computer,"

provides information on installing

options and using your computer's

high-technology features.

Chapter 3.

"Protecting your computer,"

provides information on using

passwords, and using locks.

Chapter 4. "Solving computer problems,"

Chapter 5. "Getting service,"

describes what to do when you have a

computer problem. The chapter includes a troubleshooting guide and information on

how to recover lost or damaged software.

describes various options of IBM's support and service.

Chapter 1. "Getting familiar with

your computer," acquaints you

with the basic features of your computer

Appendix A, Features and specifications describes the features

and specifications associated with your computer, including informa-

tion on power cords.

Appendix B, Product warranties and notices contains the war-

ranty statements for your computer and notices for this book.

The book concludes with an index.

Get user manuals: See SafeManuals.com

Safety information

Electrical safety notice

DANGER

Electrical current from power, telephone, and communi-

cation cables is hazardous. Reduce the risk of fire and

electric shock by always following basic safety precau-

tions, including the following:

Do not use your computer in or near water.

During electrical storms, do not connect the cable to

or disconnect it from the telephone outlet on the

wall.

To avoid shock hazard, connect and disconnect cables

as shown below when installing, moving, or opening the

covers of this product or attached devices. The 3–pin

power cord must be used with a properly grounded

outlet.

vii

Get user manuals: See SafeManuals.com

Safety information

DANGER

Do not disassemble, incinerate, or short-circuit the

rechargeable battery pack. Do not put it in trash that is

disposed of in landfills. Dispose of it as required by

local ordinances or regulations. In the United States, call

IBM at 1-800-IBM-4333 for information on disposal.

viii

Get user manuals: See SafeManuals.com

Safety information

DANGER

There is a danger of an explosion if the battery is incor-

rectly replaced.

The lithium battery (IBM P/N 02K6502 UL-recognized

component [file no. MH12210]) contains lithium and can

explode if it is not properly handled or disposed of.

Replace only with a battery of the same type.

Do not: (1) throw or immerse it into water, (2) allow it to

heat to more than 100°C (212°F), or (3) attempt to repair

or disassemble it. Dispose of it as required by local ordi-

nances or regulations.

CAUTION:

The fluorescent lamp in the liquid crystal display (LCD) contains

mercury. Do not put it in trash that is disposed of in landfills.

Dispose of it as required by local ordinances or regulations.

The LCD is made of glass, and rough handling or dropping the

computer can cause the LCD to break. If the LCD breaks and

the internal fluid gets into your eyes or on your hands, imme-

diately wash the affected areas with water for at least 15

minutes; then get medical care if any symptoms are present

after washing.

Laser compliance statement

The CD-ROM drive of the ThinkPad i Series 1200/1300 computer is

a laser product. The CD-ROM drive's classification label (shown

below) is located on the top of the drive.

CLASS 1 LASER PRODUCT

LASER KLASSE 1

LUOKAN 1 LASERLAITE

Get user manuals: See SafeManuals.com

Safety information

APPAREIL A LASER DE CLASSE 1

KLASS 1 LASER APPARAT

The CD-ROM drive is certified in the U.S. to conform to the require-

ments of the Department of Health and Human Services 21 Code of

Federal Regulations (DHHS 21 CFR) Subchapter J for Class 1 laser

products.

In other countries, the drive is certified to conform to the require-

ments of EN60825.

CAUTION:

Do not open the CD-ROM drive; no user adjustments or service-

able parts are inside.

Use of controls, adjustments, or the performance of procedures

other than those specified may result in hazardous radiation

exposure.

Class 1 laser products are not considered to be hazardous. The

CD-ROM drive has an internal, Class 1, 0.5-milliwatt, aluminum

gallium-arsenide laser that operates at a wavelength of 760 to 810

nanometers. The design of the laser system and the CD-ROM drive

ensures that there is no exposure to laser radiation above a Class 1

level during normal operation, user maintenance, or servicing condi-

tions.
