Ibanez AEQ-2UT Owner's manual
Preamp Information
AEQ-2UT
ENGLISH
1
➤➤
Basic Controls
VOLUME
Controls the overall gain of the Pre-Amp.
TREBLE
Controls the boost/cut of the treble frequencies.
BASS
Controls the boost/cut of the bass frequencies.
AEQ-2UT
Tuner functions
TUNER ON/OFF SWITCH
Pressing the volume knob will alternately turn the tuning meter on/off. The tuner will turn off automatically after 5
minutes.
A B C D E F G
NOTE INDICATER LED
TUNING GUIDE LED
the G indicator and the # indicator will light up. If the note
one you wish, try tightening or loosening the string until the correct LED lights up. Be careful not to tighten the
strings too much (over tune) as the strings may break. When in doubt, it is better to tune down and loosen the
on the left will light up. If the pitch of the string is sharp, the red LED on the right will light.
AEQ-2UT
ENGLISH
2
➤➤
Replace the batteries if you notice any of the following things.
• Decreased sound quality or volume
• The tuner does not respond when you turn it on
• The LEDs do not operate when you turn on the tuner
• The battery check LED is lit or blinking
To prevent the battery from being consumed needlessly, disconnect the plug from the output jack when you’re
not using the guitar.
※Dispose of used batteries in accordance with local regulations.
※
Notes
ENGLISH
