Hytera RD98XSU2 User manual

Preface

Thanks for your favor in our product. To derive optimum performance from the product. To ensure you get

maximum benefit from the product, please read this manual carefully before use.

This manual is applicable to the following model:

RD98XS U(2) (X may indicate 0, 2, 5, 6 or 8)

Instructional Icons

The following icons are available through this manual:

Caution: indicates situations that could cause damage to your product.

Note: indicates tips that can help you make better use of your product.

*: indicates functions available in later version.

Term Explanation

Duplexer

Duplexer is a device that allows bi-directional communication. Its role is to isolate the TX signal from the

RX signal to ensure that the transmitter and receiver can work normally.

Feed Line

Feed Line is the cable or transmission line that connects the antenna with the radio transmitter or

receiver.

Voltage Standing Wave Ratio (VSWR)

VSWR is a value that measures how well a load is impedance-matched to a source.

Squelch

Squelch is a circuit function that acts to suppress the audio output of a receiver in the absence of a

sufficiently strong desired input signal.

Hytera is the trademark or registered trademark of Hytera Communications Co., Ltd. (the Company) in

PRC and/or other countries or areas. The Company retains the ownership of its trademarks and product

names. All other trademarks and/or product names that may be used in this manual are properties of their

respective owners.

The product described in this manual may include the Company’s computer programs stored in memory

or other media. Laws in PRC and/or other countries or areas protect the exclusive rights of the Company

with respect to its computer programs. The purchase of this product shall not be deemed to grant, either

directly or by implication, any rights to the purchaser regarding the Company’s computer programs. Any of

the Company’s computer programs may not be copied, modified, distributed, decompiled, or

reverse-engineered in any manner without the prior written consent of the Company.

The AMBE+2TM voice coding technology embodied in this product is protected by intellectual property

rights including patent rights, copyrights and trade secrets of Digital Voice Systems, Inc. This voice coding

technology is licensed solely for use within this product. The user of this technology is explicitly prohibited

from attempting to decompile, reverse engineer, or disassemble the Object Code or in any other way

convert the Object Code into a human readable form.

U.S. Patent Nos. #6,912,495 B2, #6,199,037 B1, #5,870,405, #5,826,222, #5,754,974, #5,701,390,

#5,715,365, #5,649,050, #5,630,011, #5,581,656, #5,517,511, #5,491,772, #5,247,579, #5,226,084 and

#5,195,166.

Disclaimer

The Company endeavors to achieve the accuracy and completeness of this manual, but no warranty of

accuracy or reliability is given. All the specifications and designs are subject to change without notice due

to continuous technology development. No part of this manual may be copied, modified, translated, or

distributed in any manner without the express written permission of us.

If you have any suggestions or would like to learn more details, please visit our website at:

http://www.hytera.com/.

RF Radiation Information

RF Radiation Profile

Radio Frequency (RF) is a frequency of electromagnetic radiation in the range at which radio signals are

transmitted. RF technology is widely used in communication, medicine, food processing and other fields.

It may generate radiation during use.

RF Radiation Safety

In order to ensure user health, experts from relevant industries including science, engineering, medicine

and health work with international organizations to develop standards for safe exposure to RF radiation.

These standards consist of:

United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2

sub-part J;

American National Standards Institute (ANSI)/Institute of Electrical and Electronic Engineers (IEEE)

C95. 1-1992;

Institute of Electrical and Electronic Engineers (IEEE) C95. 1 – 1999;

International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998;

FCC Regulations

Federal Communication Commission (FCC) requires that all radio communication products

should meet the requirements set forth in the above standards before they can be marketed

in the U.S, and the manufacturer shall post a RF label on the product to inform users of

operational instructions, so as to enhance their occupational health against exposure to RF

energy.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired

operation.

Any Changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment.

Compliance with RF Exposure Standards

To control your exposure and ensure compliance with the occupational/controlled

environment exposure limits, this equipment should be operated with minimum distance

350cm between the radiator& your body.

Pour contrôler votre exposition et assurer le respect des valeurs limites d'exposition

professionnelles environnement / contrôlée, cet équipement doit être utilisé avec une

distance minimale de 350 cm entre le radiateur et votre corps.

Operational Instructions and Training Guidelines

To ensure optimal performance and compliance with the occupational/controlled

environment RF energy exposure limits in the above standards and guidelines, users should

always adhere to the followings:

Gain of antenna must not exceed 6.5dBi.

Antenna Installation: install the antenna at least 3.5 meters away from your body,

in accordance with the requirements of the antenna manufacturer/supplier.

EU Regulatory Conformance

As certified by the qualified laboratory, the product is in compliance with the essential requirements and

other relevant provisions of the Directive 1999/5/EC. Please note that the above information is applicable

to EU countries only.

IC Regulations

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is

subject to the following two conditions:

(1) this device may not cause interference, and

(2) this device must accept any interference, including interference that may cause

undesired operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils

radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :

(1) l'appareil nedoit pas produire de brouillage, et

(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le

brouillage est susceptible d'en compromettre le fonctionnement

This radio transmitter (identify the device by certification number, or model number if

Category II) has been approved by Industry Canada to operate with the antenna types listed

below with the maximum permissible gain and required antenna impedance for each

antenna type indicated. Antenna types not included in this list, having a gain greater than the

maximum gain indicated for that type, are strictly prohibited for use with this device.

Le présent émetteur radio (identifier le dispositif par son numéro de certification ou son

numéro de modèle s'il fait partie du matériel de catégorie I) a été approuvé par Industrie

Canada pourfonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain

admissible maximal et l'impédance requise pour chaque type d'antenne. Les types

'antenne non inclus dans cette liste,ou dont le gain est supérieur au gain maximal indiqué,

sont strictement interdits pour l'exploitation de l'émetteur.
