Husqvarna 340iBT User manual
340iBT
EN Operator's manual 2-21
Contents
Introduction..................................................................... 2
Safety..............................................................................3
Assembly...................................................................... 13
Operation...................................................................... 15
Maintenance................................................................. 17
Troubleshooting............................................................ 18
Transportation, storage and disposal........................... 18
Technical data.............................................................. 18
Accessories.................................................................. 20
EC Declaration of Conformity....................................... 21
Introduction
Product overview
5
3
4
7
2
10
6
9
8
1
1. Backpack harness
2. Display
3. Cruise control: Set the optimal air flow for your work
4. Start/stop button
5. Boost mode: Increase of airflow
6. Blower nozzle
7. Power trigger
8. Handle
9. Hex key
10. Operator's manual
Product description
The product is a battery backpack blower with an
electrical motor.
Work is constantly in progress to increase your safety
and efficiency during operation. Speak to your servicing
dealer for more information.
Intended use
Use the product to blow leaves and other unwanted
material from areas such as lawns, pathways and
asphalt roads.
21166 - 002 - 29.10.2019
Symbols on the product
Warning! The blower can be dangerous!
Careless or incorrect use can result in
serious or fatal injury to the operator or
others. It is extremely important that you
read and understand the contents of the
operator's manual. Please read the
operator's manual carefully and make sure
you understand the instructions before using
the machine.
Use approved eye protection.
Direct current.
Noise emissions to the environment
according to European Directive 2000/14/EC
and New South Wales legislation “Protection
of the Environment Operations (Noise
Control) Regulation 2017”. Noise emission
data can be found on the machine label and
in the Technical data chapter.
Symbols on the product or its packaging
indicate that this product cannot be handled
as domestic waste. This product must be
deposited at an appropriate recycling facility.
The product agrees with the applicable EC
directives.
Do not expose to rain.
Warning LED
Start/Stop button
Boost mode button
Cruise control button
The blower operator must ensure that
no people or animals come closer
than 15 meters. When several opera-
tors are working at the same site a
safety distance of at least 15 meters
must be in effect. The blower can for-
cibly throw objects that can bounce
back. This can result in serious eye
injuries if the recommended safety
equipment is not used.
yyyywwxxxxx The rating plate shows the serial
number. yyyy is the production year
and ww is the production week.
Product liability
As referred to in the product liability laws, we are not
liable for damages that our product causes if:
• the product is incorrectly repaired.
• the product is repaired with parts that are not from
the manufacturer or not approved by the
manufacturer.
• the product has an accessory that is not from the
manufacturer or not approved by the manufacturer.
• the product is not repaired at an approved service
center or by an approved authority.
Safety
Safety definitions
Warnings, cautions and notes
are used to point out specially
important parts of the manual.
WARNING: Used if there
is a risk of injury or death
for the operator or
bystanders if the
1166 - 002 - 29.10.2019 3
instructions in the
manual are not obeyed.
CAUTION: Used if there
is a risk of damage to the
product, other materials
or the adjacent area if
the instructions in the
manual are not obeyed.
Note: Used to give more
information that is necessary in
a given situation.
Introduction
WARNING: Read all
safety warnings and all
instructions. Failure to
follow the warnings and
instructions may result in
electric shock, fire and/or
serious injury.
General power tool safety
warnings
Check before starting
•Inspect the working area.
Remove all loose objects,
such as stones, broken glass,
nails, steel wire, string etc. that
could be thrown out.
•Always remove the battery to
prevent the machine being
started by accident. Always
disconnect the battery before
any maintenance on the
machine.
•Before using the machine and
after any impact, check for
signs of wear or damage and
repair as necessary.
•Only use original spare parts.
•The machine operator must
ensure that no people or
animals come closer than 15
metres while working. When
several operators are working
in the same area the safety
distance should be at least 15
metres.
•Do an overall inspection of the
machine before use, see
maintenance schedule.
•National or local regulations
may regulate the use. Comply
to given regulations.
Personal safety
•Stay alert, watch what you are
doing and use common sense
when operating a power tool.
Do not use a power tool while
you are tired or under the
influence of drugs, alcohol or
medication. A moment of
inattention while operating
power tools may result in
serious personal injury.
•Keep bystanders away.
41166 - 002 - 29.10.2019
•This appliance is not intended
for use by person (including
children) with reduced
physical, sensory or mental
capabilities, or lack of
experience and knowledge,
unless they have been given
supervision or instruction
concerning use of the
appliance by a person
responsible for their safety.
Children should be supervised
to ensure that they do not play
with the appliance.
•Never allow children or other
persons not trained in the use
of the machine and/or the
battery to use or service it.
Local laws may regulate the
age of the user.
•Keep unauthorised persons at
a distance. Children, animals,
onlookers and helpers should
be kept outside the safety
zone of 15 m (50 ft.). Stop the
machine immediately if
anyone approaches.
•Store the equipment in a
lockable area so that it is out
of reach of children and
unauthorized persons.
•Dress properly. Do not wear
loose clothing or jewellery.
Keep your hair, clothing and
gloves away from moving
parts. Loose clothes, jewellery
or long hair can be caught in
moving parts.
•Never use the machine if you
are tired, if you have drunk
alcohol, or if you are taking
medication that could affect
your vision, your judgement or
your coordination.
•Wear personal protective
equipment. See instructions
under the heading "Personal
protective equipment".
•Always remove the battery
when passing the machine to
another person.
•Keep in mind that it is you, the
operator that is responsible for
not exposing people or their
property to accidents or
hazards.
Power tool use and care
•Never use a machine that has
been modified in any way from
its original specification. Never
use the machine near
explosive or flammable
materials.
•Never use a machine that is
faulty. Carry out the safety
checks, maintenance and
service instructions described
in this manual. Some
maintenance and service
measures must be carried out
by trained and qualified
1166 - 002 - 29.10.2019 5
specialists. See instructions
under the heading
Maintenance.
•Only use original spare parts.
•Always ensure that ventilation
openings are kept clear of
debris.
•All covers, guards and handles
must be fitted before starting.
•Only use the machine in
daylight or in other well-lit
conditions.
•Never use the machine in bad
weather, for instance in fog, in
rain, damp or in wet locations,
strong winds, intense cold, risk
of lightning, etc. Extremely hot
weather may cause
overheating of the machine.
Operation in bad weather is
tiring and can lead to
dangerous conditions, for
instance slippery surfaces.
•If the machine starts vibrating
abnormally, stop the machine
and remove the battery.
•Walk, never run.
General safety instructions
WARNING: Read the
warning instructions that
follow before you use the
product.
•Incorrect or careless use of
the product can turn it into a
dangerous tool that can cause
serious or even fatal injury to
the operator or others. You
must read and understand the
contents of this operator's
manual.
•Under no circumstances may
the design of the product be
modified without the
permission of the
manufacturer. Never use a
product that has been
modified in any way from its
original specification and
always use original
accessories. Non-authorized
modifications and/or
accessories can result in
serious personal injury or the
death of the operator or
others. Your warranty may not
cover damage or liability
caused by the use of non-
authorized accessories or
replacement parts.
•This product produces an
electromagnetic field during
operation. This field may
under some circumstances
interfere with active or passive
medical implants. To reduce
the risk of serious or fatal
injury, we recommend persons
with medical implants to
consult their physician and the
61166 - 002 - 29.10.2019
medical implant manufacturer
before operating this product.
•Remove the battery from the
product during charging.
Safety instructions for operation
WARNING: Read the
warning instructions that
follow before you use the
product.
•If you encounter a situation
where you are uncertain how
to proceed you should ask an
expert. Contact your dealer or
your service workshop. Avoid
all usage which you consider
to be beyond your capability.
•Do not allow children to use or
be in the vicinity of the
product. Since the product is
easy to start, children may be
able to start it if they are not
kept under full surveillance.
This can mean a risk of
serious personal injury.
Disconnect the battery when
the product is not under close
supervision.
•Ensure that no people or
animals come closer than 15
meters (50 ft.) while you work.
When several operators are
working in the same area the
safety distance should be at
least 15 meters. Otherwise
there is a risk of serious
personal injury. Stop the
product immediately if anyone
approaches. Never swing the
product around without first
checking behind you to make
sure that no one is within the
safety zone.
•Make sure that you can move
and stand safely. Check the
area around you for possible
obstacles (roots, rocks,
branches, ditches, etcetera) in
case you have to move
suddenly. Take great care
when you work on sloping
ground.
•Keep a good balance and a
firm foothold at all times. Do
not overreach.
•Listen out for warning signals
or shouts when you wear
hearing protection. Always
remove your hearing
protection as soon as the
product stops.
•Show consideration to persons
in your surroundings by
avoiding using the product at
unsuitable times, such as late
in the evening or early in the
morning. Follow local
regulations and ordinances.
•Do not operate the product
near open windows.
1166 - 002 - 29.10.2019 7
•Use the product with the
lowest possible airflow. It is
seldom necessary to use full
airflow, and many work
procedures can be done at
half airflow. A lower airflow
means less noise and less
dust, and it is also easier to
keep control over the rubbish
collected together/moved.
•Use a rake or a brush to
release rubbish stuck to the
ground.
•Hold the opening of the blower
as close to the ground as
possible.
•Observe your surroundings.
Direct the product away from
persons, animals, play areas,
cars etc.
•Minimize the blowing time by
lightly wetting dusty areas or
using spray equipment.
•Be aware of the wind direction.
Work with the wind to make
your work easier.
•Stop the product and remove
the battery if the product starts
to vibrate abnormally.
•Using the product to move
large piles is time consuming
and creates unnecessary
noise.
•Clean up afterwards. Make
sure that you have not blown
rubbish into someone's
garden.
•Do not run with the product.
•The powerful currents of air
can move objects at such a
speed that they can bounce
back and cause serious eye
injuries.
•Do not direct the airflow
towards people or animals.
•Stop the motor before you
assemble or dismantle
accessories or other parts.
•Keep all parts of your body
away from hot surfaces.
•Never put the product down
when it is activated unless you
have it in clear sight.
81166 - 002 - 29.10.2019
•The product must not be used
while on a ladder or
scaffolding.
•Do not use the product unless
you are able to call for help in
case of an accident.
•Watch out for thrown objects.
Stones, rubbish, etc., can be
thrown up into the eyes
causing blindness or serious
injury.
•Use a residual-current device
(RCD) for increased security
when you charge the product.
A residual-current device is
fitted to protect operators in
case an electrical fault should
occur.
•This product is renowned for
its low vibration load.
Overexposure to vibration can
lead to circulatory damage or
nerve damage in people who
have impaired circulation.
Contact your doctor if you
experience symptoms of
overexposure to vibration.
Such symptoms include
numbness, loss of feeling,
tingling, pricking, pain, loss of
strength, changes in skin color
or condition. These symptoms
normally appear in the fingers,
hands or wrists.
•Only use the product for the
purpose it was intended for.
•It is not possible to cover
every conceivable situation
you can face. Always exercise
care and use your common
sense. Avoid all situations
which you consider to be
beyond your capability. If you
still feel uncertain about
operating procedures after
reading these instructions, you
should consult an expert
before continuing.
•The harness must always be
worn when working with the
product. Failure to do so
means you will be unable to
manoeuvre safely and this can
result in injury to yourself
and/or others.
Personal protective equipment
WARNING: Read the
warning instructions that
follow before you use the
product.
•Always use approved personal
protective equipment when
1166 - 002 - 29.10.2019 9
you use the product. Personal
protective equipment cannot
fully prevent injury but it
decreases the degree of injury
if an accident does occur. Let
your dealer help you select the
right equipment.
•Long term exposure to noise
can result in damaged
hearing. In general, battery
powered products are
relatively quiet but damage
can result from a combination
of noise level and long usage.
recommends that operators
use hearing protectors when
using products for a longer
coherent time of a day.
Continual and regular users
should have their hearing
checked regularly. Note that
hearing protectors limit the
ability to hear sounds and
warning signals.
•Use approved eye protection.
If you use a visor, you must
also use approved protective
goggles. Approved protective
goggles must comply with the
ANSI Z87.1 standard in the
USAs or EN 166 in EU
countries.
•Use clothing made of a strong
fabric. Always use heavy, long
pants and long sleeves. Do
not use loose clothing that can
catch on twigs and branches.
Do not wear jewelry, short
pants, sandals or go with bare
feet. Put your hair up safely
above shoulder level.
•Keep first aid equipment close
at hand.
•A breathing mask should be
used when there is a risk of
dust.
Safety devices on the product
WARNING: Read the
warning instructions that
follow before you use the
product.
•In this section the product’s
safety features, its purpose
10 1166 - 002 - 29.10.2019
Other manuals for 340iBT
2
Table of contents
Other Husqvarna Blower manuals
Husqvarna
Husqvarna 150BT Mark II User manual
Husqvarna
Husqvarna 560BFS User manual
Husqvarna
Husqvarna 580BTS Mark II User manual
Husqvarna
Husqvarna BLOWER KIT 42'' Product manual
Husqvarna
Husqvarna 578BTF User manual
Husqvarna
Husqvarna 525BX User manual
Husqvarna
Husqvarna 536LiBX Instruction manual
Husqvarna
Husqvarna 111750 / HCS1372 Product manual
Husqvarna
Husqvarna 350BT User manual
Husqvarna
Husqvarna 593 02 43-01 User manual
Husqvarna
Husqvarna 120iBV User manual
Husqvarna
Husqvarna 525BX User manual
Husqvarna
Husqvarna 436LiB User manual
Husqvarna
Husqvarna 1153191-26 User manual
Husqvarna
Husqvarna 125B User manual
Husqvarna
Husqvarna 140 B User manual
Husqvarna
Husqvarna 125B User manual
Husqvarna
Husqvarna 350BT User manual
Husqvarna
Husqvarna 230iB User manual
Husqvarna
Husqvarna 356 BT X-series User manual
