Husky G2802B-US User manual

We appreciate the trust and confidence you have placed in Husky through the purchase of this cabinet. We strive to continually

create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement

needs. Thank you for choosing Husky!

USE AND CARE GUIDE

28 IN. 2-DOOR BASE CABINET

Questions, problems, missing parts?

Before returning to the store, call

Husky Customer Service

8 a.m. - 5 p.m., EST, Monday - Friday

1-888-HD-HUSKY

WWW.HUSKYTOOLS.COM

Item # 1001 509 625/

1001 488 134

Model # G2802B-US

Due to continuing improvements,

the actual product may differ slightly

from the product described herein.

THANK YOU

Table of Contents

Safety Information

To reduce the risk of serious injury, read and follow the safety

instructions below before assembling and using this product.

□This product is intended for indoor use only.

Any assembly or maintenance of the product must be

carried out by adults only.

Use at least two people to move, assemble or install

this product. Failure to do so can result in personal

injury or product damage.

□This product is not designed for commercial nor industrial

usage.

Keep the product on level surfaces. The product could

become unstable and it may tip over if stored or moved

on an uneven surface, which may cause personal injury,

death or product damage.

DO NOT stand or lean on the product.

Close and lock the doors before moving this product.

DO NOT leave children unattended near this product.

Cabinet may tip over if improperly opened.

Table of Contents

Safety Information

Pre-Installation

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Warranty

Specifications

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Assembly

Service Parts

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Maintenance

Care and Cleaning

...................................

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DO NOT alter this product in any manner. For example, do

not weld external bar locks or attach electrical equipment.

This may cause product damage or personal injury.

Check all nuts and bolts periodically for tightness.

When required, tighten them.

Warranty

This full warranty gives you specific rights, and you may also have other rights, which vary state to state.

Contact the customer service team at 1-888-HD-HUSKY or visit www.huskytools.com.

1 year Limited Warranty for Solid Wood top. This warranty excludes incidental/inconsequential damages and failures due to misuse,

abuse or normal wear and tear.

It is always recommended to secure this product to the

wall with the anti-tip hardware provided.

□Solid wood refers to rubber wood.

Pre-Installation

HARDWARE INCLUDED

NOTE: Screws not shown to actual size.

Part Description Quantity

AA M6 x 16 hex socket head screw 38

Adjustable foot 4

AA BB CC

CC Shelf bracket 4

TOOLS REQUIRED

Hex Wrench

(Hex Key)

Hex Screwdriver Bit

Specifications

Maximum load for shelf 100 lbs. / 45.4 kg

Maximum load for bottom panel 100 lbs. / 45.4 kg

Maximum load for wood top 100 lbs. / 45.4 kg

Maximum total load 322 lbs. / 146.2 kg

Maximum load for each door 11 lbs. / 5 kg

Drill

(not included)

WWW.HUSKYTOOLS.COM

Please contact 1-888-HD-HUSKY for further assistance.

Gloves

(not included)

M6 x 40 hex tapping bolt 2

Pre-Installation (continued)

PACKAGE CONTENTS

Part Description Quantity Part Description Quantity

A Solid wood top 1 F Right door 1

B Left side panel 1 G Bottom panel 1

C Front top beam 1 H Right side panel 1

D Left door 1 I Back panel 2

E Shelf 1 J Back top beam 1

WWW.HUSKYTOOLS.COM

Please contact 1-888-HD-HUSKY for further assistance.

Assembly

INSTALL THE ADJUSTABLE FEET

Attach the side panels (B&H) and bottom panel (G) together.

ATTACH THE SIDE AND BOTTOM PANELS

View from under

the cabinet

Front

Back

Fix the side panels (B&H) and the bottom panel (G) with two M6 x 16 hex socket head screws (AA).

Two M6 x 16 hex socket head cap screws (DD) (security screws) should

be fixed to the left bottom face of cabinet for additional door security.

Two M6 x 16 hex socket

head cap screws for

additional door security

Assemble on a flat surface. Make sure the surface is free of debris or the cabinet is protected.

A piece of cardboard is recommended to keep the product from being scratched during assembly.

Please wear gloves during the whole assembling process to avoid accidental personal injury.

For component with protective film, please peel off the protective film from each before assembling it.

Install the adjustable feet (DD) to the bottom panel (G). Make sure side A of the adjustable feet (DD) are facing either towards

the back or the front of the cabinet. Tighten securely with sixteen M6 x 16 hex socket head screws (AA).

□

Assembly (continued)

4 ATTACH THE FRONT TOP BEAM

3 ATTACH THE TOP BACK BEAM AND BACK PANELS

Place the top back beam (J) onto the side panels’ (B&H) top.

□

Make sure your floor is free of debris or the cabinet face is

protected before laying the cabinet on its face.

The top edge of the top back panel should be inserted under

the back of the back top beam.

Insert the top edge of top back

panel under the back top beam.

Attach the front top beam (C) to the side panels (B & H) with four M6 x 16 hex socket head screws (AA).

Insert the screws by hand. DO NOT tighten.

□

View from inside of cabinet

Attach the back panels (I) to the back of the cabinet with six M6 x 16 hex socket head screws (AA).

Insert the screws by hand. DO NOT tighten.

□

Fix the side panels (H&B) and bottom panel (G) together with two M6 x 16 hex socket head screws (AA).

Insert the screws by hand . DO NOT tighten.

□

Fix the side panels (H&G) and bottom panel (G) together with four M6 x 16 hex socket head screws (AA).

Insert the screws by hand. DO NOT tighten.

□Stand up the cabinet.

Assembly (continued)

5 ATTACH THE SOLID WOOD TOP

Attach the wood top (A) to the cabinet top by inserting four M6 x 16

hex socket head screws (AA) through the pre-drilled holes at the top

beams (C & J) to the wood top (A). Tighten securely.

6 ATTACH THE DOORS

□Insert the pins from the hinges of the left door (D) into the

slots of the bottom hinges at the front of the left side panel (B).

□Repeat the same procedure to attach the right door (F).

WWW.HUSKYTOOLS.COM

Please contact 1-888-HD-HUSKY for further assistance.

□

□Close the doors to see if the doors can touch the magnets

completely. If not, adjust the cabinet’s top and side panels to

make sure the shape of the cabinet is square and flush. Until

the doors can catch the magnets completely, tighten all

the screws at the cabinet front and back.

magnet

Assembly (continued)

7 INSTALL THE SHELF

Insert four shelf brackets (CC) into the slots on the side panels at the desired height. Make sure the four brackets (CC) are at

the same height. Place the shelf (E) over the shelf brackets (CC), and push it down onto the shelf brackets. Make sure the

shelf (E) is properly and safely locked by the upright hooks of the shelf brackets.

Shelf locked by shelf bracket

after installation

□

Slots on the inner back side

of side panel

Slots on the inner front

side of side panel

The M6 x 40 hex tapping bolts (BB) should be drilled into

the stud of the wall.

Maintenance

Check all the screws and nuts periodically for tightness. Tighten them when necessary.

□

CONNECT THE CABINET TO THE WALL

Open the doors and fasten the cabinet to the wall with

two M6 x 40 hex tapping bolts (BB).

□

WALL

Slots on the inner front

side of side panel

Slots on the inner

back side of side

panel

WALL

Service Parts

Part Description Quantity Part Description Quantity

ASolid wood top 1

IBack panel 2

BLeft side panel 1

JBack top beam 1

CFront top beam 1

AA M6 x 16 hex socket head screw

DLeft door 1

Adjustable foot

E Shelf 1

CC Shelf bracket

FRight door 1

GBottom panel 1

KKey

LMagnet

MLock

Replacement keys may be ordered. Call 1-844-370-2288 .

Replacement Part # Replacement Part #

WWW.HUSKYTOOLS.COM

Please contact 1-888-HD-HUSKY for further assistance.

HRight side panel 1

DD 4

Care and Cleaning

□

□Grease and oil can be removed with most standard cleaning fluids. For safety, use a nonflammable cleaning fluid.

Periodically clean the surfaces with a soft rag and water.

M6 x 40 hex tapping bolt

571215

121803

121804

243230

243231304213

121800

121806

121802

121801

243232

312033

304212

320327

320328

243311

313066

Questions, problems, missing parts? Before returning to the store,

call Husky Customer Service

8 a.m.-5 p.m., EST, Monday-Friday

1-888-HD-HUSKY

WWW.HUSKYTOOLS.COM

Retain this manual for future use.
