Hunter 28671 Manual

Fan Parts

(Not Drawn to Scale)

PARTS GUIDE

Using this Parts Guide, make sure all

parts are included in the box.

If parts are missing, DO NOT RETURN

THIS ITEM TO THE STORE, call 888-830-1326 for assistance.

THIS PARTS GUIDE IS FOR REFERENCE ONLY.

REFER TO THE INSTALLATION MANUAL FOR FULLASSEMBLY INSTRUCTIONS.

Using this Parts Guide, make sure all

parts are included in the box.

If parts are missing, DO NOT RETURN

THIS ITEM TO THE STORE, call 888-830-1326 for assistance.

THIS PARTS GUIDE IS FOR REFERENCE ONLY.

REFER TO THE INSTALLATION MANUAL FOR FULLASSEMBLY INSTRUCTIONS.

Parts List

Model # 28671

Asm. Dwg. # 99968-01

Finish Brushed Nickel

Item Name Qnty Part #

*Hanging System Kit 1 96761-09

Ceiling Plate

Canopy

Setscrew

Canopy Screw

Wood Screw

Flat Washer

Mounting Isolator

Hanger Ball / Downrod Assembly 1 74229-03

Extension Pipe / 8” Downrod 1 74228-13

Switch Housing Assembly 1 99966-01

Blade Iron Set 1 89677-03

Blade Set 1 G0253-96

Screw, Blade Iron Armature 6 63755-05

Hardware Kit 1 99968-00-860

Blade Grommet

Blade Assembly Screw

Screw, Machine, 6-32

Wire Connector

Balancing Kit 1 65666-01

Light Kit Assembly 1 89399-01

Pull Chain Pendant 1 G0090-01

Pull Chain Pendant 1 G0091-01

Pull Chain 2 63756-42

Globe/Shade 1 99964-01

Hardware

(Drawn to Scale)

Hanger

Bracket

Assembly

Blade

Assembly

Light Kit

Assembly

Screw,

Machine, 6-32

Setscrew

Mounting Isolator

Screw, Blade

Iron Armature

Canopy Screw

Flat Washer

Screw, Blade

Assembly

3” Wood Screw

Balancing

Kit

Wire

Connector

1.5” Wood Screw

Blade

Grommet

x 2

x 4

x 2

x 4

x 1

x 6

x 4

x 10

x 4

x 1

x 4

x 10

Materiales

(no dibujados a escala)

Piezas del ventilador

(no dibujadas a escala)

GUÍA DE PIEZAS

PARADA

Consulte esta Guía de partes para

asegurarse de que todas las partes

estén incluidas en la caja.

Si falta alguna parte, NO DEVUELVA ESTE PRODUCTO A LA TIENDA. Solicite ayuda al

888-830-1326. ESTAGUÍA DE PARTES SOLAMENTE ES REFERENCIAL. CONSULTE LAS

INSTRUCCIONES COMPLETAS DE ENSAMBLAJE EN ELMANUALDE INSTALACIÓN

PARADA

Lista de piezas

No. del modelo 28671

No. del dibujo de ensamblaje 99968-01

Acabado Bronce Nuevo

Nombre del ítem Cantidad No. de la pieza

*Kit del sistema de suspensión 1 96761-09

Placa de techo

Campana

Tornillo prisionero

Tornillo, de campana

Tornillo, de madera

Arandela, plana

Aislador de montaje

Bola de suspensión / Conjunto de varilla 1 74229-03

Tubo de extensión / varilla de 8” 1 74228-13

Conjunto del interruptor 1 99966-01

Juego de soporte de paletas 1 89677-03

Juego de paletas 1 G0253-96

Tornillo, de armadura de soporte de paleta 6 63755-05

Kit de materiales 1 99968-00-860

Arandela de caucho, de paleta

Tornillo, de conjunto de paleta

Tornillo, mecánico, 6-32

Empalme plástico

Kit de equilibrado 1 65666-01

Conjunto del kit de luz 1 89399-01

Pendiente del tirador de cadena 1 G0090-01

Pendiente del tirador de cadena 1 G0091-01

Tirador de cadena 2 63756-42

Globo / Pantalla 1 99964-01

Conjunto del

soporte de

suspensión

de conjunto

de paleta

Conjunto del

kit de luz

Tornillo

mecánico, 6-32

Tornillo prisionero

Tornillo de armadura

de soporte de paleta

Tornillo de campana

Arandela plana

Tornillo, de conjunto

de paleta

3” Tornillo de madera

Kit de

equilibrado

Empalme

plástico

1.5” Tornillo

de madera

Arandela de caucho de

paleta

Tornillo

mecánico, 6-32

x 2

x 4

x 2

x 4

x 1

x 4

x 1

x 4

x 4 Aislador de montaje

x 6

x 10
