Huawei MediaPad M2 10.0 User manual

Quick Start

1

1 HUAWEI MediaPad M2 10.0 at a

glance

Avoid blocking the ambient light sensor as it may

affect normal use of the M2. Choose a screen

protector that has a hole above the ambient light

sensor.

2

2 Card insertion



Use standard micro-SIM cards. SIM cards that are

manually cut or in a sleeve may damage the card slots.



Do not insert or remove a SIM or microSD card while

your M2 is on.



With the card tray horizontal, make sure that the beveled

edge of the card is aligned with the card tray.

Store the card eject tool in a safe place out of reach

of children to prevent them from swallowing it or

injuring themselves by accident.

3

3 Fingerprint identification

Touch

Settings

>

Fingerprint ID

>

Fingerprint

management

. Follow the onscreen instructions to set a

PIN or password and enroll your fingerprint.

After enrolling your fingerprint, you can touch the

fingerprint sensor to unlock your screen.

4

4 Dual windows

You can split the screen into two parts and view different

content simultaneously. To enable dual windows, touch

and hold the recent key , or swipe up from the bottom

of the screen with two fingers.

On the dual windows screen, touch or drag to

view more options.

5

5 M-Pen (optional accessory)

The M-Pen replaces the finger to easily control the screen

and optimize your efficiency. It can also work with special

apps for handwriting and drawing, bringing you endless

fun.

The M-Pen is provided with M2 premium edition

and is optional for other editions. To purchase the

M-Pen, please contact your M2 retailer.

6

Eraser



When drawing, press and hold the eraser button to delete

pictures.

Not all apps support this function.

Function button



Press and hold and then outline the screenshot area to

take a screenshot.



Press and hold and then double touch the screen to take

a full screenshot.



Press and hold, and touch the screen to easily open the

floating window for special apps.

7

Installing the battery

1. Unscrew the lid in a counterclockwise direction.

2. Insert the battery (AAAA only) into the pen with

the plus sign at the bottom and the minus sign at

the top.

3. Screw in the lid in a clockwise direction.

8

Remove the battery if the M-Pen will not be used

for a long time.

Changing the pen tip

1. Use forceps or your fingers to clamp the pen tip.

2. Pull the pen tip out with force. Clamp tightly onto

the pen tip so that you don't lose your grip.

3. Clamp the top part of the spare tip and insert the

bottom part into the pen. Push it in until it is

firmly in place, to prevent it from becoming loose

and getting lost.

Store the removed tip in a safe place out of reach of

children to prevent them from swallowing it or

injuring themselves by accident.
