HRMTEC 123 SCHLEIFENPROFI VX User manual

v1.6e

USER MANUAL FOR 123 SCHLEIFENPROFI

VX EMBOSSING MACHINE

v1.6e

CONTENT

1. Delivered Parts.......................................................................................................................3

1.1 Hardware.............................................................................................................................3

1.2 Consumables......................................................................................................................3

1.3 Software..............................................................................................................................3

2. Setup........................................................................................................................................4

2.1 Installation Printer Driver..................................................................................................4

2.2 Setting Printer Driver.........................................................................................................6

2.2.1 Set Schleifenprofi VX as Default Printer....................................................................6

2.2.2 Set the Parameters of the Printer Driver....................................................................7

2.2.3 Setting the Print Size and Print Quality....................................................................10

2.3 Installation of Ribbon Printing Software.......................................................................11

3. Instructions............................................................................................................................12

3.1 Prepare the 123 Schleifenprofi VX Embossing Machine...........................................12

3.1.1 Check Parts..................................................................................................................12

3.1.2 Keys and Functions.....................................................................................................12

3.1.3 Insert Ribbon................................................................................................................13

3.1.4 Insert Printing Foil........................................................................................................14

3.1.5 Verification....................................................................................................................14

3.2 Prepare Ribbon Printing Software.................................................................................15

3.2.1 Prepare Links...............................................................................................................15

3.2.2 Prepare Layouts...........................................................................................................15

3.3 Embossing Process.........................................................................................................16

3.3.1 Preparations.................................................................................................................16

3.3.2 Embossing....................................................................................................................16

3.3.2.1 Printing Foil Consumption..........................................................................................16

3.3.2.2 Print Quality..................................................................................................................17

3.3.3 Standard Parameters per Ribbon Material and Printing Foil................................17

4. Maintenance.........................................................................................................................19

4.1 Clean Print head..............................................................................................................19

4.2 Storage of Printing Foils .................................................................................................19

5. Technical Data......................................................................................................................20

6. Index......................................................................................................................................20

7. Trouble Shooting..................................................................................................................21

v1.6e

1. Delivered Parts

Please check the complete delivery of your 123 Schleifenprofi VX Embossing Machine:

1.1 Hardware

1 Embossing machine

3 carrier rolls for the printing foil, the ribbon and the waste foil

1 Carton roll for the waste foil

1 power cable with Schuko plug

1 connection cable embossing machine - computer (USB interface)

1.2 Consumables

1 High-tech Premium Printing foil (usually gold)

1.3 Software

To always use the latest and most recent software version, please download it directly

from our website:

Printer driver: https://www.hrmtec.com/en/downloads/

You are independent to choose the ribbonprinting software or graphics software, which

is most suitable for your company.

As an example you can try the freeware GreenRibbon

(https://greenribbon.de/greenribbon1.htm). Please note that the ribbon printing

software GreenRibbon is a freeware provided by the manufacturer watermann IT

without support and without warranty. For a supported full version (GreenRibbon 2.x)

or another ribbon printing software, please contact the appropriate manufacturer.

v1.6e

2. Setup

2.1 Installation Printer Driver

After downloading the latest printer driver from https://www.hrmtec.com/en/downloads/,

unpack the zip file (using WinZip https://www.winzip.com/win/en/downwz.html) and

run the file "Schleifenprofi_VX.exe" to install the printer driver. To do this, follow the

steps below:

Schleifenprofi_VX.exe

Double-click to execute the program.

Select "English" and press "OK".

Press "Next" to continue.

Select „I have read and accept the

license terms”, and press “Next” to

continue.

v1.6e

Press "Install" to start the installation.

Select the path where the printer

driver should be installed, the

default folder is already entered.

Press "Next" to continue.

Leave the printer settings

unchanged.

The Schleifenprofi_VX should be

set as default printer.

Press "Next" to continue.

The printer drive is now installed.

Please wait until the installation is

complete (which can take several

minutes).

v1.6e

The installation of the printer

driver is completed successfully.

Press "Finish" to close the

window.

2.2 Setting Printer Driver

2.2.1 Set Schleifenprofi VX as Default Printer

Define the "Schleifenprofi VX " printer driver as the default printer (Windows Printer

overview, select printer driver, press right mouse button, select "Set default printer").

How to proceed:

Check under "Devices and

Printers" if the Schleifenprofi VX

is defined as the default printer

(green checkmark).

If another printer is defined as the

default printer, then set the

Schleifenprofi VX as the default

printer (see next step).

v1.6e

Select Schleifenprofi VX and

press the right mouse button.

Select "Set as Default Printer".

The Schleifenprofi VX is set correctly

as Standard Printer.

2.2.2 Set the Parameters of the Printer Driver

Under "Properties" of the printer driver, the following settings have to be checked or

made:

v1.6e

Select Schleifenprofi VX and

press the right mouse button.

Select "Printer Properties".

Under "Printer Settings" make the

following settings:

Check the Page Settings list.

The standard 252 x 550 mm

should be in the list.

After installing the driver for the

first time, this setting must be

made manually. To do this,

press "Add" and continue with

the next step

Depending on the application

further settings can be defined,

we recommend 252 x 650 mm

and 252 x 750 mm.

Enter the following:

Paper Name: 252 x 550mm

Width: 252

Length: 550

Press "OK"

We recommend the additional

settings:

Paper Name: 252 x 650mm

Width: 252

Length: 650

v1.6e

Paper Name: 252 x 750mm

Width: 252

Length: 750

Select now 252 x 550mm

Press "OK"

Under "Device Settings" make the

following settings:

Manual Paper Feed: 252 x

550mm

Density (Print temperature):

100Level (this depends on the

material used, ribbon and

printing foil)

Print Speed: (Printing speed):

LowSpeed (this depends on

the material used, ribbon and

printing foil)

Press "OK"

ATTENTION: the values given here for "Density" and "Print Speed" are for Warp

Moiré and Embossed Moiré in combination with Metallic Print Foils (Gold, Silver).

For other materials and foil colors, these values must be adjusted, see also 3.3.3

v1.6e

Please note that in order to get the best print results, the parameters "Density" and

"Print Speed" have to be set according to the ribbon used and the printing foil used.

Under 3.3.3 you find a table with guideline values.

In general, using coarser material (e.g., warp moiré or embossed moiré) tends to

imprint higher print temperatures and lower speed than using fine material (SuperSatin,

SuperSatin Premium, Poly tapes).

Normally, an operation always uses the same ribbon materials. Thus, this setting only

needs to be optimized once and will only be changed if another ribbon material is to

be embossed.

2.2.3 Setting the Print Size and Print Quality

Under "Properties" of the printer driver, the following settings have to be checked or

made:

Select Schleifenprofi VX and

press the right mouse button.

Select "Printing preferences"

Select "Advanced"
