HP E2416B User manual
User’s Guide
Publication Number E2416-97002
June 1998
For Safety Information, Warranties, and Regulatory Information, see the
pages at the end of this manual.
Copyright Hewlett-Packard Company 1993 - 1998
All Rights Reserved.
HP E2416B Analysis Probe for
Intel 80196
The HP E2416B Analysis Probe — At a Glance
The HP E2416B Analysis Probe provides a complete interface for
state or timing analysis between any compatible 80196 PLCC target
system and HP logic analyzers. The supported logic analyzers are
listed in chapters 1. A microprocessor is defined as compatible if it
conforms to the 80196 architecture, uses the 80196 instruction set,
and uses the 68-pin PLCC pinout. This includes 8096, 8097, AH
versions, -90 versions, BH versions, and 80C196KA/KB/KC/KD.
The analysis probe provides the physical connection between the
target microprocessor and the logic analyzer. The configuration
software on the enclosed disks set up the logic analyzer for
compatibility with the analysis probe. The inverse assemblers on the
disks let you obtain displays of the 80196 data in 80196 assembly
language mnemonics.
If you are using the analysis probe with the HP 16600 or HP 16700
series logic analysis systems, you only need this manual as a
reference. The HP 16600 and 16700 series contain a Setup Assistant,
which guides you through the connection and configuration process
using on screen dialog windows. For an overview of Setup Assistant,
refer to Chapter 1, "Setup Assistant."
For more information on the logic analyzers or microprocessor, refer
to the appropriate reference manuals for those products.
ii HP E2416B 80196 Analysis Probe
Analyzing a Target System with the HP E2416B Analysis Probe
The HP E2416B AnalysisProbe — Ata Glance
HP E2416B 80196 Analysis Probe iii
In This Book
This book is the User’s Guide for the HP E2416B Analysis Probes. It assumes
that you have a working knowledge of the logic analyzer used and the
microprocessor being analyzed.
This user’s guide is organized into the following chapters:
Chapter 1 contains overview information, including a list of required
equipment.
Chapter 2 explains how to connect the logic analyzer to your target
system through the analysis probe, and how to configure the analysis
probe and logic analyzer to interpret target system activity. The last
section in this chapter shows you how to hook up optional equipment
to obtain additional functionality.
HP 16600 and HP 16700 Series Logic Analysis Systems
If you are using the analysisprobe with HP16600or HP 16700 serieslogic
analysissystems, youonly need this manual as areference for obtaining and
interpretingdata. The HP 16600 and HP 16700 contain a Setup Assistant, which
guides youthroughthe connection and configuration processusing on screen
dialog windows. For an overview of Setup Assistant, refer to chapter 1, "Setup
Assistant."
Chapter 3 provides information on analyzing the supported
microprocessors.
Chapter 4 contains reference information on the analysis probe.
Chapter 5 contains troubleshooting information.
Configuring
Connecting &
Configuring
Your System
Chapter 2
Connecting
the Analysis
Probe to the
Target System
Analyzing the
Target System
Chapter 3
Connecting
Optional
Equipment
Overview
Chapter 1
Reference
Chapter 4
If You Have
a Problem
Chapter 5
Connecting
the Analysis
Probe to the
Logic Analyzer
iv HP E2416B 80196 Analysis Probe
Contents
The HP E2416B Analysis Probe — At a Glance ii
1 Overview
Setup Assistant 1–3
Logic Analyzers Supported 1–4
Logic analyzer software version requirements 1–5
Equipment Used with the Analysis Probe 1–6
Equipment supplied 1–6
Minimum equipment required 1–8
Additional equipment supported 1–8
2 Connecting and Configuring Your System
Power-on/Power-off Sequence 2–4
To power on HP 16600 and HP 16700 series logic analysis systems 2–4
To power on all other logic analyzers 2–4
To power off 2–4
Connecting the Analysis Probe to the Target System 2–5
To connect to a PLCC target system 2–6
Connecting the Analysis Probe to the Logic Analyzer 2–8
Analysis probe pod locations 2–9
To connect to the HP 16600A logic analysis system 2–10
To connect to the HP 16601A logic analysis system 2–11
To connect to the HP 16602A logic analysis system 2–12
To connect to the HP 16603A logic analysis system 2–13
To connect to the HP 16550A logic analyzer 2–14
To connect to the HP 16554/55/56 logic analyzers 2–15
To connect to the HP 1660A/AS/C/CS/CP logic analyzers 2–16
To connect to the HP 1661A/AS/C/CS/CP logic analyzers 2–17
Contents-1
To connect to the HP 1662A/AS/C/CS/CP logic analyzers 2–18
To connect to the HP 1670A/D logic analyzer 2–19
To connect to the HP 1671A/D logic analyzer 2–20
To connect to the HP 1672A/D logic analyzer 2–21
Configuring 2–22
Configuring the Analysis Probe 2–23
Configuring the Logic Analysis System 2–24
To load configuration and inverse assembler files — HP 16600/700 logic analy-
sis systems 2–25
To load configuration and inverse assembler files — other logic analyzers 2–
26
Connecting Optional Equipment 2–28
3 Analyzing the Target System
Analyzing the Target System 3–2
Modes of Operation 3–3
State-per-transfer mode 3–3
State-per-clock mode 3–3
Timing mode 3–3
Logic Analyzer Configuration 3–4
Trigger specification 3–4
Format specification display 3–4
Logic Analyzer Symbols 3–6
Modifying the trigger menu 3–8
Contents
Contents-2
Using the Inverse Assemblers 3–9
To display captured state data 3–10
To align the inverse assembler 3–11
Inverse assembler output format 3–12
Inverse assembler error messages 3–12
4 Reference
Operating characteristics of the analysis probe 4–3
Theory of operation and clocking 4–5
State-per-transfer mode 4–5
State-per-clock mode 4–5
Timing mode 4–6
Signal-to-connector mapping 4–8
Circuit board dimensions 4–13
Replaceable parts 4–14
5 If You Have a Problem
Analyzer Problems 5–3
Intermittent data errors 5–3
Unwanted triggers 5–3
No activity on activity indicators 5–4
No trace list display 5–4
Analyzer won’t power up 5–4
Analysis Probe Problems 5–5
Target system will not boot up 5–5
Erratic trace measurements 5–6
Capacitive loading 5–6
Inverse Assembler Problems 5–7
No inverse assembly or incorrect inverse assembly 5–7
Inverse assembler will not load or run 5–8
Intermodule Measurement Problems 5–9
Contents
Contents-3
An event wasn’t captured by one of the modules 5–9
Analyzer Messages 5–10
“. . . Enhanced Inverse Assembler Not Found” 5–10
“. . . Inverse Assembler Not Found” 5–10
“. . . Does Not Appear to be an Inverse Assembler File” 5–10
“Measurement Initialization Error” 5–11
“No Configuration File Loaded” 5–14
“Selected File is Incompatible” 5–14
“Slow or Missing Clock” 5–14
“Time from Arm Greater Than 41.93 ms” 5–15
“Waiting for Trigger” 5–15
Cleaning the Instrument 5–16
Glossary
Index
Contents
Contents-4
1
Overview
Overview
This chapter describes:
•Setup Assistant
•Logic analyzers supported
•Logic analyzer software version requirements
•Equipment used with the analysis probe
•Equipment supplied
•Minimum equipment required
•Additional equipment supported
Configuring
Connecting &
Configuring
Your System
Chapter 2
Connecting
the Analysis
Probe to the
Target System
Analyzing the
Target System
Chapter 3
Connecting
Optional
Equipment
Overview
Chapter 1
Reference
Chapter 4
If You Have
a Problem
Chapter 5
Connecting
the Analysis
Probe to the
Logic Analyzer
1-2 HP E2416B 80196 Analysis Probe
