Hotpoint HSS22DDM User manual

HSS22DDM - Hotpoint 21.8 Cu. Ft. Side-by-Side Refrigerator with Icemaker

Specification Revised 3/01

®

A

Front View

Top View

G

D

C

F

BE

H

Height with hinge (in.) A 69-3/4

Height without hinge (in.) B 66-1/2

Depth without Doors (in.) C28

Depth with Doors (in.) D 30-3/4

Depth plus Handle with Doors Closed (in.) E33

Depth with Doors open 90° (in.) F 48-13/16

Width with Doors Closed (in.) G 33-1/2

Width with Doors open 90°Less Handle (in.) H 35-12/16

Each side (in.) 1/8

Top (in.) 1

Back (in.) 1

Overall

Dimensions

Air

Clearances

CU

®

Manufacturer Certified to

ASSOCIATION OF HOME

APPLIANCE MANUFACTURERS

ANSI/AHAN HRF-1-1979

VOLUME and

SHELF AREA

R

Total volume and shelf

area are calculated by the

Association of Home

Appliance Manufacturers’

standards.

Listed by

Underwriters

Laboratories

Specification Revised 3/01

HSS22DDM - Hotpoint 21.8 Cu. Ft. Side-by-Side Refrigerator with Icemaker

WATER CUBED

LIGHT

Features and Benefits

•21.8 cu ft Capacity (Fresh Food 14.7 cu ft / Freezer 7.1 cu ft)

•Upfront Electronic Temperature Control

•FrostGuard™Technology

•Tall LightTouch! Dispenser

•Hotpoint®Water Filter

•NeverClean™Condensor

•3 Adjustable Wire Fresh Food Cabinet Shelves

•Sealed Deli Pan

•Sealed Fruit/Vegetable Crisper

•4 Fresh Food Door Shelves (2 Adjustable with Gallon Storage)

•Electronic Icemaker

•Deluxe Quiet Design

•Model HSS22DDMWH - White

®
