Hotpoint HM311i User manual

Instructions for Installation and Use

Integrated Fridge / Freezer

Model HM311i

WARNING: This appliance must be earthed.

Fuses

Your appliance comes fitted with a plug and a 13 fuse. If you need to replace the fuse, only

those rated at 13 and ST approved to BS1362 should be used. Correct replacement is

identified by colour coding or the marking on base of plug.

WARNING: Do not use plug unless fuse cover is fitted.

Changing the Plug

Cut off and dispose of the supplied plug if it does not fit your socket.

WARNING: To avoid a shock hazard do not insert the discarded plug into a socket

any here else.

IMPOR AN : WIRES IN HE MAINS LEAD ARE COLOURED IN ACCORDANCE WI H HE

FOLLOWING CODE:

Green/Yellow - Earth

Blue - Neutral

Brown - Live

If you change the plug, the colour of

wires in the mains lead may not

correspond with the colour of the

markings identifying terminals in the

plug.You should therefore wire it as

shown.

Changing the Mains ead

special lead can be ordered from

our Service Department

UK: 08709 066 066 or

Republic of Ireland: 1850 302 220

If you have damaged the existing lead or require a longer one a charge will be made. It is

strongly advised that this work is carried out by a qualified electrician.

CE marking certifies that this appliance conforms to the following EEC directives:-

ow Voltage Equipment - 72/23/EEC & 93/68 EEC

Electromagnetic Compatibility - 89/336/EEC, 92/31/EEC & 93/68/EEC

Electrical Supply

Green and yellow (Earth)

wire to terminal

marked ‘E’,

symboL, or

coloured green

and yellow.

Blue (Neutral)

wire to terminal

marked ‘N’ or

coloured black.

13 ST approved

fuse to BS1362.

Brown (Live)

wire to terminal

marked ‘L’ or

coloured red.

Cord clamp

WARNING: AVOID ACCIDEN S O CHILDREN. WHEN DISCARDING AN OLD FRIDGE OR

FREEZER BE CER AIN O MAKE HE LOCK UNUSABLE. IF POSSIBLE, REMOVE HE DOOR

AND DISCARD SEPERA ELY.

DO NO A EMP O SI ON OP OF YOUR APPLIANCE. I IS NO DESIGNED FOR SUCH

USE AND YOU COULD INJURE YOURSELF OR DAMAGE HE APPLIANCE BY SUCH ABUSE.

IMPORTANT INFORMATION:

●

Do not plug in and switch appliance on at the mains until installation is complete.

●

You may be charged for a service call if a problem with your appliance is caused

by incorrect installation or misuse.

Contents Page

Installation

Choosingalocation 4

Installation 4

Door Reversal 5-6

Mountingtheappliance 7-8

Get to know your Appliance 9-10

Getting your Appliance ready for use

FinalCheck 10

RunningintheCompressor 10

The Controls 11

Storing Food

StoringFresh Food 12

FreezingFresh Food/Procedure 13

StoringFrozenFood 13

DefrostingFrozenFood 13

Caring for your Appliance

Defrosting 14

ChangingtheLightBulb 14

Cleaning 15

Going Away 15

Troubleshooting 16

After Sales Service 17

Guarantee 18

Key Contacts BackCover

Retention of the Instruction Book

ThisInstruction Book mustbe kept handyforreferenceasit contains importantdetails on the

safeandproperuse of the appliance.

If you sell or passthe appliance to someone else,ormovehouseandleaveitbehind,make sure

thisBook is also providedsothenew owner can become familiar withthe appliance and safety

warnings.

694527.qxd 1/31/03 9:18 Page 3

Before Fitting:

Before connecting to the electricity supply

leave the appliance to stand for 2 hours to

allow the cooling system to settle.

Please read through this section before

starting any work.

At the base of the kitchen unit intended for

installing the appliance,there should be at

least 200cm2free space,for adequate air

circulation.

Do not cover the air outlet grille at the top of

the appliance.

Your Integrated Fridge Freezer is designed to

fit into a tall housing as shown (fig 1). It is

vitally important that the appliance is vented

correctly.

Choosing a location:

Your Integrated Fridge Freezer should be

fitted into a kitchen unit space where it is easy

to use.

The power socket should be in a readily

accessible position adjacent to the unit.

Never place the appliance near a heat

emitting device (eg.cooker,radiator,water

heater or similar) and do not expose it to

direct sunlight.In such a position your Fridge

Freezer will have to work harder and will cost

more to run and may be damaged by the

heat. The appliance may be exposed to lower

or higher temperatures but only for short

periods of time and the temperature should

never be lower than 5˚C.

The rear wall of the appliance gets warm

during operation and water evaporates from

the drain pan on the compressor.You must

therefore provide adequate air circulation at

the rear of the appliance.

Installation.

WARNING:THE APPLIANCE SHOULD

ONLY BE INSTALLED BY A QUALIFIED

ELECTRICIAN IN COMPLIANCEWITHTHESE

INSTRUCTIONS,CURRENT STANDARDS

AND REGULATIONS.

Fig.1

A (mm) B (mm) C (mm)

Bottom door Top door Cabinet

846 840 1775-1780

PlinthVentilation

545

694527.qxd 1/31/03 9:18 Page 4

Installation (Door reversal).

1. Top hinge cover of the refrigerator door.

2. Top hinge of the refrigerator door.

3. Top strip.

4. Bottom hinge of the refrigerator door.

5. Top hinge of the freezer door.

6. Washer.

7. Bottom hinge of the freezer door.

8. Bottom hinge filling plug of the freezer

door.

9. Slider guide.

10.Corner cap with a hole.

11.Corner cap without a hole.

694527.qxd 1/31/03 9:18 Page 5

Installation (Door reversal).

If you find that the direction of the door

opening is not convenient,you can reverse it.

The necessary holes on the opposite side of

the cabinet have been made inthe factory and

plugged.

* Remove the top hinge cover of the

refrigerator door.Remove the door by

unscrewing the hinge (the door is

supported only by the bottom hinge) and

remove the hinge washer.

* Unscrew the top strip,move it on the

opposite side of the appliance and fasten

it.

* Unscrew the bottom hinge and washer of

the freezer door and the bottom hinge of

the refrigerator door.

* Remove the corner caps from the door and

reposition them (instead of the one with a

hole insert the one without it,and vice

versa).

* Take off the washer from the bottom hinge

of the freezer door (by turning it in

clockwise),unscrew the bottom hinge

filling plug and screw the bottom hinge

without a plug.

* Insert the filling plug and washer in the

reverse order into the ho;e for the bottom

hinge on the opposite side of the

appliance.

* Put the freezer door on the bottom hinge.

* Turn the bottom hinge of the refrigerator

door by 180˚,insert the hinge and the

washer into the hole of the corner cap on

the freezer door and fasten it.Use the same

procedure for the top hinge of the freezer

door and screw it on the opposite side of

the upper door.Put the washer and the

upper door on the hinge.

* Screw the top hinge of the refrigerator

door and replcae the cover.

* Reposition the slide guides on the

opposite side of both doors.

* Plug the remaining holes with the

decorative caps.

* After you have reversed the door,check if

the magnetic gasket seals correctly.It must

not be creased and must seal all around

the door.

694527.qxd 1/31/03 9:18 Page 6

Mounting the appliance

Before mounting the appliance into the

kitchen uniut,disconnect the power supply

and set the thermostat knob to the OFF (O)

position.

Push the appliance for some 38mm into the

kitchen unit and allow at least 4mm free

space on both sides between the appliance

and the side walls of the kitchen unit.(Fig.1)

Open both doors as wide as possible and put

them together with the door of the kitchen

unit.The proceduere is as follows;

* Fix the slide guides (attached in a plastic

bag along with the screws ST 4,2 x 9,5) to

the edge of the door.Cover the open

holes with the attached cap.

* Put the appliance door and the door of

the kitchen unit (Fig.2).

Insert the slides into the guides and fix

them on the kitchen unit door some

15mm from the edge,using the A4 x 12

screws (Fig.3).

* Remove the slide guides and separate the

appliance door from the door of the

kitchen unit.

* Fix the slides taking care not to move

them (Fig.4).

* Fix the slides to the original position.

* Close the door and check that the gasket

is not creased and the door opens

smoothly

Fig.1

Fig.3

Fig.4

Fig.2

694527.qxd 1/31/03 9:18 Page 7

Mounting the appliance

* Fix the appliance into the kitchen unit.On

the upperside,fix the three screws through

the rail and on the lower side with 2 screws

through the lower hinges.Drill holes ¿3 x 5

(Fig.5).

* Seal the gap on the opposite side of the

hinge with the enclosed seal (Fig.6)

Fig.5

Fig.6

694527.qxd 1/31/03 9:18 Page 8

Get to know your Appliance.

WARNING:CHILDREN SHOULD NOT BE

ALLOWEDTO PLAYWITH THE APPLIANCE

ORTAMPERWITH THE CONTROLS.

A. 1.Shelf

The shelves are adjustable and can be pulled

out and used on any of the guide slots.They

can also be used in a tilted position to allow

the safe storage of bottles,jars etc.on there

sides.To tilt a shelf,place the back of the shelf

on a lower slot than the front.

2.The defrost water outlet

The interior of the refrigerator is cooled with

a cooling plate incorporated in the rear wall.

Under the plate there is a channel and an

outlet for the defrosted water.

Regularly check the outlet and channel for

food deposits which could clog the drain

hole.If the hole is blocked,use a plastic straw

to clean it out.

3.Fruit and vegetable container

The container is under the glass at the bot-

tom of the refrigerator and is mainly used to

store fruit and vegetables.

The door liner

The door liner consists of various shelves or

holders used for storing eggs,cheese,butter

and yogurt as well as other small packages ,

tubes,cans etc.

The lower shelf is used for storing bottles.

The interior light

The light will come on when the door is

opened.

4.Freezing compartment

This is used for freezing fresh food.

5.Storing compartment

This is used for storing packages of frozen

foods.

6.Defrost water outlet

(see care and cleaning).

Note:

Various accessories (depending on model)

such as;spice container,tube holder or addi-

tional shelves can be bought from authorised

centres

694527.qxd 1/31/03 9:18 Page 9

Getting your Appliance ready for use.

Before connecting to the mains electricity

supply leave the appliance to stand for 2

hours to allow the cooling system to settle.

Clean the appliance,and be thorough,

especially in the interior.(see‘Caring for

your Appliance.

Final Check:

Before you start using your appliance check

that:

- The appliance is level.

- It is thoroughly dry inside.

- There is adequate air circulation.

- Accessories are correctly placed in their

positions.

Running in the Compressor:

Your appliance is operated by a compressor

which switches on and off in order to

maintain the internal temperature.

The compressor requires a running in period

of up to 2 months.During this time it has to

work a little harder and may result in more

noise than usual.

Noise levels are also determined as to the

location of the appliance,what is stored and

where the items are placed,

Whether the compressor is running

or not,it is normal to hear sounds

created by the liquid and gases sealed

within the system.

694527.qxd 1/31/03 9:18 Page 10

Table of contents

Other Hotpoint Refrigerator manuals

Hotpoint

Hotpoint HUL 1621 User manual

Hotpoint

Hotpoint FF4DK(UK) User manual

Hotpoint

Hotpoint 162D6746P002 Operating instructions

Hotpoint

Hotpoint MTAA 24S User manual

Hotpoint

Hotpoint FFL49 User manual

Hotpoint

Hotpoint HTS18IBSBB Manual

Hotpoint

Hotpoint HTS22GBMARCC Original instructions

Hotpoint

Hotpoint 8130 User manual

Hotpoint

Hotpoint RL175G User manual

Hotpoint

Hotpoint FF48TX User manual

Hotpoint

Hotpoint HTR16ABSL Manual

Hotpoint

Hotpoint HTH16BBSL User manual

Hotpoint

Hotpoint HSS25GFTHWW and Operating instructions

Hotpoint

Hotpoint HTM18IBPLRSA and Operating instructions

Hotpoint

Hotpoint CTX18GACWW User instructions

Hotpoint

Hotpoint 22 Series Original instructions

Hotpoint

Hotpoint FFUG 18xx x O3 User manual

Hotpoint

Hotpoint FFP187B User manual

Hotpoint

Hotpoint HotPoint CSX22D Installation instructions

Hotpoint

Hotpoint HCIH50TI1WUK User manual

Hotpoint

Hotpoint CSX22T Installation instructions

Hotpoint

Hotpoint HTS15BBM User instructions

Hotpoint

Hotpoint FF200LG User manual

Hotpoint

Hotpoint HTM17CBTSA - 16.6 cu. Ft. Top Freezer... Assembly instructions

Popular Refrigerator manuals by other brands

Bonnet Neve

Bonnet Neve SKYVIEW PLUS User instructions

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Instruction book

Sharp

Sharp SJ-BA31IEXW2-EU user manual

CORBERO

CORBERO CC2300MCW Instruction booklet

KitchenAid

KitchenAid 2205264 Use and care guide

Stengel

Stengel KU 1101 A++ user manual

NEFF

NEFF KI181 Series user manual

Hoshizaki

Hoshizaki Reach-In instruction manual

Amana

Amana ASD2524VES00 User instructions

BOMANN

BOMANN KGC 213 instruction manual

Danby

Danby DAR044A1SLDD Owner's use and care guide

Samsung

Samsung RF323TE user manual

Beko

Beko CSA31022 Instructions for use

IKEA

IKEA FROSTIG C 185 E manual

Electrolux

Electrolux ER 6821 D Instruction book

True

True TS-28 Specifications

Frigidaire

Frigidaire FSC23R5DW9 installation guide

Beko

Beko LSP4579W Instructions for use
