RGA524PW—24" Compact Gas Range

Dimensions (in inches) Installation Information (in inches)

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

Electrical Rating: 120V, 60Hz, 5A

Installation Information: Before

installing, consult installation

instructions packed with product

for current dimensional data.

CANADIAN GAS ASSOCIATION

R APPROVED

24 24

36

40-1/2

40-1/4*

*Depth including up-front 

angled control panel

2

0

6

2

1-1/2

23

30" Min.

24-3/8

A

Electrical 

Connection 

Area

Gas Hookup

Area

Check local codes 

before making 

connections

13" 

Max.

36

11

18" Min.

92

33

For answers to your GE Monogram,™GE Profile,™

GE, Hotpoint and RCA appliance questions, call

GE Answer Center®service, 800.626.2000.

Created 8/96

RGA524PW—24" Compact Gas Range















Features and Benefits

•Available In White and Almond

• Recessed Lift-Up Cooktop

• Standard Clean Oven

• Standing Pilot Ignition System

• Push-To-Turn Controls

• Round Grates

• Separate Broiler Drawer (With Tip-Down Door)

• Porcelain-Enameled Broiler Pan With Grid

• 2 Oven Shelves

• Solid Color-Matched Porcelain-Enameled Oven Door

• Also Available With Electronic Ignition as Model RGA524EW
