Hologic Definity User manual

Deﬁnity™Cervical Dilator

SYSTEM OVERVIEW

QUICK REFERENCE GUIDE

PLUNGERDILATION ZONE

CHARGE ZONE

(GREEN)

STOPCOCK

RELEASE

BUTTON

LUER

CONNECTOR

LOCKING NUT

10CC MARK

PRESSURE

INDICATOR

PROXIMAL HANDLE

ACORN TIP

DISTAL HANDLE

DILATION QUICK SETUP | Preparing the Dilator

FILL the ination device with 10cc of sterile saline

CONNECT the inflation device to the dilator catheter

CHARGE the outer balloon by rotating the plunger

clockwise until the pressure indicator is

within the charge zone (green)

RETRACT the outer balloon and now

you’re ready for dilation

PREPARE the outer balloon by pushing

the proximal handle forward

1-2 cm

are trademarks or registered trademarks of Hologic, Inc. and/or its subsidiaries in the United States and/or other countries.

IMPORTANT SAFETY INFORMATION

The Deﬁnity™ cervical dilator catheter system is intended to be used whenever cervical softening and dilation is desired.

Some examples are: treatment of cervical stenosis, IUD placement and removal, placement of instruments for intrauterine

radiotherapy, endometrial biopsy, global endometrial ablation, uterine tissue removal, uterine curettage, diagnostic

hysteroscopy, operative hysteroscopy. This device is not intended for use in the induction of labor. Use of the Deﬁnity

cervical dilator catheter system is contraindicated in patients with: an active genital tract infection such as genital

herpes, pelvic structure abnormality that prevents passage of the device, or invasive cervical cancer. This device is also

contraindicated for the induction of labor.

QUICK REFERENCE GUIDE

This Quick Reference Guide is designed to be used in conjunction with, not to replace, the Deﬁnity cervical dilator Instructions for

Use. Prior to performing the dilation, the physician must review and be familiar with the full operating instructions for the Deﬁnity

cervical dilator, as well as any warnings, contraindications, and safety information.

Deﬁnity Cervical Dilator

SYSTEM OVERVIEW

DILATION QUICK SETUP | Performing the Dilation

INSERT the Definity cervical dilator

ensuring the Acorn tip is snug

against the cervix

DEPLOY the inner balloon by rotating the plunger

until the pressure indicator drops below the

charge zone (green)

ROTATE the stopcock 90 degrees

COMPLETE the dilation and remove

DILATE by slowly turning the plunger

until the pressure indication is

in the dilation zone (blue)
