Hizero F801 User manual

4-in-1 Bionic Mop

4-in-1 Bionic Mop (F801)

User Manual

www.hizero.com

Bringing the

World into

Bionic Cleaning

Era

Take out the trash container Open the cleaning head cover to take out the trash container.

Insert the cleaning roller

Insert the battery

Place the lower body on its side, nd the drive motor and gently pull it out to a right angle (not to exceed 45°), insert

the cleaning roller onto the drive motor, then push into the cleaning head till the lateral button in place.

Note:

1. For the rst use, make sure to soak the cleaning roller till soft before inserting it onto the drive motor. (Refer to

Section 2 Assembling on Page 6)

2. During daily use, in case the cleaning roller becomes dry, soak the cleaning roller till soft.

Insert the trash container

Place the lower body in an upright position, open the cleaning head cover, insert the trash container and press it

in place, then place one new disposable trash container optional and close the cleaning head cover.

Assemble the upper and lower body

Remove the quick-mount screw from the handle, then insert the handle onto the lower body of the appliance

properly. Insert the quick-mount screw and tighten it with a coin or screwdriver.

Insert the battery into the battery compartment on the lower body and tighten the screw with a coin or screwdriver.

Assembling

Quick Start Guide

MAX

45°

Lock

Assemble the charging base

Ready for use

Fill the clean water tank Unlock the product

Insert the clean water tank Enjoy your cleaning Empty the dirty water tank

Take out the dirty

water tank

Throw away the

used disposable

trash container

Connect the two components of the charging base.

Connect the power adapter, and the excess power line can be stored in the cable slot.

To ensure effective cleaning, make sure that the hard waste to be

collected is in front of the cleaning head.

Maintenance & Cleaning

Maximise your Hizero's cleaning power by maintaining the product regularly. See Section 5

Maintenance&Cleaning on page 10 for more instructions and tips.

Check whether it is necessary to charge the product rst (blue battery indicator means a full battery)

before use. The charging time is a maximum of 4 hours.

Use Guidance

MAX

40℃

Unlock

4 Hours

Handle

Display Panel

Upper Body

Lower Body

Decorative Light

Cleaning Head

Trash Container

Brush Roller

Lateral Button of Cleaning Roller

Cleaning Roller

Release Button for the

Cleaning Head Cover

Body

Li-ion Battery

Clean Water Tank

Dirty Water Tank

Cap of the clean water tank

Product Label

Power Contactor

Locating Stud

Charging Base

Hand Lifting Position

Charging Contactor

Latch Locator

Spindle

Release Button for

the Clean Water Tank

Cap of the dirty water

tank (With Sensor)

Release Button for the

Dirty Water Tank

Auxiliary Wheel

Body Quick-Mount Screw

Battery Quick-Mount Screw

Product View

Battery Indicator

Mode 2 (Extra water)

Mode 1 (Normal)

Indicator for empty

clean water tank

Indicator for full dirty

water tank

Cleaning Roller Status Indicator

Brush Roller Status Indicator

Mode Button

Power Button

Lock of Cleaning Head Cover

Lateral Button of

Brush Roller

Release button for the

Cleaning Head Cover

Filter Assembly

Charging

In Use

Flashing Red: The product is charging.

Flashing Blue: Something is wrong and contact the Customer Service Centre for a

solution.

Solid Blue: The product is charged fully.

Flashing red: Too low battery to continue working.

Solid red: Low battery and the product will automatically power off within 3 minutes.

Solid blue: Sufficient power.

Mode 2: Extra mode, the appliance will use more water. A full tank (500ml) of clean water can be used for approximately 5

minutes (half the time)

Mode 1: Normal mode, the appliance will use less water. A full tank (500ml) of clean water can be used for approximately 10

minutes (should be used for regular clean)

Flashing: The water in the clean water tank is insufficient. The product will stop working and automatically switch-off

after 30 seconds.

Solid red: Something is wrong and contact the Customer Service Centre for a solution.

Flashing: A. The dirty water tank is full.

B. The sensor on the cap of the dirty water tank is dirty.

Solid red: A. The dirty water tank may not be inserted properly.

B. Something is wrong and contact the Customer Service Center for a solution.

Flashing: Maybe the cleaning roller is jammed by foreign object.

Solid red: Replace the cleaning roller with a new one roller has reached end of life,to reset press the mode button till the

indicator goes out.

Flashing: The cleaning head cover is not closed properly.

Solid red: A. Maybe the brush roller is jammed by foreign object

objects. B. Something is wrong and contact the Customer Service Center for a solution.

Solid blue: All is normal

Solid red: Something is wrong and check the display panel for more information.

(Extra water)

(Regular)

Table of Contents

1 Introduction

1.1 Safety Instructions

1.2 Technical and Security Specications

1.3 Self-Protection System

1.4 Intended Use

1.5 Floor Maintenance

3 Preparation

3.1 Charging

3.2 Remove Large Objects Off the Floor 3.3

Filling the Clean Water Tank

3.4 Locking the Body

4 Operation

4.1 Unlock the Body

4.2 Start Cleaning

4.3 Indicator for A Full/Empty Water Tank

4.4 Empty the Dirty Water Tank

4.5 Empty the Trash Container

4.6 Self-Protection System

5 Maintenance & Cleaning

5.1 Maintenance

5.2 Clean the Water Tanks

5.3 Clean the Brush Roller

5.4 Clean the Cleaning Roller

5.5 Clean the Trash Container

5.6 Clean the Cleaning Head Cover

5.7 Clean the Water Sink Drain

5.8 Clean/Replace the Filter Assembly

6 Storing & Moving

6.1 Storing

6.2 Moving

7 Replacing

7.1 Replace the Brush Roller

7.2 Replace the Cleaning Roller

2 Assembling

8 Ordering Accessories

9 Caring for the Environment

10 Warranty & After-sales

11 Troubleshooting

1 Introduction

Thank you for choosing HIZERO 4-in-1 Bionic Mop!

HIZERO 4-in-1 Bionic Mop is an intelligent oor cleaning

machine based on innovative bionic technologies, which

perfectly integrates the functions of sweeping, mopping, drying

and cleaning roller's self-cleaning. Its advent is honored as “The

second revolution in the oor cleaning eld”. The product has

a built-in rechargeable battery and when cleaning the floor, the

cleaning roller while can separate the solid trash from the liquid

one, simultaneously,self-cleaning the roller. After use, all that

needed is to discard the disposable trash container and empty

the dirty water tank. It is featured by extremely high cleaning

efficiency, simple operation and easy maintenance.

In this user manual, you will learn some tips to make the cleaning

job as easy and efficient as possible.

Please read this user manual carefully before you use the

product and save it for further reference.

1.1 Safety Instructions

1.1.1 Danger

•To prevent electric shock, never move the product over

floor/wall/plugged power cords.

• Keep all parts of the human body or large objects such as

clothes away from the cleaning roller.

1.1.2 Caution

• The product must be removed from the charging base

before cleaning or maintaining.

• Always switch off the product before you remove water

tanks or open the cleaning head cover.

• To avoid any hazard, do not let the product clean

sharp objects.

• To avoid any damage, never immerse the body of the

product in water or any other liquid, nor rinse it

under the tap.

• Never use the product to clean ammable or combustible

liquid and do not put ammable or combustible liquids in the

clean/dirty water tank.

•

Regularly check the product and all parts, stop using if the

product or the charging base is damaged, and bring it to an

authorized service center.

This product is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been

given supervision or instruction to use the product by a

person responsible for their safety.

Children should be supervised to ensure that they do not play

with the product.

• Never store the product at a temperature lower than 0°C/32°F.

• Use only clean water or clean water with HIZERO cleaning

solution in theclean water tank of the product.

•Do not put acetic acid (vinegar) or unauthorized detergent in

the water tanks nor use the product to clean them.

• Do not put wax, oil or floor maintenance products that cannot

be diluted in the clean water tank, or use the appliance to clean

them.

• The model of the battery pack is F8Z-BTA01/F8Z-BTA02/F8Z-

BTA03.

•Only change the product on original Hizero charging base.

• Never use the battery for other purposes other than this

product, and never expose it to heat (50°C/122°F+), outdoor or

wet conditions.

•When removing or replacing the battery, keep the terminals

away from other metal objects like nail clips, keys, bails, screws,

etc. to avoid any thermal effect, smoke, fire or even explosion.

• Stop using the battery in case of leakage and call the Customer

Service Center for special battery treatment immediately.

•Do not disassemble the battery without authorization in case of

any abnormal situaton.

•Do not discard used batteries at will as special battery

treatment or recycling shall be required.

• Use only HIZERO authorized cleaning solution to prevent any

damage to internal components.

•Never clean the cleaning roller with a sharp object, or the roller

may be damaged while the cleaning performance may be

reduced.

•When there is water in the water tanks, never put the product

on its side or upside down in order to prevent any leakage.

• Clean the dirty water tank after every use to prevent the

bacteria breeding or odour.

•Do not clean the cleaning roller, brush roller or water tanks in a

dishwasher or washing machine.

• This product is intended for the indoor use only.

1.2 Technical and Security Specications

This product complies with the current recognized electrical

product technical specications and safety regulations.It is

safe to use the product if the user operates according to the

instructions of this user manual.

1.3 Self-Protection System

The product is equipped with an active protection system, and

it will stop working and alert automatically if large objects like a

towel or a patch of a curtain are rolled and stuck.

1.4 Intended Use

The product is used for water-proof

hard oors (tile, marble, wooden, etc.)

only. Do not use this product to clean

carpets or other oors that are water-

sensitive.

Note: Do not use the product for carpet.

1.5 Floor Maintenance

Follow the cleaning and maintaining instructions of the user

manual, and simultaneously refer to the maintenance description

of your oors.

HIZERO cleaning solution can be used to advance the cleaning

performance. Do not add any unauthorized oor-care product

into the water tank.

2 To open the cleaning head, press the "PRESS" button on

the cleaning head cover to open the cover, then take out the

trash container.

3 Close the cleaning head cover, put the lower body on its side

on at ground and make sure the lateral button of the cleaning

roller is on the upside.

2 Assembling

1 Open the package and take out the cleaning roller. Before

installation, please immerse the whole cleaning roller in clean

water (recommend 15°C-40°C), and evenly squeeze the entire

body of the cleaning roller until the body is completely soft.

Then, take out the soft cleaning roller and squeeze the excess

water out to prepare for the following installation.

Note: If the appliance fails to start after the

connection, please try again to insert the handle

onto the lower body and restart the appliance.

4 Insert the cleaning roller onto the drive motor (note: the

maximum open angle of the drive motor is 45°), gently push and

x it into the cleaning head till the lateral button is in place.

8 Insert the quick-mount screw into the bolt hole on the

handle of the appliance and tighten it.

9 Insert the battery into the battery compartment on the lower

body, tighten the screw with a coin or screwdriver and make sure

the battery is installed well.

10 Assemble the two parts of the charging base . Connect the

power adapter and put the excess power line in the special cable

slot.

5 Place the lower body in upright position, open the cleaning

head cover, insert the trash container and press it into place,

then place a new disposable trash container optional. Close

the cover until you hear a click to ensure the cover is closed

well.

6 Push the lower body forward lightly until you hear a

click which means the product is locked in a right position.

7 Take out the handle and remove the body quick-mount

screw first. Then gently insert the handle onto the lower body

and make sure the handle and the lower body of the appliance

are connected closely.

3 Preparation

3.1 Charging

1 Make sure the charging base and power adapter are

connected well and plug the adapter in a properly grounded

outlet.

2 Place the product on the charging base and clasp the

latch locator onto the locating stud. The battery indicator will

flash red to indicate the product is charging.

3 4

1 2 3

3 4

3 Before first use, please check if it needs charge, and if

needed, charge the product to full power (it needs a maximum of

4 hours to a full charge).

3 Turn the cap clockwise to tighten it and install back the clean

water tank into the product and make sure it is installed well.To

prevent the product from toppling over, hold it upright with one

hand and place the clean water tank with your other hand.

Note: For your safety, please keep the charging base in a dry

situation and do not touch the charge port. Note: To avoid the water tank from sliding out during

cleaning, please make sure it is locked.

Note: If detergent is needed, only HIZERO cleaning solution is

allowed. And adding the cleaning solvent/tablet must follow the

related use instruction before lling in clean water.

Note: During locking or unlocking, the click sound is normal.

Hold the handle of the product, push it forward lightly until you

hear a click which means the product is locked well.Do not push

it any further, or it will damage the product.

Fill the clean water tank before every use.

3.2 Remove Large Objects Off the Floor

Before using the product, remove large objects such as toys,

power cords and shoes.

3.4 Locking the Body

3.3 Filling the Clean Water Tank

1 Press the release button while pulling the clean water tank

to take it out. To prevent the product from toppling over, hold it

upright with one hand and take out the clean water tank with

your other hand.

2 Turn the cap anticlockwise and remove it from the clean

water tank. Fill the clean water tank with cold or warm water

(should not be higher than 40°C/104°F). If needed, HIZERO

cleaning solution may be added (refer to Section 1.5 Floor

Maintenance).

4 Operation

Lift up the product from the charging base, hold the handle and

x the cleaning head with one foot, then slowly pull back the

body until you hear a click which means the body is unlocked.

Press the power button to start the product.

4.1 Unlock the Body

LOCK

Note: To avoid the water tank from sliding out during cleaning,

make sure it is placed and locked well. To avoid any bad

connection, make sure to wipe the metal sensor plate with a

soft and dry cloth.

4.3 Indicator for A Full/Empty Water Tank

4.4 Empty the Dirty Water Tank

4.2 Start Cleaning

1 Make sure that the hard waste to be collected is always in

front of the cleaning head, or it may not be cleaned effectively.

1 Press the release button for the dirty water tank to take it

out. To prevent the product from toppling over, hold it upright

with one hand and take out the dirty water tank with your other

hand.

2 To easily remove the cap of the dirty water tank, hold the

cap and pull it up lightly from the front to the back as the below

picture shows. Then slowly pour out the dirty water and be

careful of dirty water overow as well as spilling.

3 Rinse the empty dirty water tank and its cap under the tap

and and wipe the metal sensor plate with a soft and dry cloth.

Then place the tank back into the product. To prevent the

product from toppling over, hold it upright with one hand and put

the dirty water tank with your other hand.

2 To avoid inefcient cleaning, the cleaning path shown in the

following pictures is recommended.

3 To remove stubborn stains, move the product back and forth

repeatedly.

4 Do not lay the product as

the picture shows.

5 If the cleaning roller is stuck by foreign objects, press

the power button to switch off the product immediately.

1 The indicator will ash when

the clean water tank is empty. At

this time, switch off the product

and ll the clean water tank ( refer

to Section 3.3 Filling the Clean

Water Tank). Then re-start the

product.

2 The indicator will ash and the

product will stop working when the

dirty water tank is full. Empty the

dirty water tank (refer to Section

4.4 Empty the Dirty Water Tank

) and re-start the product.

Other manuals for F801

Table of contents

Other Hizero Steam Cleaner manuals

Hizero

Hizero F801 User manual

Popular Steam Cleaner manuals by other brands

Oreck

Oreck STEAM-IT STEAM100LRH user guide

Beautural

Beautural YPZ-146 instruction manual

MPM

MPM MZP-02 user manual

Electrolux

Electrolux Refine 500 instruction manual

Kärcher

Kärcher SC 3 Premium operating instructions

Shark

Shark PRO Steam & Spray Quick start guides

Jula

Jula 802-337 installation instructions

Haan

Haan Floor Sanitizer MS-30 user manual

Black & Decker

Black & Decker HSM13E1 instruction manual

HOFFEN

HOFFEN GS-1231 instruction manual

POLTI

POLTI VAPORETTO SYSTEME PRO Instructions for use

eta

eta AQUASIM PRO Instructions for use

Maxwell

Maxwell MW-3715 G Manual instruction

VAPamore

VAPamore Primo MR-100 Instruction handbook

Bestron

Bestron AZQ016 instruction manual

Nilfisk-ALTO

Nilfisk-ALTO Steamtec 312 operating instructions

Tempo di saldi

Tempo di saldi SPINSCRUBBER Use and maintenance manual

DOMENA

DOMENA HYGIAFLOR instructions
