HITESCA CCHIA/CCHIBA 301 Installation guide

Installation, Operation and Maintenance Manual

03.17 207529 Rev.100

CSTIA/CCHIA │ CSTIBA/CCHIBA

AUTONOMOUS AIR-AIR ─ SPLIT HORITZONTAL INVERTER UNITS

Models: 301

Cooling Capacities: from 1,3 kW to 8,3 kW

Heating Capacities: from 1,2 kW to 8,1 kW

ONLY COOLING

SOLO FRIO

HEAT PUMP

Thank you for trusting in Hitecsa Products. Our company has been offering the market an extended range of specialized units for

air conditioning and cooling installations for over 30 years. Our approach is based on efficiency, adaptability, usability and practical

solutions. This has been the hallmark of our product catalogue.

The versatility of our factory allows us to contribute solutions, almost tailored to each project’s specifications, in search of a solution

to every problem that arises in design and implementation of air conditioning installations.

From all of us at Hiplus Aire Acondicionado, once again, thank you very much.

03.17 207529 Rev.100

CSTIA/CCHIA –CSTIBA/CCHIBA

SPLIT HORITZONTAL INVERTER UNITS

AUTONOMOUS AIR-AIR

INDEX

INTRODUCTION................................................................................................................ 4

CONTENTS ..............................................................................................................................4

REGULATIONS AND CERTIFICATIONS .....................................................................................4

SAFETY PRECAUTIONS...................................................................................................... 5

RECEPTION....................................................................................................................... 6

INSPECTION UPON RECEIPT....................................................................................................6

RIGGING .................................................................................................................................6

STORAGE ................................................................................................................................6

INSTALLATION LOCATION ................................................................................................ 7

SERVICE AREA (MM) ................................................................................................................7

CCHIA/CCHIBA 301 ........................................................................................................ 7

CSTIA/CSTIBA 301 .......................................................................................................... 7

WEIGHT DISTRIBUTION (KG)....................................................................................................8

UNIT SETTLEMENT..................................................................................................................8

START-UP ......................................................................................................................... 9

OPERATION LIMITS...............................................................................................................10

DRAINAGE ............................................................................................................................11

AIR DUCTS.............................................................................................................................11

COMPRESSOR LUBRICANT....................................................................................................11

TECHNICAL DATA ........................................................................................................... 12

DIMENSIONS .................................................................................................................. 14

CSTIA/CSTIBA 301.................................................................................................................14

CCHIA/CCHIBA ......................................................................................................................15

COOLING CIRCUIT .................................................................................................................16

DISCHARGE LINES .................................................................................................................16

LINES POSITION ....................................................................................................................16

REFRIGERANT CHARGE .........................................................................................................18

MAINTENANCE............................................................................................................... 19

APPENDIX: SAFETY DATA R410A .................................................................................... 20

CSTIA/CCHIA –CSTIBA/CCHIBA

03.17 207529 Rev.100

CSTIA/CCHIA –CSTIBA/CCHIBA

SPLIT HORITZONTAL INVERTER UNITS

AUTONOMOUS AIR-AIR

INTRODUCTION

CONTENTS

The contents of this manual are designed to assure the correct installation, adjustment and

maintenance of the unit, therefore:

Read the instructions with due care and attention.

The appliance must be installed, tested and serviced by properly qualified staff licensed in accordance with the

established legislation.

The manufacturer declines all liability and warranty coverage is automatically waived, if electrical and/or mechanical

modifications to the unit. Tampering and unauthorized repairs or modifications to the unit will automatically void the

warranty.

Observe the safety regulations in force at the time of installation.

Make sure that the characteristics of the mains network conform to the data on the serial number plate placed on the

unit.

Keep this manual and the wiring diagram with care and make sure that they are available for consultation by the

operator whenever necessary.

Packing materials (plastic wrappings, expanded polystyrene, etc) are potentially hazardous and must be kept out of

reach of children. Recycle packing materials in accordance with local legislation.

The units must be used only for the purpose for which they are designed .The manufacturer bears no responsibility

in the case of applications other than the specified use.

Disconnect the unit in the event of breakdowns or malfunctions.

If repairs are necessary, use only HITECSA approved service centres and always insist on original spare parts. The

use of non-original parts and/or unauthorized service centres may result in unsafe operation of the unit.

REGULATIONS AND CERTIFICATIONS

ISO 9001:2008 CERTIFICATION: HILPUS AIRE ACONDICIONADO S.L., trying always to find the customer satisfaction,

has obtained the ISO 9001:2008 Quality System referred to its production activity. This will results in a continuous

determination to improve quality and reliability of all our products; commercial activities, design, raw materials, production

and after-sales service, are the means to reach our goal.

CE MARKING: Our machines have got the CE mark, in conformity with the essential requirements of the applicable EC

directives and their last modifications as well as with the national legislation of each country.

03.17 207529 Rev.100

CSTIA/CCHIA –CSTIBA/CCHIBA

SPLIT HORITZONTAL INVERTER UNITS

AUTONOMOUS AIR-AIR

SAFETY PRECAUTIONS

Installation and maintenance of air conditioning equipment can be dangerous because the system is under pressure,

because some of its elements have high temperatures and include electrical components.

Only qualified and trained service staff should install, commission and carry out maintenance works. Unqualified staff

should only carry out basic tasks such as cleaning and replacement of filters, etc.

In every visit, all precautions should be taken into account: those recommended in the Installation, operation and

maintenance instructions, as well as the ones indicated in labels of the unit. Do not forget to strictly follow any other

safety codes.

Use safety glasses, work gloves and any other safety accessory necessary.

For brazing operations use a quenching cloth and have at close distance a fire extinguisher.

When repairing the unit, use only original spare parts and install them properly in the same position where old parts

were placed.

The equipment is designed to work with 100% recirculated air. For installations with external air supply, consult our

commercial department.

Do not install the unit in explosive atmosphere.

Before starting installation, service or maintenance, turn off the main power switch in

order to avoid electrical shock that may cause personal damages.

03.17 207529 Rev.100

CSTIA/CCHIA –CSTIBA/CCHIBA

SPLIT HORITZONTAL INVERTER UNITS

AUTONOMOUS AIR-AIR

RECEPTION

INSPECTION

Units are delivered with special protective packing; therefore when it arrives, please inspect it carefully to check that

no damage has occurred during transport and that the unit has been supplied complete with all parts specified in the

order. If any damage is found, immediately file a claim with the transport company. (first 48h)

Verify the correct voltage of the nameplate and make sure it’s in accordance with local power supply.

In case of any flaw or anomaly detected, please contact HITECSA.

RIGGING

Before moving the unit, make sure that all panels are well fixed.

Raise and set down the equipment carefully.

Do not tilt the unit more than 15 degrees during transportation (Fig. 2).

When lifting the unit, make sure that it’s balanced and stable; bear in mind that the heaviest part is where the

compressor is installed.

STORAGE

If the equipment is going to be stored please follow the instructions below in order to avoid damages, corrosion or

deterioration:

Keep the unit away from direct sunlight, rain, sand, wind or temperatures above 50ºC.

Storage temperature: maximum 50ºC, minimum -15ºC.

Maximum humidity: 90%.

03.17 207529 Rev.100

CSTIA/CCHIA –CSTIBA/CCHIBA

SPLIT HORITZONTAL INVERTER UNITS

AUTONOMOUS AIR-AIR

INSTALLATION LOCATION

Check if the base is able to support the weight of unit during operation.

Reserve a minimum service area.

Choose a place free of dust or any other foreign material that could clog or damage the condenser coil. The location

should also be a place that cannot be flooded.

Consult and respect all regulations concerning installation of air conditioning systems.

Install anti-vibration supports to avoid noise transmission.

SERVICE AREA (mm)

CCHIA/CCHIBA 301

CSTIA/CSTIBA 301

03.17 207529 Rev.100

CSTIA/CCHIA –CSTIBA/CCHIBA

SPLIT HORITZONTAL INVERTER UNITS

AUTONOMOUS AIR-AIR

WEIGHT DISTRIBUTION (kg)

UNIT SETTLEMENT

Make sure that the unit is correctly levelled.

The bed frame should be strong and solid enough to support the weight of the machine.

Verify that the water drain of the indoor is working properly.

CSTIA-CSTIBA

TOTAL

301

CCHIA-CCHIBA

TOTAL

301

150

CSTIA/CSTIBA 301

CCHIA/CCHIBA 301

03.17 207529 Rev.100

CSTIA/CCHIA –CSTIBA/CCHIBA

SPLIT HORITZONTAL INVERTER UNITS

AUTONOMOUS AIR-AIR

START-UP

Start-up should be performed by qualified technical people.

Use a start-up check list: record inlet and outlet temperaturesof the indoor coil, volts and amps of each compressor

and fan motor, suction and discharge pressure of each compressor.

Remember that after the first 4 hours of operation, it is necessary to clean the filters.

Monitor at least 3 cooling cycle operations.

Due to the unit has frequency converters for compressor and fans, it’s essential that the differential supply be at

minimum 300 mA to prevent supply cuts caused by the differential switch.

Check the following points:

Electrical connections are well tightened.

Panels are firmly secured with screws.

There are no oil or refrigerant leaks.

The unit is correctly leveled.

There is enough space for service and maintenance.

Drainage is not blocked.

If outdoor temperature is under 25ºC, verify the crankcase heater of the compressor.

Air filters are clean and correctly mounted.

Grilles, air diffusers, air ducts and flexible connections are in good condition.

Electrical power source is in accordance with what is said in the nameplate.

Fans rotate in the right direction.

BEFORE START-UP

EVAPORATOR

CONDENSER

1. Power Supply 230/I/50 + T

2. Circuit Breaker

3. Th-Tune Termostat

4. Electrical Panel

Belden Comunication Cables

(Shielded and Twisted)

6. Switch

03.17 207529 Rev.100

CSTIA/CCHIA –CSTIBA/CCHIBA

SPLIT HORITZONTAL INVERTER UNITS

AUTONOMOUS AIR-AIR

OPERATION LIMITS

OUTDOOR AIR

INDOOR AIR

DRY

WET

DRY

WET

COOLING

ºC

Standard

35ºC

27ºC

19ºC

Minimum

18ºC

19ºC

15ºC

Maximum

48ºC

32ºC

23ºC

HEATING

ºC

Standard

7ºC

6ºC

20ºC

Minimum

-10ºC

-11ºC

20ºC

Maximum

24ºC

18ºC

27ºC

Units can operate at a maximum altitude of 1.500 meters.

For other conditions, please consult.

These units are designed to work with 100% recirculated air. The installation with 100% outdoor air is prohibited. See

application limits.

Main power supply of the unit should agree with the data shown on the nameplate. HITECSA will not be held

responsible for damages resulted from non observance of the above.

Always use the wiring diagram sent with the unit to make electrical connections

Check that the crankcase heater has been working at least 24 hours prior to the start-up of the unit.

Power supply should be within 10% of Volts indicated on the unit nameplate.

Do not operate the unit at different voltage from that shown on the unit nameplate.

The installer should put line protection elements in compliance with current legislation.

The interconnecting wires should be protected with a tube or put inside a groove channel.

Before starting installation, service or maintenance, turn off the main power switch in

order to avoid electrical shock that may cause personal damages.

This manual suits for next models

Table of contents

Other HITESCA Heat Pump manuals

HITESCA

HITESCA ECHBA 201 Instruction manual

Popular Heat Pump manuals by other brands

MICROWELL

MICROWELL HP 1000 GREEN Installation and user manual

Sanyo

Sanyo SAP120FCH Service manual

Daikin

Daikin EHYHBH05AA Operation manual

Panasonic

Panasonic WH-SDF03E3E5 Design handbook

Bryant

Bryant 544B Specifications

Airxcel

Airxcel 45000 Series Installation, operation and maintenance instructions

Mitsubishi Electric

Mitsubishi Electric PUZ-SWM60VAA Service manual

Dimplex

Dimplex LI 16I-TUR Installation and operating instruction

Carrier

Carrier WSHP Open v3 Integration guide

TGM

TGM CTV14CN018A Technical manual

Carrier

Carrier 38MGQ Series installation instructions

Kokido

Kokido K2O K880BX/EU Owner's manual & installation guide

Viessmann

Viessmann VITOCAL 300-G PRO Type BW 2150 Installation and service instructions

Carrier

Carrier 48EZN installation instructions

Viessmann

Viessmann KWT Vitocal 350-G Pro Series Installation and service instructions for contractors

Ariston

Ariston NIMBUS user manual

Weishaupt

Weishaupt WWP L 7 Installation and operating instruction

GE Zoneline AZ85H09EAC datasheet
