Hitachi L32C205 User manual

Owner’s Guide

Model L32C205

32” Class (31.51” Diagonal)

L32C205_OR-OG_cover.indd 6 7/5/11 3:03:36 PM

IMPORTANT SAFETY INSTRUCTIONS....................................................................... 2-6

HOW TO ATTACH / REMOVE THE STAND..................................................................... 7

FIRST TIME USE

.......................................................................................................

10-13

TV OPERATION ........................................................................................................ 14-18

CONNECTIONS TO OTHER EQUIPMENT ..............................................................19-21

TROUBLESHOOTING ................................................................................................... 22

SPECIFICATIONS.......................................................................................................... 23

LIMITED WARRANTY............................................................................................... 24-25

END USER LICENCE AGREEMENT FOR HITACHI DTV SOFTWARE ..................26-27

APPENDIXES................................................................................................................. 28

Thank you for purchasing this Hitachi product. Please read these instructions carefully.

For additional assistance please call 1-888-333-1899(U.S.A. or Puerto Rico), or 01-800-700-4321(Mexico)

or visit our website at www.hitachi.us/tv.

Keep this owner’s guide for future reference.

Record the model number and serial number of your LCD Television for future reference.

This information is located on the back of the television.

MODEL NUMBER SERIAL NUMBER

TABLE OF CONTENTS

4 inches

The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause overheating. Do not block

ventilation holes, or set up near radiators. Do not place in direct sunlight. When placing on a shelf leave 4 inches (10 cm) free space

around the entire unit.

Notes when mounting the LCD TV on a wall

If the unit is to be mounted on the wall, contact the retailer where you purchased the LCD TV for advice, and have the equipment pro-

fessionally installed. Incomplete or improper installation may cause injury to you, and/or damage to the LCD TV.

The screws ISO M6 thread type should be used. The insertion length must be within 12 - 16mm.

If the insertion length is less than 12mm, the weight can not be maintained.

If the insertion length is more than 16mm, a space is created between the Wall Mount Bracket and the Television.

(Insertion Length) = (Screw Length) - (Washers Thickness) - (Mounting Bracket Thickness)

Securing to a Wall

1. Use metallic wire, clamp and screw (not provided) on the rear of the LCD TV as shown below.

2. Use proper hardware (drywall anchor, masonry screw, etc) to secure other end of wire to wall.

NOTICE FOR TV CABINET

If the unit is to be mounted on a cabinet smaller than the length of the unit, it could result in an unstable location and the unit may tumble

over, making a risk of personal, possibly fatal injury. Also, this would damage the product seriously. Accordingly, Hitachi accepts no

responsibility or liability for any injuries or property damage resulting from the improper installation.

YES !! NO !!

SAFETY PRECAUTIONS

YES!! NO!!

4 inches

Wire

Screw（M6×12）

Clamp

1.Lay the soft cloth on a table which can hold the weight of the whole TV.

2.Put the TV on the cloth with its back upwards and the LCD downwards.

3.Take out the pedestal,and insert the pedestal into the TV then put the pedestal,to relevant position of the TV set,until all

the holes match each other completely.

4. Fasten the pedestal and the TV set together with screws.

5. Erect the TV set,and put it on the proper position for watching.

The below figures are for reference only,please refer to the actual units to determine the appearances.

Every hole of the pedestal must be fastened with screws!

above

End User License Agreement

COMPONENT

POWER
