Hitachi DB3DL2(HL) User manual
• Lightweight and ergonomic slim soft grip
handle ensures comfort and reduces user
fatigue
• Compact size with convertible action from
straight to angled ensures convenient use
• Manual tightening mechanism allows model
to be used as a manual screwdriver
• Lock button to prevent inadvertent motor
start up
• Tool features multiple protection circuit that
protects the battery & tool from overload, over
heat, over discharge & over charge
• 21 stage adjustable clutch
• 2 speed gear box
• Ultra bright white LED for improved visibility
DB3DL2(HL)
3.6V Cassette Pencil Driver Drill
Specifications
Max. torque 5Nm
No load speed 200 / 600 (min-1)
Weight 0.45kg (with EBM315 battery)
Length Straight: 268mm / Angled : 210mm
(with EBM315 battery)
Battery type EBM315: 3.6V 1.5Ah Lithium ion
cassette
Standard
accessories
2 x EBM315 batteries, charger,
driver bit and carry case
30
1.5
