Hisense HS205 User manual

Quick Start Guide

2.0 Channel Sound Bar Home Theater System

Model: HS205

What’s in the Box

Main Unit

Bracket(x2) / Wall Plug(x2) / screw(x2) / bracket screw(x2) AC Power Cord

Identifying the Parts

ENEN

71089 11 12

Product Diagram

Main Unit

1Remote Control Sensor

Receive signal from the remote control.

2 LED Indicators

• Red : In STANDBY mode.

• Orange / Orange ash : In Optical / Coaxial mode.

• Blue : In Bluetooth mode.

• White : In HDMI ARC mode.

• Green / Green ash : In LINE IN / USB mode.

3Screws

Remove the screws then install the wall

mounting screws into the back of the unit.

4(ON/OFF) Button

Switch the unit between ON and Standby mode.

5 +/- (Vol+/Vol-) Buttons

Increase/decrease the volume level.

6 (SOURCE) Button

Select the play function.

7AC~ Socket

Connect to the power supply.

8LINE IN Socket

Connect to an external audio device.

9 USB Socket

Insert the USB device to play music.

10 HDMI ARC Socket

Connect to a TV via HDMI cable.

11 COAXIAL Socket

Connect to a coaxial audio output on the TV.

12 OPTICALSocket

Connect to an optical audio output on the TV.

Remote Control /

AAA Batteries x 2

User Manual/Quick Start Guide/

Wall Mount Guide

Optical Cable HDMI Cable

1Remote control

1 Switch the unit between ON and

STANDBY mode.

2 (MUTE) Mute or resume the sound.

3 MOVIE Switch to MOVIE EQ eect.

4 MUSIC Switch to MUSIC EQ eect.

5 VOL+/VOL- Increase/decrease the volume level.

6 /Skip to previous/next track in

Bluetooth/USB mode.

7 /PAIR Play/pause/resume playback in

Bluetooth/USB mode.

Press and hold to activate the

pairing function in Bluetooth mode

or disconnect the existing paired

Bluetooth device.

8 NEWS Switch to NEWS EQ eect.

9 HDMI ARC Select the HDMI ARC mode.

10 OPT/COAX Select the OPTICAL/COAXIAL mode.

11 (BT) Select the Bluetooth mode.

12 LINE IN Select the LINE IN mode.

13 USB Select the USB mode.

Replace the Remote Control Battery

1 Press and slide the back cover to

open the battery compartment of

the remote control.

2 Insert two AAA size batteries

(included). Make sure the (+) and (–)

ends of the batteries match the (+)

and (–) ends indicated in the battery

compartment.

3 Close the battery compartment cover.

- Do not mix old and new batteries;

-Do not mix alkaline, standard (Carbon-Zinc) or

rechargeable (Ni-Cd, Ni- MH, etc.) batteries.



























Connections

6Wall Mounting

HDMI ARC OPTICALCOAXIALAUDIO OUT Headphone

●Before connecting the AC power cord, ensure you have completed all other connections.

Bluetooth( ) Operation

≤8 mm/

0.31"

4mm/

0.16"

≥35 mm/1.4"

921 MM

4Basic Operation

◎Standby/ON

When you rst connect the main unit to the mains socket,

the main unit will be in Standby mode.

• Press the button on the unit or on the remote control

to switch the unit ON.

• Press the button again to switch the unit back to

STANDBY mode.

• Disconnect the mains plug from the mains socket if you

want to switch the unit OFF completely.

Auto Wake

If a TV or an external device is connected (LINE IN /

OPTICAL / COAXIAL / HDMI ARC), the unit will switch on

automatically when the TV or the external device is

switched on.

Automatic Power O Function

The unit automatically turns to Standby mode after about

15 minutes if the TV or the external unit is disconnected,

switched o.

• To switch the unit o completely, remove the mains

plug from the mains socket.

• Please turn the unit o completely to save energy

when not in use.

◎Select Modes

Press the (SOURCE) button repeatedly on the unit or

the HDMI ARC, (Bluetooth), OPT/COAX, USB and LINE IN

buttons on the remote control to select the desired mode.

The indicator light on the front of the main unit will show

which mode is currently in use.

◎Adjust the Volume

Press the VOL+ / VOL- buttons on the unit or on the

remote control to adjust the volume.

If you wish to turn the sound o, press the (MUTE)

button on the remote control. Press the (MUTE) button

again or press the VOL+ / VOL- buttons on the unit or on

the remote control to resume normal listening.

◎Select a Preset Sound Eect

While playing, press the NEWS / MOVIE / MUSIC buttons

on the remote control to select the preset equalizers:

• MOVIE (recommended for viewing movie)

• MUSIC (recommended for listening to music)

• NEWS (recommended for listening to news)

Settings Bluetooth

Bluetooth

DEVICES

Hisense HS205

Now Discoverable

Connected

< 8 m / 27 ft

1 3

Roku TV Ready and the Roku TV Ready logo are trademarks of Roku, Inc.
