Hisense RS696N4IB1 User manual
RS696N4IB1
1
RS696N4II1
2
Contents
Safety and warning information.........2
Installing your new appliance............8
Description of the appliance............12
Display controls...............................13
Using your appliance.......................17
.......................21
.......................23
Troubleshooting...............................25
Disposal of the appliance................27
Cleaning and care....
Helpful hints and tips
This appliance is produced in accordance with the following EU
guidelines: 2 014/35/EU, 2 014/30/EU, 2009/125/EC,
EC.643/2009 and 2002/96/EC.
Safety and warning information
For your safety, before installing
and first using the appliance,
read this user manual carefully,
including its hints and warnings.
To avoid unnecessary mistakes
and accidents, it is important to
make sure that all people using
the appliance are thoroughly
familiar with its operation and
safety features. Save these
instructions and be sure that
they remain with the appliance if
it is moved or sold, so that
anyone using it, throughout its
life, will be properly informed on
its usage and safety notices.
For the safety of life and
property, keep the warnings
contained within these user's
instructions as the manufacturer
is not responsible for damages
caused by omission.
Safety for children and
others who are vulnerable
This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge if
they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved. Children shall not
play with the appliance.
Cleaning and user
maintenance should not be
carried out by children without
supervision.
Keep all packaging away
from children as there is risk of
suffocation.
3
If you are discarding the
appliance, pull the plug out of
the socket, cut the connection
cable (as close to the appliance
as you can) and remove the
door to prevent children playing
from suffering an electric shock
or from closing themselves
inside the unit.
General safety
WARNING —This
appliance is intended
to be used to be used in
domestic households and not
intended for use in retail or
commercial environments;
WARNING — The water
supply line should only be
connected to a potable water
supply.
WARNING — Do not store
explosive substances such as
aerosol cans with a flammable
propellant in this appliance.
WARNING — If the supply
cord is damaged, it must be
replaced by a qualified
electrician in order to avoid the
risk of electric shock.
WARNING — Keep
ventilation openings, in the
appliance enclosure or in any
built-in structure clear of
obstruction.
WARNING — Do not use
mechanical devices or other
means to accelerate the
defrosting process, other than
those recommended by the
manufacturer.
WARNING — Do not damage
the refrigerant circuit.
WARNING — Do not use
electrical appliances inside the
food storage compartments of
the appliance, unless they are
of the type recommended by
the manufacturer.
WARNING — The refrigerant
and insulation are flammable.
When disposing of the
appliance, do so only at an
authorized waste disposal
center. Do not expose to flame.
Refrigerant
The refrigerant isobutene
(R600a) is contained within the
refrigerant circuit of the
appliance. This is a natural gas
with a high level of
environmental compatibility,
which is nevertheless
4
flammable. During
transportation and installation
of the appliance, ensure that
none of the components of the
refrigerant circuit becomes
damaged. The refrigerant
(R600a) is flammable.
Caution:risk of fire
If the refrigerant circuit is
damaged:
-Avoid naked flames and
sources of ignition.
-Thoroughly ventilate the room
in which the appliance is
situated. It is dangerous to alter
specifications or modify this
product in any way. Any
damage to the cord may cause
a shortcircuit, fire, and/or
electric shock.
Electrical safety
3. Make sure that you can
access the main plug of the
appliance.
4. Do not pull the main cable.
5. If your wall socket is loose,
do not insert the power plug.
There is a risk of electric shock
or fire.
6. You must not operate the
appliance without the interior
lighting lamp cover.
7. The fridge should only be
supplied with single phase
alternating current of
220~240V/50Hz. If the supply
fluctuates outside this range an
automatic A.C. voltage
regulator of more than 350W
should be used. The fridge
should be plugged into an
adequately earthed supply.
1. The power cord must not be
lengthened.
2. Make sure that the power
plug is not crushed or
damaged. A crushed or
damaged power plug may
overheat and cause a fire.
Daily use
Do not store flammable gas
or liquids in the appliance,
There is a risk of an explosion.
Do not operate any electrical
appliances in the appliance
(e.g. electric ice cream makers,
mixers etc.).
5
When unplugging always pull
the plug from the mains socket.
Do not pull on the cable.
Do not place hot items near
the plastic components of this
appliance.
Do not place food products
directly against the air outlet on
the rear wall.
Store pre-packed frozen food
in accordance with the frozen
food manufacture’s instructions.
The manufactures storage
recommendations should be
strictly adhered to. Refer to
relevant instructions for
storage.
Do not place carbonated or
fizzy drinks in the freezer
compartment as it creates
pressure on the container,
which may cause it to explode,
resulting in damage to the
appliance.
Do not place food directly
against the air outlet on the rear
wall cause it to explode,
resulting in damage to the
appliance.
Frozen food can cause frost
burns if consumed straight from
the freezer compartment.
Do not place the appliance in
direct sunlight.
Keep burning candles, lamps
and other items with naked
flames away from the
appliance.
The appliance is only
intended for keeping food stuff
and/or beverages for normal
household consumption as
explained in this instruction
booklet.
The appliance is heavy. Care
should be taken when moving it
Do not remove nor touch
items from the freezer
compartment if your hands are
damp/wet, as this could cause
skin abrasions or frost/freezer
burns.
Never use the base, drawers,
doors etc. to stand on or as
supports.
Frozen food must not be
refrozen once it has been
thawed out.
6
To avoid items falling and
causing injury or damage to the
appliance, do not overload the
door racks or put too much food
in the crisper drawers.
Caution!
Care and cleaning
Before performing
maintenance, switch off the
appliance and disconnect the
mains plug from the mains
socket.
Do not clean the appliance
with metal objects, steam
cleaner, ethereal oils, organic
solvents or abrasive cleansers.
Do not use sharp objects to
remove frost from the
appliance. Use a plastic
scraper.
Installation Important!
It is advisable to wait at least
four hours before connecting
the appliance to avoid
damaging the compressor.
Adequate air circulation
should be provided around the
appliance. To achieve sufficient
ventilation, please follow the
instructions relevant to
installation.
Wherever possible the back
of the product should not be too
close flammable materials as
some components are hot in
normal operation.
The appliance must not be
locate close to radiators or
cookers.
Make sure that the mains
plug is accessible following
installation of the appliance.
For electrical connection
carefully, follow the instructions
given in this manual.
Unpack the appliance and
check for damage. Do not
connect the appliance if it is
damaged. Report possible
damage immediately to your
retailer. In this case retain
packing.
Service
This product must be serviced
by an authorized Service
Center or Service Agent, and
only genuine spare parts must
be used.
W1
130°
140°
D1
≥100
W
D
≥100
≥75
W2
Installing your new appliance
Before using the appliance for the first
time, you should be aware of the
following tips.
Ventilation of appliance
In order to improve efficiency of
the cooling system and save
energy, it is necessary to maintain
good ventilation around the appliance
for the dissipation of heat. For this
reason, sufficient clear space should
be available around the refrigerator.
Suggest: It is advisable for there to
be 75mm of space from the back to
the wall, at least 100mm from its top,
at least 100mm from its side to the
wall and a clear space upfront to allow
the freezer door to open 130°and
refrigerator door to open 140°. See
in follow diagrams. Please refer to the
diagrams below.
the
Relevant information (mm)
This appliance performs well in the
climate class from SN to T. It may not
work properly if being left at a
temperature above or below the
indicated range for a long period.
Note:
Stand your appliance in a dry place
to avoid high moisture damage.
Keep the appliance out of direct
sunlight, rain or frost. Stand the
appliance away from heat sources
such as stoves, fires or heaters.
WW1 W2 DD1
908 417.5 277 600 1142.5
7
adjusta e bottom f etbl e
adjusta e bottom f etbl e
Warning!
For proper installation, this refrigerator
must be placed on a level surface of
hard material that is the same height
as the rest of the flooring. This surface
should be strong enough to support a
fully loaded refrigerator.
The rollers, which are not castors,
should be only used for forward or
backward movement. Moving the
refrigerator sideways may damage
your floor and the rollers.
Leveling of appliance
For sufficient leveling and air
circulating in the lower rear section of
the appliance, the bottom feet may
need to be adjusted. Please use a
suitable spanner.
To allow the doors to self-close, tilt
back the top backwards at about
15mm or 0.5°by turning the
adjustable feet.
Whenever you want to move the
appliance, remember to turn the feet
back up, so that the appliance can roll
freely. Reinstall the appliance when
relocating.
0.5
15mm
Fixing the handle
Before you use the product, please
check the handle of the refrigerator. If
the handle is loose, you should fix it
with the hexangular screwdriver in the
clockwise direction, then it can be
used normally.
8
Installing the water lines and filter
Installing the water filter
Installing the filterthe water lines of
Note!
The water lines must be fully
inserted into the filter to prevent water
leaking.
Filter Holder Screw
To ,
follow the instructions of installing
steps below that referring to the
figures supplied.
install the water lines of the filter
Second,
mount the external filter. (Note: The
water filter should be mount on the
wall where it is convenient to be
replaced, and do not mount on the
wall behind the refrigerator.)
determine the location to
Third,
between the filter and the tap, and the
distance from the filter to the fridge.
Prepare lines as required lengths.
(Cut the proper lengths of water lines
which you determine to connect with
the filter inlet or outlet.)
determine the distance
Fourth, mount the filter holder onto
the wall by using a screwdriver and
attach the water filter.
Warning!
The water filter must be held upright
as shown in the figure above. It is
critical to connect the water inlet and
outlet hoses on the filter correctly.
Never mount the filter onto the
refrigerator. Coolant pipes might be
pierced.
Filter Holder
Filter
Inlet
Outlet
FLOW
First, take out the water filter and
water lines from the fridge room.
To , follow the
installing steps below.
fit the water filter
First, the 2 clips out, then pull out
the 2 stopper of the water filter.
take
Clip
Stopper
Stopper
Water Filter
It is recommended to have a
suitably qualified person to install the
product.
The line length should be less than
5m. If the water line is too long(>5m),
the ice and cold water content may be
affected due to insufficient water
pressure.
Cut the water line as required length
and avoid overbending the water
lines.
9
Clip
Connector
Water line Water line
The water lines must be connected
with the potable water only.
Note:
To operate properly, the ice maker
requires a water pressure of 207~689
Kpa.
Connect filter outlet line to the fridge
The outlet line of the water filter
should be connected with the inlet line
of the refrigerator by a Two-Way
Connector.
The water lines must be fully inserted
into the center of the connector to
prevent water leaking.
Insert the 2 clips in the install pack as
shown in the diagram, and then
confirm that each clip holds the line
firmly.
Connecting the filter inlet line to
the water supplier
Screw the adaptor onto a suitable 3/4”
BSP connector water outlet, and use
the spanner to tighten it. Fully insert
the water line into the check valve.
Then insert the clip in the install pack
as the figure shown below.
The initial dark discoloration of
water is normal.
After installed the filter, please open
the water valve to flush the filter for 5
minutes before use.
Third,
position as the figure shown below,
and confirm that each clip holds the
water line firmly.
insert the 2 clips in the proper
Clip
Water line
Water line
FLOW
Water line
Water Filter
Water line
Outlet
Inlet
Second, fully insert the water lines
into the Inlet and Outlet of the water
filter.
10
Clip
Connector
Filter inlet line
Water valve
Spanner
Check valve
FLOW
Water
The connector and the check valve is
provided as one part. You should use
the new connector incidentally but not
the old one you have.
This manual suits for next models
1
Table of contents
Other Hisense Refrigerator manuals
Hisense
Hisense RS-34WC SERIES User manual
Hisense
Hisense HRBM482SW User manual
Hisense
Hisense RS670N4AC1 Mounting instructions
Hisense
Hisense H230RTS Mounting instructions
Hisense
Hisense RS694N4TF2 User manual
Hisense
Hisense H420BMEI-WD Mounting instructions
Hisense
Hisense RT286N4ABN Mounting instructions
Hisense
Hisense RS44G1 Mounting instructions
Hisense
Hisense HR6BMFF320 Mounting instructions
Hisense
Hisense RS-11DC4SB Mounting instructions
Hisense
Hisense RF21A3FSE User manual
Hisense
Hisense RIB312F4AW1 Mounting instructions
Hisense
Hisense RR154D4AW2 Mounting instructions
Hisense
Hisense RS840N4WCF Mounting instructions
Hisense
Hisense FT237D4BW21 Mounting instructions
Hisense
Hisense RQ515N4AB1 Mounting instructions
Hisense
Hisense RS694N4TC2 Mounting instructions
Hisense
Hisense RB418D4AD2 Technical manual
Hisense
Hisense RT267D4ABF Mounting instructions
Hisense
Hisense FMN486W20S Mounting instructions
