Hioki LR8512 User manual
LR8512
LR8513
Measurement Guide
WIRELESS PULSE LOGGER
EN
Sept. 2018 Revised edition 5
LR8512B981-05 18-09H
LR8514
LR8515
WIRELESS CLAMP LOGGER
WIRELESS HUMIDITY LOGGER
WIRELESS VOLTAGE/TEMP LOGGER
i
Contents
For customers who are using the LR8410 Wireless Logging
Station ................................................................................................1
Instrument Version............................................................................2
Introduction........................................................................................3
Trademark ..........................................................................................3
Verifying Package Contents .............................................................4
Options................................................................................................5
Safety Notes.......................................................................................7
Usage Notes.....................................................................................10
1 Overview 19
1.1 Overview and Features..........................................................19
1.2 Parts Names and Functions..................................................20
2 Preparation for Measurements 21
3 Using the LR8410 as a Unit 25
3.1 Real-time Measurement Using the LR8410..........................25
3.2
Performing Real-time Measurement Using a Windows
®
PC
..26
4 Collecting Measurement Data Using a
Windows®PC 27
5 Collecting Measurement Data Using an
AndroidTM Terminal 29
LR8512B981-05
1
For customers who are using the LR8410 Wireless Logging Station
For customers who are using the LR8410
Wireless Logging Station
This instrument can be used on the LR8410 rmware version 1.30 or later.
The rmware version for the LR8410 is displayed on the system screen.
The latest version can be downloaded from our website.
For details on how to upgrade the software, see our website or check with your authorized Hioki
distributor or reseller.
2
Instrument Version
Instrument Version
The Wireless Logger Collector can be used on the instrument software version 1.20
or later.
A version older than 1.20 needs to be updated. The software can be updated in
Wireless Logger Collector (Windows® PC version).
If the software version is older than 1.20, a communication error (protocol error)
occurs in any communications attempted between the instrument and Wireless
Logger Collector.
3
Introduction
Introduction
Thank you for purchasing the HIOKI LR8512 Wireless Pulse Logger, LR8513 Wireless
Clamp Logger, LR8514 Wireless Humidity Logger, or LR8515 Wireless Voltage/Temp
Logger. To obtain maximum performance from the product, please read this manual
rst, and keep it handy for future reference.
In this manual, the name of each instrument is indicated as follows.
Product name Name indicated in the manual
LR8512 Wireless Pulse Logger
LR8513 Wireless Clamp Logger
LR8514 Wireless Humidity Logger
LR8515 Wireless Voltage/Temp Logger
Instrument
There are the following instruction manuals available for this instrument. Please refer
to the appropriate manuals for the intended usage.
Measurement Guide
(this manual)
Read this rst.
For customers who use this instrument for the rst time, this
manual describes the basic operation procedures.
Instruction Manual Describes details of the functions, operations, and specications
of this instrument.
Trademark
• Microsoft, Windows, Windows Vista, and Excel are either registered trademarks or
trademarks of Microsoft Corporation in the United States and other countries.
•Bluetooth® is a registered trademark of Bluetooth SIG, Inc. (USA).
The trademark is used by HIOKI E.E. CORPORATION under license.
• Adobe and Adobe Reader are either trademarks or registered trademarks of Adobe
Systems Incorporated in the United States and other countries.
• Android and Google Play are trademarks of Google, Inc.
4
Verifying Package Contents
Verifying Package Contents
When you receive the instrument, inspect it carefully to ensure that no damage
occurred during shipping. In particular, check the accessories, panel keys,
and connectors. If damage is evident, or if it fails to operate according to the
specications, contact your authorized Hioki distributor or reseller.
Check the package contents as follows.
Instrument
LR8512 × 1
LR8513 × 1
LR8514 × 1
LR8515 × 1
Common accessories
CD × 1
[Instruction Manual (PDF), Application Software (Logger
Utility, Wireless Logger Collector)]
The latest version of the application software can be
downloaded from our website.
Measurement Guide
Precautions Concerning Use of Equipment That Emits
Radio Waves
LR6 Alkaline battery × 2
LR8512 Accessory
L1010 Connection Cable (length approx. 1.5 m) × 2
5
Verifying Package Contents
Options
The following options are available for the LR8512, LR8513, LR8514, and LR8515.
Contact your authorized Hioki distributor or reseller when ordering.
Common options
Z2003 AC Adapter (power cord attached)
Z5004 Magnetic Strap
Z5020 Magnetic Strap
LR8512 Option
L1010 Connection Cable (length approx. 1.5 m)
LR8513 Option
9669 Clamp On Sensor
9695-02 Clamp On Sensor
CT6500 Clamp On Sensor
9657-10 Clamp On Leak Sensor
9675 Clamp On Leak Sensor
CT9691-90 Clamp On AC/DC Sensor
CT9692-90 Clamp On AC/DC Sensor
CT9693-90 Clamp On AC/DC Sensor
9219 Connection Cable (for 9695-02 connection)
CT7631 AC/DC Current Sensor
CT7636 AC/DC Current Sensor
CT7642 AC/DC Current Sensor
CT7731 AC/DC Auto-Zero Current Sensor
CT7736 AC/DC Auto-Zero Current Sensor
CT7742 AC/DC Auto-Zero Current Sensor
CT9667-01 AC Flexible Current Sensor
CT9667-02 AC Flexible Current Sensor
CT9667-03 AC Flexible Current Sensor
CT7044 AC Flexible Current Sensor
CT7045 AC Flexible Current Sensor
CT7046 AC Flexible Current Sensor
CM7290 Display Unit
For the CT7631,CT7636,CT7642,CT7731,CT7736,CT7742,CT7044,CT7045,CT7046
CM7291 Display Unit
For the CT7631,CT7636,CT7642,CT7731,CT7736,CT7742,CT7044,CT7045,CT7046
L9095 Output Cord (for CM7290/CM7291 connection)
6
Verifying Package Contents
LR8514 Option
Z2010 Humidity Sensor (Length including the sensor: Approx. 50 mm)
Z2011 Humidity Sensor (Cable length: Approx. 1.5 m)
Supported instrument
LR8410 Wireless Logging Station
(Supported for software version 1.30 and later)
