Connect the HD TunerConnect the HD Tuner
Connect the HD TunerConnect the HD TunerConnect the HD TunerConnect the HD TunerConnect the HD Tuner
3Connect the HD tuner and television terminal
4Connect the HD tuner and television
Coaxial cable (commercially available)
Telephone cord (accessory)
Telephone or
facsimile machine
If this screen is displayed,
setup is complete.
Step 1
*Please make sure to complete the tuner setup to start viewing SKY PerfecTV
!
HIKARI in high definition.
2
3桁入力
(3-digit input)
10/0 10/0
Confirm that Ch.200 and Ch.202 can be viewed
A free channel (Ch.200) that provides
information about programs and
viewing procedures will be displayed.
When connecting via terminal D cable
To D1/D2/D3/D4 video
output terminal
To D1/D2/D3/D4 video
input terminal
Television with video input terminal D
Audio/video cord (accessory)
Terminal D cable
(commercially available)
To audio/video output terminal
*No connection to the yellow video terminal is required.
To audio/video input terminal
*No connection to the yellow video terminal is required.
When connecting via HDMI cable
To HDMI input terminal
To HDMI output terminal
Television with HDMI input terminal
HDMI cable (accessory)
A video signal will not be output from terminal D when connected
to the HDMI terminal. Proceed to inside pages after
completing connection
Make sure to perform this check.
Confirm that you are receiving the channels chosen under the high-definition contract.
Now for our Now for our
amazing high-definition lifestyle!amazing high-definition lifestyle!
Now for our Now for our
amazing high-definition lifestyle!amazing high-definition lifestyle!
Finally, check
the contract!
Telephone coupler
(accessor y)
3-digit input button is here.
Channels can normally be
viewed 1 ～ 2 hours after
completing setup.
*Does not apply to some channels.
*More time may be required depending
on the reception environment.
Television
3-way
divider
(accessor y)
Please make sure to check that
the power cord is disconnected
before inserting the coaxial cable.
To telephone line terminal
To SKY PerfecTV
!
HIKARI input terminal
To terrestrial digital antenna input terminal
To BS/110-degree CS antenna input terminal
入力(Input)
出力(Output)
出力(Output)
UHF/VHF
BS/CS
テレビなど出力
(Output such as television)
To terrestrial
digital input
terminal
Wall terminal
*If you have a branching filter or dual-divider, you can
use it (if it is compatible with 2150MHz).
1
Open the SKY PerfecTV
!
HIKARI HD-compatible
tuner package
Here’s the Here’s the
HD tuner.HD tuner.
I'll put the old I'll put the old
one in the box one in the box
and return it.and return it.
2
Remove the dedicated SKY PerfecTV
!
CS digital tuner
(standard definition) used up until now
■Please make sure to check that the power cord is
disconnected before inserting the coaxial cable.
If the power cord is connected, even when the power switch
is off, a short circuit and failure may occur (converter power).
■After removing the old tuner, please place it in its original
box with attachments and return it.
A return form is enclosed with the new tuner.
Finally, Check the Images Finally, Check the Images
and Sound!and Sound!
Finally, Check the Images Finally, Check the Images
and Sound!and Sound!
Finally, Check the Images Finally, Check the Images
and Sound!and Sound!
Finally, Check the Images
and Sound!
The high-definition channels are in the 600s (602 ～ ). Please input the channel
numbers in the 600s chosen under the contract and confirm reception.
To allow you to experience even more high-definition channels, even the channels
that are not part of your contract can be viewed free-of-charge for approximately
2 weeks. Please use this opportunity to consider an additional contract.
Connection
Setup
GuideGuide
SimpleSimple
GuideGuide
SimpleSimple
GuideGuide
SimpleSimple
Guide
Simple
SKY PerfecTVSKY PerfecTV
!
HIKARI HIKARI
HD-compatible tunerHD-compatible tuner
SKY PerfecTVSKY PerfecTV
!
HIKARI HIKARI
HD-compatible tunerHD-compatible tuner
SKY PerfecTVSKY PerfecTV
!
HIKARI HIKARI
HD-compatible tunerHD-compatible tuner
SKY PerfecTV
!
HIKARI
HD-compatible tuner
Let’s start Let’s start
watching!watching!
スカパー
！
(SKY PerfecTV
!
)
(compatible with 2150MHz)
Branching filter
(commercially available)
