Hiboy MAX 3 User manual
MAX 3 ELECTRIC SCOOTER
USER MANUAL
The manufacturer reserves the right to make changes to the product, and update this manual at any time
Visit www.hiboy.com to download the latest user materials
www.hiboy.com
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
1. Package Contents
Carefully check package contents, if anything is missing or
damaged, please contact Hiboy customer service for support:
us.support@hiboy.com Charger
Allen Wrench Inflator
10 x Screws
(2 spare screws included)
1
Package Contents
Product Overview
Assembly
Charging
Riding Basics
Riding Notice
Dangerous Actions (No Attempting!)
Safety Instructions
Folding and Carrying
Daily Care and Maintenance
Disc Brake Adjustment
Specifications
Limited Warranty Statement
01
02
04
06
06
10
12
14
15
16
17
19
20
2. Product Overview
32
Control Panel Power Button
Battery Indicator
Light
Mode
Press the button and hold for few seconds to turn on/off the scooter.
The power level is indicated by five power lights on the control panel.
When the scooter is on, tap twice will turn on/off the front light, platform light and rear light.
One-tap to change the riding mode 1 to 3.
S
Cruise Control When the icon lights up, you have activated cruise control.
Handlebar
Brake
Filding Clip
Display
Throttle
Folding latch
Kickstand
Platform
Brake Light
Disc Brake
1. Fold up the latch and insert into hole until you hear a sound. 2. Put the all 8pcs screws into the holes,then tighten
the each screws properly.
One-step Folding latch:
You must make sure the folding latch is locked before riding.
Fold up the latch and insert into hole until you hear a sound.
ATTENTION:
3. Assembly
5
4
98
4. Charging
5. Riding Basics
1. Turn the power on,and check the electricity indicator.
2. Stand on the base with one foot and propel
yourself with the other foot.
Your scooter will be fully charged when the LED light on the charger
changes from red（charging）to green.
After a period of full charge, the charging will cut off automatically.
Even so, we still don't recommend charging your scooter for a long
time more than 24 hours at one time.
Do not connect the charger if the charging port is wet. Cover the
charging port when not use.
3. When the electric scooter begins to glide, put
both feet on the deck and press the accelerator.
The speed shall be kept above 3.1mph (5km/h)
for starting the throttle.
4. Release the throttle and to reduce the speed
slowly. Squeeze the brake lever for a sudden
brake.
5. Tilt your body to the steering direction as you
turn, and turn the handlebar slowly.
Always wear a helmet and safety gear so to
avoid falling and injury during the driving
learning,as shown in the figure.
1110
6. Riding Notice
Do not accelerate when you go downhill.
Look out for doors, elevators and other overhead
obstacles.
Please keep a medium or low speed (５mph) when you ride through
speed bumps, elevator door sills, bumpy roads or other uneven
surfaces Slightly bend your knee to better adjust mentioned surfaces.
Do not press the throttle when walking with the
scooter.
Always steer clear of obstacles.
Keep both feet on the deck all time.
Do not hang bags or other heavy stuff on the handlebar.
Do not ride in the rain.
1312
7. Dangerous Actions (No Attempting!)
Do not turn the handlebar violently
during high-speed riding
Do not ride with anyone else, including
children.
Do not keep your feet on the rear
mudguard.
Do not keep your hands away from
handlebar.
Do not touch the disc brake.
Do not try riding up or down stairs, and
jumping over obstacles
Do not ride in a ponding that is higher
than 0.79 inches.
Do not ride in traffic lanes or residential areas where
vehicles and pedestrians are both allowed.
15
14
8. Safety Instructions 9. Folding and Carrying
The Hiboy Max3 electric scooter is a leisure device. But once they're in a public area, they'll be seen as vehicles, subject-
ing to any risks faced by vehicles. For your safety, please follow instructions in the manual and traffic laws and regulations
set forth by government and regulatory agencies.
● At the same time, you should understand that risks cannot be entirely avoided as others may violate traffic regulations
and drive incautiously, and you're exposed to road accidents just as when you're walking or biking. The faster the scooter
is, the longer it takes to stop. On a smooth surface, the scooter may slip, lose balance, and even result in a fall. Thus it is
crucial that you use caution, keep proper speed and distance, especially so when you're unfamiliar with the place.
● Respect pedestrians' Right of Way. Try not to startle them while driving, especially children. When you ride from behind
pedestrians, ring your bell to give them a heads-up and slow your scooter to pass from their left (applicable to countries
where vehicles drive on the right). When you ride across pedestrians, keep to the right at a low speed. When you drive
across pedestrians, keep the lowest speed or getting off the vehicle.
● Closely follow the safety instructions in the manual. Hiboy shall not be liable for any financial losses, physical injuries,
accidents, legal disputes and other interest conflicts resulted from actions that violate user instructions.
● Do not lend your scooter to whoever doesn't know the operations. And when you do lend it to your friends, please take
the responsibility to ensure he/she knows the operation and wears the safety gear.
● Check the scooter before every use. When you note loosen parts, low battery alerts, excessive wear, strange sounds,
malfunctions and other abnormal conditions, stop riding.
● WARNING – Risk of Fire – No User Serviceable Parts.
Make sure that the scooter’s turned off. To fold , unlock the latch and bend the lever, then, insert the buckle into the hole on the
platform to fasten the lever and pedestal. To open, take out the buckle from the hole, erect the lever and lock the latch.
Hold the handlebar stem with either one hand or both hands to carry.
1
2
16 17
10. Daily Care and Maintenance
Cleaning and storage
Battery maintenance
If you see stains on the scooter's body, wipe them off with a damp cloth. If the stains won't scrub off, put on some toothpaste,
and brush them with a toothbrush, then wipe them off with a damp cloth.
Notes: do not clean the scooter with alcohol, gasoline, kerosene or other corrosive and volatile chemical solvents to prevent
dire damage. Do not wash the board with a high-pressure water spray. During cleaning, make sure that the scooter's turned
off, the charging cable is unplugged, and the rubber flap is closed as water leakage may result in electric shock or other major
problems.When the scooter not in use, keep it indoors where it is dry and cool. Do not put it outdoors for a long time.
Excessive sunlight, overheating and overcooling accelerate the battery pack's lifespan．
1. Use original battery packs, use of other models or brands may bring about safety issues;
2. Do not touch the contacts. Do not dismantle or puncture the casing. Keep the contacts away from metal objects to prevent short
circuit which may result in battery damage or even injuries and deaths;
3. Use original power adapter to avoid potential damage or fire;
4. Mishandling of used batteries may do tremendous harm to the environment. To protect natural environment, please follow local
regulations to properly dispose used batteries.
5.After every use, fully charge the battery to prolong its lifespan.
Storage and Disposal
1.Please try to store the scooter in a cool and dry place between 14℉and 104℉. In extremely humid environments the interior of the
scooter may suffer condensation or even water accumulation, which may damage the battery rapidly.Devices are not intended for
use at elevations greater than 2000 m above sea level Prolonged Exposure to UV Rays, Rain and the Elements May Damage the
Enclosure Materials, Store Indoors When Not in Use.
2. In daily use, try to avoid recharging the scooter after completely exhausting the battery. If the battery is low, charge it as soon as
possible.
3. Please charge the scooter every other month to preserve the battery.
To adjust the disc brake sensitivity:
You need the H5 Allen wrench to loosen the screw on the rocker
When the disc brake is too sensitive, rotate the disc brake rocker down a bit. Then, reinstall the screw back to the
brake cable core to tighten.
When the disc brake cannot stop, rotate the disc brake rocker up a bit. Then, reinstall the screw back to the brake
cable core to tighten.
Notice: The disc brake may squeak when in use until it is broken in. This is normal and does not affect the brake's
function or performance.
11. Disc Brake Adjustment
12. Specifications
Operating Temperature
(1) The height of the body: distance from the ground to the highest end of the body.
(2) Description of the battery life: it is measured under the condition of full charge, a load of 150 lb, at 77°F , on a flat road without wind, and at
a speed of 9.3mph. The real battery life will differ with different factors of the load, humidity, wind speed and operation habits.
(3) The maximum allowable weight shall be kept within 220lb (driver and objects included)in any case. Consider an extra weight of the clothes or other accessories
with us during the trip and the gravity generated by speed, the scooter will not support it if this load limit is exceeded.
Max. Range
Load
Max3
18 19
45.1*19.5*43.5 inch
45.1*19.5*18.3 inch
40 lbs
16-50
18.6 mph
12 - 17 mile
15%
32-104 ℉
IPX4
36 V
42 V
7.5 AH
350 W
100-240 V
42 V
2 A
≌4 h
220 lbs
To remove the disc brake noise,
First make sure the scooter is turned off. For easier operating, we suggest you put the scooter on the desk.
Loosen two screws on the pump (not the screw on the rocker).
Adjust the position of the disc brake pump to ensure that the brake disc is in the middle of the two
brake pads.
Keep the brake disc and brake pad not touching each other.
Hold the disk brake pump in the desired position, then retighten the screws to the pump.
