Hi TV Twinview HD User manual
Welcome
Congratulations on your purchase of HiTV Twinview HD Digital Panel with Built-In DVD rear
seat System that will provide your family with many years of enjoyment. This sophisticated
product provides video entertainment to rear seat passengers without altering the appearance
of your vehicle’s original interior.
Reviewing this owner’s manual thoroughly prior to operation will provide you with the best
performance and help explain the simple requirements for proper care.
Important Safety Information:
This video product is designed and intended for positioning in back seating areas of a vehicle
where it cannot be viewed directly or indirectly by the driver and possibly cause him/her to
be distracted from the task of operating the vehicle. Driver distraction is a major cause of ac-
cidents and for this reason; many states specically prohibit the viewing of motion video within
view of the driver while the vehicle is in motion.
For safety reasons, when changing discs it is recommended that the vehicle is stationary, and
that you do not allow children to unfasten seat belts to change discs or make any adjustments
to the system. System adjustments can be safely accomplished using the remote control unit.
Enjoy your HiTV Twinview HD Digital Panel DVD rear seat System but remember the safety of
all passengers is the number one priority.
Care and Maintenance
HiTV Twinview HD Digital panel with Built-In rear seat System is a product of superior design
and craftsmanship and should be treated with care. The suggestions below will help to fulll
any warranty obligations and provide many years of enjoyment.
• Cleaning the Monitor Screen and Housing:
The components may be cleaned by occasionally wiping with a soft, lint-free, cotton cloth that
has been slightly dampened with water.
CAUTION: Do not use liquids, abrasives, aerosol cleaners, or paper cleaning products
because they will result in permanent damage to the nish of your components! The LCD
screen is made of a specially coated glass and can be scratched or damaged by abrasive or
ammonia-based window cleaners.
• Use and Storage:
These units contain precision electronics that must be protected from dust, dirt, and moisture.
-Never spill liquids on any of the components. Liquids, humidity, and precipitation contain
minerals that will corrode electronic circuits.
• Take care to avoid the following:
-Rough handling can break internal circuit boards. Do not drop, knock, or shake the compo-
nents.
-Do not attempt to paint or renish the components. Paint can clog moving parts and prevent
proper operation.
-The components can be damaged by non-expert handling. Attempting to open any of the
components may void the limited warranty.
1
Product Features
- 7-inch colour TFT-LCD high resolution digital panel with 16:9 aspect
- Built-in Top-loading Slot-in DVD loader (except for monitor version)
- 3 Operating Modes
(1) DVD
(2) Crosslink
(3) AUX AV Input
- Dual-channel IR Transmitter for wireless Headphone
(1) Channel A
- Audio-R: 2.3 MHz
- Audio-L: 2.8 MHz
(2) Channel B
- Audio-R: 3.2 MHz
- Audio-L: 3.8 MHz
- IR Sensor on the Front Panel
- 5 Touch Buttons on the Front Panel - OSD (on screen display) Control
(1) Power/Source
(2) Forward
(3) Rewind
(4) Stop
(5) Play/Pause
- Audio FM modulator (optional)
88.1/88.3/88.5/88.7/88.9/ MHz
- Dual-mode (DVD/Monitor) Remote Controller
- Power Input: +12VDC
2
Crosslink Function
With this function, it is easy to let the 2 units play the same video & audio to let users to have
more fun and convenience.
If one unit switches to DVD and plays DVD disc, switch another unit to Crosslink to play the
same video & audio.
Please note it is not possible to have both units switch to Crosslink at the same time. If both
units switch to Crosslink, the message “No Signal” will be displayed.
WARNING:
Table of Contents
HiTV Twinview HD.................................................................................................................... 4
Remote Control Operations...................................................................................................... 6
On Screen Display Function Control........................................................................................ 9
Accessories............................................................................................................................. 10
Warnings / Troubleshooting.................................................................................................... 11
Specications.......................................................................................................................... 12
Set Up Region Code .............................................................................................................. 13
3
Item Function Description
1 PLAY / PAUSE
2 STOP
3 FR (Fast Rewind/Previous)
4 FF (Fast Forward/Next)
5 POWER / SOURCE
First press this button to turn the monitor ON. The current video source will be
displayed on the screen. Press the button again to switch the video source. If you
wish to turn off the unit, press the button for 3~4 seconds.
6 IR Receiver
For use with remote controller
7 Infrared Lens
To transmit audio to the wireless headphone.
8 USB Port
93.5Φ RCA Input
10 Digital LCD Panel (800x480)
11 Power On LED
12 Disc slot (only on Master/DVD Built-in unit)
13 Eject button
13
1
2
3
4
5
9
8
7
6
10
11
12
HiTV Twinview HD
4
Insert Disc
Be careful not to touch the power key when you rotate the monitor. If you touch it carelessly,
and the video source changes, just press it again to go back to the original source.
5
HiTV Twinview HD
Eject Button
Press Press
1
2
3
4
5
6
7
89
10
11
12
13
14
15
16
17
18
19
20 21
22
23
24
25
26
27
28
29
30
31
Item Operation Description
1
POWER
Press the button to turn the monitor ON/OFF. The current video source will be
displayed on screen within a few seconds.
2
SOURCE
All video sources connected to the AV inputs can be viewed on the monitor by
pressing this button. Each time the button is pressed, the AV source changes in
the following sequence: AUX1; AUX; Crosslink; DVD.When the monitor is turned
off, the source input will momerizes the last viewed.
3DVD/USB SOURCE(only when USB input is utilized)
4
PLAY/PAUSE
Press the button to play or pause a disc that is loaded into the integrated DVD
player.
5
STOP
Press the button to stop playing the movie or song. STOP->PLAY: Resumes
play from where disc was stopped. STOP->STOP->PLAY: Restarts play from the
beginning of the disc.
Remote Control Operations
6
Item Operation Description
6PREV
Plays the previous chapter or track.
7NEXT
Plays the next chapter or track.
8
FAST FORWARD
Press the button to search disc forward continuously. There are 5 speed options to
choose from:2x,4x,8x,16x,and 32x.
9
FAST REWIND
Press the button to search disc backward continuously. There are 5 speed options
to choose from:2x,4x,8x,16x,and 32x.
10 MENU
Goes to the Root Menu on the disc.
11
AUDIO
Changes the subtitle language to other available languages or turns the subtitles
off (only applicable if the disc contains multiple subtitle languages).
12 ZOOM
Selects the screen-mode between wide/normal/zoom.
13 PBC(Video CD only)
Turns the PBC (Play Back Control) on or off.
14
SETUP
Navigates SETUP MENU. There are 4 pages to congure System:
(1) General Setup Page
(2) Audio Setup Page
(3) Preference Page
(4) Password Setup Page
15 OSD UP
Moves up within the OSD menu.
16 OSD
On Screen Display
17 OSD DOWN
Moves down within the OSD menu.
18
SUB
Changes the subtitle language to other available languages or turns the subtitles
off (only applicable if the disc contains multiple subtitle languages).
19 ANGLE
N/A
20
MUTE
Press the button to mute the audio to the wireless headphones. The screen will
display ‘MUTE‘ in the lower left corner when using this feature. Press the button
again to restore audio to the previously set level.
7
Item Operation Description
21 RETURN
Returns to the previous menu screen or playing point.
22 UP
Moves up within the DVD SETUP menu.
23 LEFT
Moves left within the DVD SETUP menu.
24 DOWN
Moves down within the DVD SETUP menu.
25 RIGHT
Moves right within the DVD SETUP menu.
26 ENTER
Conrms a selection.
27 REPEAT(Except VCD with PBC on)
Repeats all or a part of a chapter, title, track, or an entire disc.
28 A-B (Except MP3)
Repeats disc from user selected point A to point B.
29 DISPLAY
Shows information on the top left corner of the screen including title, chapter/track,
time elapsed, and time remained, or turns off the display.
30 GOTO
Navigates the “Go To” Menu and goes to the desired title, chapter, track or song
on the disc.
31 NUMBER PANEL
Use these buttons to access a specic chapter or track.
8
OSD (On Screen Display) Function Control
OSD MENU
Press OSD key on remote control to enter OSD menu, then select item in the menu by press-
ing OSD key. Use the up and down buttons to change the value.
Exit OSD MENU
Wait for few seconds to exit the OSD menu.
BRIGHTNESS
Adjust BRIGHTNESS value from 0-30(Default:15) by
pressing▲for increment or▼for decrement.
CONTRAST
Adjust CONTRAST value from 0-30(Default:15) by
pressing▲for increment or▼for decrement.
COLOR
Adjust COLOR value from 0-30(Default:15) by
pressing▲for increment or▼for decrement.
IR PHONE
Adjust IR Phone to channel A (CHA) or channel B (CHB) by
pressing▲for increment or▼for decrement.
RESET
Reset each OSD parameters to factory default value by
pressing▲or▼keys.
FM
Adjust FM to Driver/Traveler/Aux-Box/OFF by
pressing▲for increment or▼for decrement.
FM CH
Adjust FM CH to different frequency by
pressing▲for increment or▼for decrement.
9
NOTE: Functions available with AV Box only.
