HANDI CART
®
Firstly, insert the spine tube (b) into the base tube (a). Before securing in to place, pull
up and fasten the mesh bag over the two prongs at the top end of the spine tube. Now
proceed to tighten the M8 screw and associated ttings as shown above in gure 1, using
the Allen key and spanner provided. Secondly, insert the handle (c) into the spine tube (b)
and adjust to your desired height and orientation and secure using the linchpin as shown in
gure 2. Lastly, place the two in each of the xed holders.
ai
j
h
g
fk
e
c
spine
tube linchpin
b
d
gure 1 gure 2
base
tube
M8 screw (g)
Steel washer (i)
M8 nylon nut (h)
& nut cover (j)
handle
spine
tube
What’s in the box?
Bromyard Road, Ledbury
Herefordshire HR8 1NS
Tel: +44 (0)1531 635678
Fax: +44 (0)1531 635670
www.HHEnvironmental.co.uk
k- Linchpin
a- Chassis - consisting of main frame (part code: LP0004), base tube, wheels (LP0007)
and mesh bag (LP0005)
b- Spine tube c- Handle (LP0006)d- x 2 (LP0001)
e- 13mm spanner f- 5mm Allen key g- M8 screw h- M8 nylon nut
i- Steel washer j- Nut cover
