HELLER DAYNE User manual
CEILING FAN INSTALLATION MANUAL
Models: DAYNE & EBONY
Fan picture is for illustration purposes only. Styles will vary according to the particular models.
READ AND SAVE THESE INSTRUCTIONS
MUST BE INSTALLED BY A LICENSED ELECTRICIAN
The appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
PREPARATION:
Unpack your ceiling fan carefully, then remove all parts and components, and lay on a cloth or
soft surface to avoid damage. DO NOT lay the motor housing on its side, the housing may get
damaged.
Before commencing installation, check that all parts are included. NB: You may need to remove
all foam packaging material to ensure there are no missing components.
mounting the motor to the ceiling.
Unlike most ceiling fans, The Ceiling Fan requires you to attach the blades to the motor BEFORE
SELECTING A LOCATION:
vChoose a location for mounting the fan where the blades will have at least 2.1 metres of
clearance from the floor.
vMake sure that the installation site will not allow the rotating fan blades to come into contact with
any object and that there is a minimum clearance of 150mm (6”) from the blade tip to the wall or
ceiling. Please note that the bigger this clearance is the better the airflow from your fan will be.
vDO NOT use outdoors. Installing the fan in a position where it could be exposed to water or
moisture is dangerous.
vIf the location you have chosen does not have a suitable support beam capable of supporting
45Kg, install a brace 2” x 4” between the ceiling joists as a support medium.
ASSEMBLY:
Ifin
stalling more than one ceiling fan, ensure that the blades do not get mixed up between units, as
each set is dynamically balanced.
BLADE ATTACHMENT:
1. Remove the two screws from the covering plate on top of the motor housing (Fig. 4), and
remove the plate.
2. Insert the blade through the slots around the motor. Align the blade with the three holes, and
secure the three screws through the opening exposed when the covering plate was removed. If
the holes do not align, the blade is upside down. The blade is designed to fit snugly, the screws
should be vertical with the blade.
3. Tighten all blade screws evenly and securely to ensure quiet, wobble free operation of the fan.
4. Replace the covering plate on top of the motor housing by reversing step 1.
INSTALLATION:
CAUTION: Before installing the fan, make sure you have turned OFF the electricity supply.
1. Secure the hanging bracket to the ceiling joist or suitable structure that is capable of carrying a
load of at least 45Kg, with the two long fixing screws provided. Ensure that at least 30mm of
the screw is threaded into the support.
NB: The fixing screws included are designed for use when ceiling fan is secured onto timber joists.
For all other surfaces, additional and suitable fixing screws for that surface will need to be
purchased.
2. Make sure that the position of installation will not allow the blades to come into contact with
any object. The fan must be mounted so that the tips of the blades are at least 2.1 metres
above the floor.
3. Carefully lift the fan, and place the down rod ball assembly into the mounting plate ensuring
that the ball correctly locks into place.
4. Refer to the following section detailing “Electrical Connection” for details on how to wire this
product correctly.
5. After the fan has been wired to the power supply, carefully position all excess cable inside the
boundaries of the hanging bracket.
6. Carefully slide the canopy up to cover the hanging bracket and ball joint, taking care not to
damage wires. Once in position, secure the canopy with the screws provided.
ELECTRICAL CONNECTIONS:
For your convenience, and to assist in easy installation & cleaning, your ceiling fan is connected
with Mawson’s easy connect system. Simply connect the male and female couplings, and then
ensure all excess wiring is retained inside the ceiling canopy.
The appliance must have a means for disconnection from the supply mains having a contact
separation in all poles that provide disconnection under overvoltage category III conditions. A
means for disconnection must be incorporated in the fixed wiring in accordance with the wiring
rules.
REVERSE SWITCH:
The “Summer / Winter” switch should be in the forward position to make the fan rotate in an anti-
clockwise direction during summer. In winter,, this switch should be reversed (move to UP position)
so that the blades now move in a clockwise direction.
10.
Select the desired position of the reverse switch on the lower canopy of the fan.
Warmer Weather ---Have the airflow directed downwards.
Cooler Weather ---Have the airflow directed upwards.
Threaded components which are slightly loose
The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
8
TROUBLE PROBABLE CAUSE SUGGESTED REMEDY
A/ Fuse or circuit breaker has
blown.
A/ Check main and branch circuit
breakers.
B/ Loose wire connections to
the fan.
B/ Check line wire connections to
fan.
C/ Speed controller not in the
correct position. C/ Check speed controllers position.
A/ Fan blades are not horizontal
to the ceiling.
A/ Retighten all screws on blades.
Do not make any adjustments by
applying pressure up or down on
blades.
B/ Blade screws are loose. B/ Make sure all screws are
tightened.
B/ Loose fan blades. B/ Retighten all screws on fan.
C/ Ceiling fan not secured
against ceiling.
C/ Retighten all screws in the
hanging bracket.
D/ Incorrect speed controller. D/ Change speed controller to the
one supplied with the unit.
Mechanical noise A/ Fan has not settled in fully. A/ Allow at least 8 hours settling in
period.
Fan will not start
Fan wobbles
Fan sounds noisy
TROUBLE SHOOTING:
9
