Failure to comply can result in the awning falling off and therefore can cause injuries!
Transport the awning to the place of installation in the correct position.
The drive side is indicated on the packaging.
Secure the installation area; at least the area equivalent to the extended awning.
When pulling up the awning into higher installation positions by means of ropes the awning is to be removed from the
packaging. The pull ropes are to be attached so that the awning is securely fastened, but is not damaged. The awning
may only be raised in the horizontal position and uniformly.
Before starting the installation, check whether the type and number of brackets match the order and whether the installation surface
(substrate) matches the surface given in the order. In the event of significant differences, which make safe and secure fixing of the
awning questionable, consult the system manufacturer and a fixing technology specialist.
SAFETY NOTES AND IMPORTANT INFORMATION ARE INTEGRATED IN THE TEXT AS APPROPRIATE.
THE FOLLOWING SYMBOLS ARE USED TO ALERT THE READER/USER OF THE INSTRUCTIONS.
This symbol means that the relevant note is important for the safety of persons or for the function of the awning. This
symbol highlights important product information for the installation engineer or user.
1. SAFETY NOTES, WARNINGS AND MOUNTING INFORMATION
1.1 EXPLANATION OF THE SAFETY NOTES
1.3 INSTALLATION PREPARATION
1.2 GENERAL SAFETY INFORMATION
These Helioscreen systems have been designed and manufactured in conformity with DIN EN 13561. However,
when the awning is mounted or operated, the persons involved in the respective activity may be put at risk if the
relevant instructions are not observed.
Only qualified and duly specialised companies or trained specialist personnel may be permitted to mount the awning.
Always observe the information and notes in the Mounting and Operation Instructions.
A failure to observe the relevant information will render the manufacturerʼs liability null and void.
Electrical installation work and connections to the mains must be carried out exclusively by a licensed electrical company.
If significant differences make the safe installation of the awning seem doubtful, please consult the manufacturer of the
system and a mounting/installation specialist.
The safety-at-work and accident prevention regulations specific to each country must be complied with. In particular, a
person performing special work at height must be suitably secured.
The notes on the product and its packaging must be observed.
