Heinner HVC-VB750RD User manual

VACUUM CLEANER

Model: HVC-VB750RD

www.heinner.ro

•Vacuum cleaner

•Power: 750W

•Suction power: > 180W

www.heinner.com 750W, 50-60Hz, 220-240V

Before using the appliance, please read carefully this instruction manual and keep it for future

reference.

This instruction manual is designed to provide you with all required instructions related to the

installation, use and maintenance of the appliance.

In order to operate the unit correctly and safety, please read this instruction manual carefully

before installation and usage.

I. INTRODUCTION

II. PACKAGE CONTENT

➢

Vacuum cleaner

➢Sofa brush

➢Crevice brush

➢User manual

➢Warranty card

Thank you for choosing this product!

www.heinner.com 750W, 50-60Hz, 220-240V

III. DESCRIPTION OF THE APPLIANCE

1. Modern and elegant design

2. Multiple air-filter system guarantees a hygienic cleaning

3. Drivers accessories: floor brush, nozzle etc

4. User-friendly wire rewinder pedal

IV. KNOW YOUR VACUUM CLEANER

Suction power control

Metal tescopic tube

Floor

brush

Flexible

hose

Angled

pipe

Power

swich pedal

Speed adjusting

Rewinder pedal

www.heinner.com 750W, 50-60Hz, 220-240V

V. IMPORTANT SAFETY INSTRUCTIONS

•

If the supply cord is damaged, it must be replaced by the manufacture or its

service agent or a similarly qualified person in order to avoid a hazard. For house-

hold use only.

•

This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

•

Children should be supervised to ensure that they do not play with the appliance,

for household use only.

Forbid

Do not use for absorbing detergent,

kerosene, glass, needle, cigarette ash,

water, match etc.

Forbid

The appliance should not be exposed to

heat.

Forbid

Do not vacuum any moist or liquid

substances. Never immerse the

appliance in water.

Forbid

Unplug the appliance from the mains

supply Socket after use and before every

cleaning pull the mains cable, in order to

disconnect the appliance from the

mains.

www.heinner.com 750W, 50-60Hz, 220-240V

Forbid

Do not put any object into openings. Do

not use with any opening blocked. Keep

the appliance free of dust, lint, hair etc.

Forbid

Do not use the vacuum cleaner without

dust container or dust filter in place.

Forbid

Do not vacuum any flour, cement etc., in

order to avoid the overloads.

Forbid

The appliance should only be cleaned with

a dry or damp cloth, it should never be

immersed in water. Do not use any

solvents for cleaning.

www.heinner.com 750W, 50-60Hz, 220-240V

VI. ASSEMBLY VACUUM CLEANER

Connect the hose with vacuum cleaner

Insert flexible hose into the air-intake: Press the knob until it clicks into the position.

Remove the flexible hose: Unplug the appliance and press the knob at the end of the hose.

Remove it from the air-intake opening.

Fit the telescopic to the angled pipe.

Fit the floor brush to the telescopic tube.

Angled pipe

Telescopic

tube

Floor

brush

Telescopic

tube

www.heinner.com 750W, 50-60Hz, 220-240V

VII. OPERATION

A yellow mark on power cord shows the ideal cable length. Do not expend the cable beyond

the red mark. To rewind the power cord, press the rewinder pedal with one hand and guide

the cord with the other hand.

The suction power can be adjusted with the sliding control on the angled pipe too.

Press the power switch to switch the appliance on. Use the electronic speed adjusting to

control the suction power of the cleaner.

Put the telescopic tube into the fixing hook of the appliance when you have a break.

Caution: Do not transfer the appliance when the fixing hook is used.

Angled pipe

Suction power control

Rewinder pedal

Yellow mark

Red mark

Power switch pedal

Speed adjusting

www.heinner.com 750W, 50-60Hz, 220-240V

VIII. CLEANING TOOLS

Crevice tool:

For cleaning corner edge and draws etc.:

Where is difficult to reach, such as gaps and the keyboard, bookshelf and windows.

Sofa brush: For cleaning bed, sofa, couch etc.

Use of the selector on floor brush: Bristles extended for carpets. Bristles retracted for

hard floors.

If the angled pipe has blockage insert it into the air-intake and switch the appliance on.

www.heinner.com 750W, 50-60Hz, 220-240V

IX. CLEANING AND MAINTENANCE

Empty the dust container

After removing the flexible hose, press the cover lock button and open the dust

container.

2. Remove the dust filter from the container.

3. Replace the dust filter in the container.

4. Close the dust container until it is locked in the position.

Change filter

Replace the motor filter: Open the dust container and remove the motor filter. Fix the new

filter in the position.

Replace the outlet filter: Detach the grille by pulling firmly away from the appliance,

remove the outlet filter and replace the new filter. Fix the grille again.

www.heinner.com 750W, 50-60Hz, 220-240V

Clean the filter: Clean the filter in water and allow them to dry completely before

replacing them.

Clean the cloth dust bag

Clean the cloth dust bag with water and a little detergent (if needed). Allow the filter to

dry completely before replacing.
