Heatwagon P900 Manual

Electric

Construction

Heaters

Installation and Maintenance Manual

Please retain this manual for future reference.

For Indoor Use Only

Not For Use Outdoors

342 N. Co. Rd. 400 East

Va paraiso, IN 46383

219-464-8818 • Fax 219-462-7985

www.heatwagon.com

Revision 8-17

For your safety: Do not use this heater in

a space where gaso ine or other iquids

having f ammab e vapors are stored.

IM ORTANT INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USING THIS HEATER

1. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. Use

handle when moving this heater. Keep combustible materials at least 6 feet (2 meter) from the

front of the heater and keep them away from sides and rear

2. Extreme caution is necessary when the heater is used near children or invalids and whenever

the heater is left unattended

3. Always unplug the heater when not in use

4. Do not operate any heater with a damaged cord or plug or after the heater malfunctions, has

been dropped or damaged in any manner. Return heater to authorized service facility for

examination, electrical or mechanical adjustment or repair

5. Do not use outdoors

6. This heater is not intended for use in bathrooms, laundry areas and similar indoor locations.

Never locate the heater where it may fall into a bathtub or other liquid container

7. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or the like.

Arrange cord away from traffic area and where it will not be tripped over

8. TO DISCONNECT HEATER, reduce ambient thermostat to zero. Fan will continue to run

(P1800,4000,6000) until unit cools and shuts down automatically, turn switches off,

disconnect power. For P600, P900 let fan run one minute then after cooldown, turn switch off,

disconnect power.

9. Connect to properly grounded outlets only

10. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may

cause an electric shock or fire, or damage the heater

11. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use on

soft surfaces, where openings may become blocked

12. A heater has hot and arcing or sparking parts inside. Do not use in areas where gasoline, paint

or flammable liquids are used or stored

13. Do not point to flammable materials

14. Use heater only as described in this manual. Any other use not recommended by the

manufacturer may cause fire, electric shock or injury to persons

15. Always plug heaters directly into a wall outlet/receptacle. Never use with an extension cord or

relocatable power tap (outlet/power strip)

16. SAVE THESE INSTRUCTIONS

Table of Contents: age

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Principal of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Set Up and Operation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Maintenance and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Parts Breakdowns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 -16

Electrical Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10, 12, 14, 17-19

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Installation and Maintenance Manual

Models P600, P900, P1800-1,

P1800-3, P1800D, P4000 and P6000

Construction Heaters

342 N. Co. Rd. 400 East • Val araiso, IN 46383

219-464-8818 • 888-432-8924 • Fax 800-255-7985

www.heatwagon.com

WARRANTY

All new Heat Wagon and Sure Flame heaters and fans are guaranteed against defective materials and work-

manship for one (1) year from invoice date.

Warranty repairs may be made only by an authorized, trained and certified Heat Wagon dealer. Warranty

repairs by other entities will not be considered. Warranty claims must include model number and serial

number.

LIMITATIONS

Evidence of improper electric power, misapplication or evidence of abuse may be cause for rejection of

warranty claims.

Travel time, mileage and shipping charges will not be allowed. Minor adjustments of heaters are dealers’

responsibility. Defective parts must be tagged and held for possible return to the factory for 60 days from

date of repair. The factory will provide a return goods authorization, (RGA) for defective parts to be

returned.

No warranty will be allowed for parts not purchased from Heat Wagon.

Heater is not intended for use in pest remediation.

P600 P900 P1800-1 P1800-3 P1800D P4000 P6000

Heat Output (Max BTU's) 20,500 30,700 65,000 65,000 65,000 136,000 204,700

(First Stage) 20,500 30,700 41,000 41,000 41,000 51,200 81,864

(Second Stage) N/A N/A 65,000 65,000 65,000 102,400 163,728

(Third Stage) N/A N/A N/A N/A N/A 136,500 204,606

Watts (Max) 6,000 9,000 18,000 18,000 18,000 40,000 60,000

(First Stage) N/A 9,000 12,000 12,000 12,000 16,000 24,000

(Second Stage) N/A N/A 18,000 18,000 18,000 32,000 48,000

(Third Stage) N/A N/A N/A N/A N/A 40,000 60,000

Electrical Rating 240V 60Hz 1Ø 240V 60Hz 1Ø 240V 60Hz 1Ø 240V 60Hz 3Ø 240V 60Hz 3Ø 480V 60Hz 3Ø 480V 60Hz 3Ø

Min. Voltage at Heater 208 208 208 208 208 440 440

Amp Draw (Max) 25 38.0 75 50 50 50 75

(First Stage) 25 38.0 50 34 34 20 24

(Second Stage) N/A N/A 75 50 50 40 48

(Third Stage) N/A N/A N/A N/A N/A 50 75

Air Flow 250 CFM 350 CFM 590 CFM 590 CFM 940 CFM 1,800 CFM 1,800 CFM

(425 Cu. m/hr) (600 Cu. m/hr) (1,000 Cu. m/hr) (1,000 Cu. m/hr) (3,000 Cu. m/hr) (3,000 Cu. m/hr)

Ambient Thermostat 32 to 100°F 32 to 100°F 32 to 100°F 32 to 100°F 32 to 100°F 32 to 100°F 32 to 100°F

Weight 32.9 lbs 48 lbs 62 lbs 62 lbs 62 lbs 130 lbs 142 lbs

Ducting (Max) N/A N/A N/A N/A 12" x 50' (straight) 14" x 50' (straight) 14" x 50' (straight)

Duct PN-WD1225 Duct PN-WD1425 Duct PN-WD1425

12”x25’ Long 14”x25’ Long 14”x25’ Long

Temp Rise 100ºF 100ºF 100ºF 100ºF 100ºF 100ºF 100ºF

(from 0ºF ambient)

dB Noise 53 dB(A) 1m 55 dB(A) 1m 58 dB(A) 1m 58 dB(A) 1m 82 dB(A) 1m 82 dB(A) 1m

UL L sted Yes Yes Yes Yes Yes

Dimensions 20"L x 12"W x 17"H 23"L x 12"W x 18"H 30"L x 14"W x 20"H 30"L x 14"W x 20"H 30"L x 14"W x 20"H 46"L x 20"W x 25"H 46"L x 20"W x 25"H

S ECIFICATIONS

RINCI AL OF O ERATION

4000, 6000

STEE

HAND E

THERMOSTAT +

SWITCHES

POWER SE ECTOR

CONTACTORS

RUGGED GA VANIZED

STEE HOUSING OVERHEAT SENSORS

FU Y SEA ED, NON-

G OWING STAIN ESS

STEE HEATING E E-

MENT 15 PCS

SO ID P ASTIC

WHEE S

A UMINUM

FAN B ADES

E ECTRIC

FAN

MOTOR

AMBIENT THER-

MOSTAT SEN-

SOR TUBE

COO

AIR

WARM

AIR

OUT

RINCI AL OF O ERATION

600, 900, 1800-1, 1800-3

2 PCS - P600

3 PCS - P900

9 PCS - P1800’s

O ERATION

REVIEW AND UNDERSTAND ALL WARNINGS IN THIS MANUAL. THEY ARE

ESSENTIAL FOR SAFE USE OF THE HEATER. FOLLOW ALL LOCAL CODES.

To start heating:

1. Place the heater on a stable, level surface. Make sure that no explosive or combustible fumes

or dust are present. See that the heater is not exposed to water spray, rain, or dripping water.

Minimum clearances from combustible materials:

Outlet: 6 feet, Sides: 1 foot, Top: 2 feet, Rear: 2 feet

Floor: combustible

2. Connect heater to proper power source. The P600 requires a 240V, 60Hz single phase 25 Amp

power source. The P900 requires a 240V, 60Hz single phase, 40 Amp power source. The

P1800-1 requires a 240V, 60 Hz single phase, 75 Amp power source. The P1800-3 requires a

240V, 60 Hz three phase, 50 Amp power source. The P4000 requires a 480V, 60 Hz three

phase, 50 Amp power source. The P6000 requires a 480V three phase, 75 Amp power source.

Also, ALL OWER SOURCES NEED TO BE EQUI ED WITH A CIRCUIT BREAKER!

Note: When power is first applied to unit, the heater fan may blow

air out of heater INLET. If this condition occurs, (after first

removing power from cord) reverse the first two hot wires at heater

terminal inlet block. (3 hase Models Only)

3. Set the remote thermostat to a temperature above the ambient room temperature by turning

the knob. NOTE: The heater will start only if the thermostat “calls for heat” meaning that it is

set to higher than prevailing ambient temperature.

4. Set the selector switch to the desired heating setting. For the P1800 series, the options are #1

for ventilation (fan only), #2 for low heat output of 12Kw (41,000 Btu’s), or #3 for high

output of 18Kw (65,000 Btu’s).

For the P4000, the switches are labeled S1 with a heat output of 16Kw (54,600 Btu’s), S1 and

S2 with a heat output of 32Kw (109,200 Btu’s) or S1, S2 and S3 with a heat output of 40Kw

(136,000 Btu’s).

For the P6000, the switches are labeled S1 with a heat output of 24Kw (81,900 Btu’s), S1 and

S2 with a heat output of 48Kw (163,800 Btu’s) or S1, S2 and S3 with a heat output of 60Kw

(204,700 Btu’s).

The heater will now operate automatically, controlled by the thermostat.

To Stop Heating: ( 1800, 4000, 6000)

1. Turn all switches to “Off”.

2. Allow fan to run until unit stops automatically, controlled by unit cooldown thermostat (fan

switch). Heater may cycle more than once.

3. Unplug the power supply cable after the fan has stopped cooling down the heater completely.

To Stop Heating: ( 600, 900)

1. Reduce ambient (room) thermostat to “Heat Off” position.

2. Allow fan to run for at least two minutes.

3. Flip switch to “Off” position.

4. Unplug heater.

NOTE: The heater is equipped with an overheat limit switch which may cause the heater to

stop. Check and remove the cause for overheating before re-starting.

Never disconnect supply plug to stop the heater while in operation!!

MAINTENANCE

Never service heater while it is plugged in, running or hot. Severe bodily injury or electric

shock may occur.

Only qualified persons are allowed to open heater for service.

1. Keep heater clean (ex. dry wall dust). Use pressurized air to blow fan blades clean.

NOTE: Use moderate pressure to avoid damage to fan blades.

2. Inspect heater before and after each use.

3. The bearings of the fan motor are permanently lubricated and sealed No additional lubrication

is needed.

GENERAL ELECTRIC HEATER SIZING ISSUES

When running Heat Wagon electric heaters from a generator, it is extremely important to make sure

that the generator selected for your heater is not undersized. The single largest service issue with

Heat Wagon electric heaters is improper set up relating to inadequate voltage due to too small of an

electric source and/or too small of a power cord.

Generator Selection for Heat Wagon Electric Heaters

The chart below will help you when it comes to selecting the correct generator required for your

Heat Wagon heater:

So, by reviewing the above chart, a P1800-1 would require a minimum 18,000 Watt (18KW),

240 volt single phase generator that can provide 75 amps of continuous power.

Heating Coil Ohm Readings

P600 - 20

P900 - 20

P1800’s - 26

P4000 - 85

P6000 - 54

Model Watts Phase BTU'S Volts Amps CFM Recommendations

P1500 1,500 1 Phase 5,100 120 15 120 3KW

P600 6,000 1 Phase 20,500 240 25 250 10KW

P900 9,000 1 Phase 30,700 240 38 350 15KW

P1800-1 18,000 1 Phase 64,000/41,000 240 75 590 25KW

P1800-3 18,000 3 Phase 64,000/41,000 240 50 590 25KW

P1800D 18,000 3 Phase 64,000/41,000 240 50 950 25KW

P4000 40,000 3 Phase 136,000/109,200/54,600 480 50 1,800 50KW

P6000 60,000 3 Phase 204,700/163,800/81,900 480 70 1,800 75KW

ELECTRICAL CORD SELECTION FOR HEAT WAGON ELECTRIC HEATERS

Once you have established that you have enough power to properly run a Heat Wagon Electric

Heater, you still need to deliver the power to the heater adequately. You will need to do a Voltage

Drop Formula. The Voltage Drop Formula is amps (source), times resistance (cord’s wire size)

equals voltage drop. A cords wire size resistance chart is below:

Wire Size Resistance Chart

#4 0.000308 Resistance per Foot

#6 0.000403 Resistance per Foot

#8 0.000641 Resistance per Foot

#10 0.00102 Resistance per Foot

#12 0.00162 Resistance per Foot

#14 0.00258 Resistance per Foot

#16 0.00409 Resistance per Foot

#18 0.00651 Resistance per Foot

A sample formula is listed below:

Example: P1800-1 phase 75 amp

Minimum Voltage Required=208V

150 ft. x 12 gauge wire (0.00162) = .24

75 amps x .24 = 18.0 volt drop

220v (at source) – 18v = 202 volts

Conclusion: Heater will not run, wire too small or cord too long.

Options to Correct the Situation:

1. Increase gauge of wire: If you increased your wire 6 gauge wire, then your

formula would be as follows:

Example: P1800-1 phase 75 amp

Minimum Voltage Required=208V

150 ft. x 6 gauge wire (0.000403) = 0.0605

75 amps x 0.0605 = 4.53 volt drop

220 volts (at source) –4.53 volts= 215.46 volts

Now, your heater will run properly.

2. Run a shorter cord. If by chance you could use a 50ft cord instead of a 150ft

cord, then your formula would be as follows:

Example: P1800-1 phase 75 amp

Minimum Voltage Required=208V

50ft. x 12 gauge wire (0.00162) = .08

75 amps x .08= 6 volt drop

220 volts (at source) –6 volts= 214 volts

Now, your heater will run properly

600 ARTS BREAKDOWN

Key # Description Part#

1 Bottom Plate HWP 4027013

2 Rear Panel HWP 4027011

3 Front Panel HWP 4027012

4 nner Mantle HWP 4027014

- Air Guide Ring, nner Mantle HWP 4027020

(not shown)

5 Outer Mantle HWP 4027010

6 Room Thermostat HWP 20220

(Ambient)

7 Fan Motor HWP 14145

8 Hub, Fan Motor HWP 17907

9 Fan Blade HWP 16109

10 Handle HWP 80100

11 Heating Element (2) HWP 42800

12 Wire Bushing (Guard Ring) HWP 36809

13 Toggle Switch HWP 26900 (400021)

15 Plastic Bracket for Bulb (2) HWP 37910

Key # Description Part#

16 Bracket for nner Mantle HWP 4027015

17 Terminal Block HWP 36704

18 Bracket for Terminal Block HWP 4027016

19 Strain Reliever HWP 36922

20 Locking Nut, Strain Reliever HWP 36923

21 Power Cord ACC 30A10

22 Plug, Handle (2 pcs) HWP 80110

23 Contactor HWP 22570

24 Overheat Limit Switch HWP 21201

25 Limiter, Air Outlet HWP 21206

26 Plug Only HWP 00275-00T

28 Knob, Room Thermostat HWP 20577

29 Bracket for Limiter HWP 4027017

30 Ground Lug Not ncluded

This manual suits for next models

Table of contents

Other Heatwagon Electric Heater manuals

Heatwagon

Heatwagon P1500 User manual

Popular Electric Heater manuals by other brands

Heatscope

Heatscope PURE Installation and instruction manual

Sunbeam

Sunbeam Calentador SFH457A instruction manual

Dura Heat

Dura Heat DH2000C owner's manual

Harvia

Harvia K10.5GS Instructions for installation and use

Harvia

Harvia GL70 Instructions for installation and use

Heylo

Heylo DE 2 XL user manual

Heylo

Heylo DE 20 SH user manual

Harvia

Harvia PP70SP Instructions for installation and use

Tylo

Tylo SENSE SPORT installation guide

Dirna

Dirna ecodirna SUN User handbook

Creda

Creda Heating Solution brochure

THERMEx

THERMEx Frame E Wi-Fi Series user manual

SHUFT

SHUFT UniMAX-R 1400VE EC Technical manual

HUUM

HUUM CLIFF Series Installation and operation manual

Harvia

Harvia HL70S Instructions for installation and use

Dimplex

Dimplex DHEBHT instructions

Radialight

Radialight SIRIO manual

Polaris

Polaris PRE E 0715 H manual
