Heatstore HSQWPH1500N User manual

HSQWPH1500N

Quartz Weatherproof Heater

Installation and Operating Instructions

Telephone: 0117 923 5375 Fax: 0117 923 5374

Victoria Road, Avonmouth, Bristol BS11 9DB

www.heatstore.co.uk

Maintenance

The heater contains no moving parts and therefore very little maintenance

is required other than to ensure that

there is no excessive build-up of dust/dirt on the reflectors or emitters

as this can cause overheating and premature emitter failure.

To clean the appliance, turn off and disconnect from mains supply,

allow to cool then wipe with a damp cloth.

Lamp Replacement

The lamp used in the ﬁtting is robust and if knocks and shock vibrations are

avoided, will last for around 5000 hours.

To replace the lamp:

Disconnect the heater from the power supply by unplugging from the mains

socket and wait until the body has cooled down.

Remove both end caps by undoing the 2 socket head screws at each end.

Remove the guard and end reﬂectors.

Unclip the lamp from the spring clips at each end, allowing the emitter to

move forward clear of the back reﬂector.

Unclip the reﬂector from the heater casing.

Disconnect the emitter wires from the terminals located in the electrical box

on the rear of the heater, and then remove the lamp.

Insert the wires of the new lamp through the holes in the heater body to the

electrical box and reconnect them into the terminals. Ensure that the

terminals are tightened correctly to make a good electrical connection.

Re-assemble making sure all the parts are replaced and the guard is in

position IMPORTANT SAFEGUARDS

WHEN USING ANY ELECTRICAL APPLIANCE, BASIC SAFETY

PRECAUTIONS SHOULD ALWAYS BE FOLLOWED.

PLEASE READ ALL INSTRUCTIONS CAREFULLY

AND RETAIN FOR FUTURE REFERENCE

IF IN ANY DOUBT ABOUT THE INSTALLATION OR USE OF THIS

PRODUCT, CONSULT A COMPETENT ELECTRICIAN.

Issue 2 0910

Waste electrical products should not be disposed

of with household waste. Please recycle where

facilities exist. Check with your local authority or

retailer for recycling advice.

Speciﬁcation

HSQWPH1500N:

1500W; 230-240V ~50Hz; 6.5A

HSQWPH1500N[10]instructions 7/9/10 10:46 Page 1

Models covered by these

instructions:

HSQWPH1500N – 1.5kW

Quartz Weatherproof

Heater.

HSQWPH1500RL – 1.5kW

Replacement Lamp for

the above.

Before installation

The heater should be

mounted horizontally

where possible or at a

maximum angle of 35

degrees from the

horizontal using the

mounting brackets

provided to ensure

adequate clearances.

If mounted on Parasols

ensure the heater is left

to completely cool

before closing.

A minimum air gap of

500mm should always

be allowed between the

top of the heater and the ceiling, roof or canvas.

A safety distance of 1metre should always be left in front of the heater.

Heaters should not be installed in areas where hazardous vapours may be

present as deﬁned in BS5345

This ﬁtting is rated class I and IP55 suitable for outdoor use. To maintain

the protection rating all connections to the mains must be done with a

minimum of IP55 equipment.

Ensure that there is no possibility of inﬂammable material coming into

contact with the heater, or is too near the heater.

The essential element of the heater is the halogen ﬁlled quartz linear lamp

with a tungsten element. This operates at about 1600°C and emits short

wave infrared radiant heat.

The lamp operates at full output almost instantly and emits a radiant

energy of 1.6 – 1.8 microns.

Important Safeguards

After unpacking make sure that the appliance is complete and shows no

signs of visible damage or tampering.

Check the supply voltage is the same as indicated on the device.

Avoid improper use of extension cords.

DO NOT touch the heater with wet hands;

DO NOT operate the heater without the guard in position.

The heater should only be used with adult supervision.

Keep packing materials, which are potential dangers, away from children.

Installation

The mains lead is made from high temperature cable and as such should

not be replaced without consulting a suitable qualiﬁed electrician.

The ﬁtting must always be installed using the mounting brackets provided.

This ensures correct positioning and adequate clearance.

This unit should be mounted at a minimum of 1800mm above ground level

(See ﬁgure 1 opposite) with a minimum air gap of 500mm maintained

above the heater and the ceiling or canopy.

A safety distance of 1metre should always be left in front of the heater.

Ensure that there is no possibility of inﬂammable material coming into

contact with the heater, or is too near the heater.

The ﬁtting must be earthed.

Wall mounting

Remove the bracket from the back of the heater by unscrewing the 2 x M8

bolts.

Before drilling any holes ensure that the wall is solid and that there are no

water pipes or electrical wires in the area where you are placing the heater.

Secure the bracket to the wall then reﬁt the heater to the bracket using the 2

x M8 bolts.

The heater must be mounted at an angle of between 45° and 90°.

(See ﬁgure 1 opposite).

Parasol mounting

Use the supplied bracket for clamping to a parasol arm. You must ensure

the canvas/material of the parasol is at least 500mm away from the back

of the heater. The parasol must not come into contact with the heater in

high winds when the heater is in use.

min 45°

max 90°

500mm

minimum

1800mm

minimum

1000mm minimum

Figure 1

The HSQWPH1500N is an easy to install weatherproof

Quartz Heater for wall-mounting or ﬁxing to a parasol.

HSQWPH1500N[10]instructions 7/9/10 10:46 Page 3
