HEADSOUND H5 User manual
EarbudsStructural
Component Description
Charging case Structural
Component Description
Power On / Off Buttons
Indicator Light
Charging contact points
Microphone
Charging contact points
Charge Jack USB
Charge Jack Mini USB
4 point exits
Indicator lights
WARRANTY ACTIVATION
1. To activate your warranty - please scan this
code or go to:
https://headsoundglobal.com/warranty
www.headsoundglobal.com
PAIRING
1. Take the earbuds out of the charging case.
2. Earbuds will automatically turn on and pair
with each other.
3. Turn on the bluetooth on your main device
and search for H5 HeadSound.
4. If facing an issue with pairing, take both
two earbuds out of charging case, double
click two earbuds at the same time. After
that put earbuds back into the case. After
a second take them out from the case
and they are re-paired successfully.
(In some H5 earbuds, there is a second method
of pairing issues. Turn of both earbuds and
remove H5 HeadSound from your bluetooth
device. Press and hold both main buttons of
earbuds for at least 10 seconds until you see
both leds flash blue/red twice. Put both earbuds
back in the charging case. After two seconds
take them out, turn on bluetooth on your device,
find H5 HeadSound and pair)
1. Once you receive the HeadSound H5 true
wireless earbuds, charge the charging case
with USB charger that comes in the package.
2. Make sure that both earbuds are located in
the slots properly.
3. Charging case is fully charged once all four
leds are blue.
4. Earbuds are fully charge when light indication
is bright blue.
5. Earbuds are charging while light indication is
bright red.
6. The charging capacity of charging case is
2600 mAh, which can be used to charge
other devices.
CHARGING
1. To turn earbuds on - press and hold the
buttons on both earbuds for 2 seconds.
2.
button on one of earbuds for 5 seconds.
3.
earbuds when putting them in the case.
Earbuds entering the sleep mode once
they are located in slots. They turn on and
pair automatically once removed from the
slots.
4. Click once - play/pause music (listening
music mode).
5. Click once - answer/hang up (calling mode).
6. Click twice on the left earbud and hold on
- volume down.
7. Click twice on the right earbud and hold on
- volume up.
8. Click two times on the left earbud - switch
to previous song.
9. Click two times on the right earbud - switch
to next song.
MAIN BUTTON FUNCTIONS
10. Click twice on the left/right earbud - redial
the last dialed number.
11. Press 2 seconds on the left /right earbuds -
wake up Siri.
2* Bluetooth Earbuds
1* Charger Case
1* USB Charging Cable
3* Ear cups
PACKAGE INCLUDES
1. This product contains a built-in lithium
battery.
2. Do not expose the product to the direct,
which may result in explosion.
3. Deal with disposal of batteries in accordance
with local regulations and do not treat them
as household waste.
SAFETY PRECAUTIONS
SPECIFICATIONS
1. Product name: HeadSound Wireless Earbuds
2. Pairing name: H5 HeadSound
3. Bluetooth version: V5.0+EDR
4. Battery on earbud: 50mAh
5. Battery in charging box: 2600mAh 18650
rechargeable Lithium ion battery
6. Input: 5V/1A
7. Bluetooth distance: 10 meters
8. Frequency: 2.4Ghz-2.48Ghz
9. Music time: 5 hours
10. Voice call time: 5 hours
11. Charging time: 1.5-2 hours
12. Standby time: about 150hours
13. Weight of earbud: 4g
14. Weight of charging box: 81g
15. Weight of whole set: 156g
