Hayward XE Series User manual

XE Pump Series

TriStar®XE | MaxFlo®XE | Super Pump®XE

QUICK START GUIDE

This illustration is showing TriStar®XE.

Energy Efficient Programmable

Variable Pump Speed

OVERRIDE MODE

SIMPLE BUTTON PROGRAMMING

To ENTER

Press once

To EXIT

Press & Hold

HIGH

3 hours

MEDIUM

3 hours

LOW

3 hours

STOP

No time limit

Press for

NEXT SPEED Light flashes slowly

in OVERRIDE MODE

4 second hold

START

230 VAC

(Default)

Ground

Jumper in

230V position

115 VAC

Ground

Jumper in

115V position

Hazardous Voltage: Always turn off power at the circuit breaker before wiring. The pump can be wired to 230 VAC

(factory default) or 115 VAC supply. Move the jumper to the corresponding input voltage as shown.

WIRING INSTRUCTIONS

Back to Daily Schedule

Solid

For detailed information

about XE Series Pumps,

scan this QR code

QRG3200VSM REV A

Back to Daily Schedule

Solid

Choose

pump speed

INTERVAL 2 INTERVAL 3

8 hours 12 hours

Save &

Continue

Choose

pump speed

Choose

pump speed

INTERVAL 1

4 hours

PRESS TO CHOOSE SPEED

DEFAULT DAILY SCHEDULE

4 hours 8 hours 12 hours

INTERVAL 1 INTERVAL 2 INTERVAL 3

50 50 50

123 4

4 second hold 4 second hold

100% for 24 hours

4 second hold 4 second hold 4 second hold 4 second hold

80% for 4 hours / 40% for 8 hours / 0% for 12 hours

HOW TO PROGRAM THE DAILY SCHEDULE

PROGRAMMING EXAMPLES

SOLID

Daily Schedule Only

SLOW FLASHING

Override Mode Only

3 RAPID FLASHES

Confirms press and hold

successful

QUICK FLASHING

Program Mode Only

Number of flashes indicates

interval

PRESS & HOLD

Program mode /

Save & continue

SHORT PRESS

Override mode /

Choose pump speed

4 second hold

24 hour

50% Pump speed 50% Pump speed 50% Pump speed

4 hours

8 hours

12 hours

INTERVAL 1

INTERVAL 2

INTERVAL 3

4 hours

8 hours

12 hours

INTERVAL 1

INTERVAL 2

INTERVAL 3

100

To ENTER

PROGRAM MODE

STATUS LIGHT

CHOOSE PUMP SPEEDDAILY SCHEDULE

PUSH BUTTON

4 second hold

100%

80%

70%

50%

45%

40%

100

START: POWER ON

START

123

Press

two times

Press

six times

Press

seven times

Press &

Hold

Press &

Hold

Press &

Hold

Press &

Hold

50% pump speed for all 3 intervals

4 second hold

Save &

Continue

4 second hold

Save &

Continue

4 second hold

Press &

Hold

Press &

Hold

Press &

Hold

Press &

Hold

Press

one time

1 2 3 4 5 6 7

The pump will start at 100% speed for 8 minutes to prime

3x 3x 3x

3x 3x 3x 3x
