HAUSSLER Landscape light User manual
Operang instrucons
Landscape light XL
Landscape light
Original operang instrucons
Contents
1 Welcome… .........................................................................................................3
to the world of milling, kneading, baking, and pasta-making! ................................ 3
2 For your safety ..................................................................................................4
Table of symbols...................................................................................................... 4
Intended use............................................................................................................ 4
Basic rules................................................................................................................ 4
Safety informaon................................................................................................... 4
3 Product guide .....................................................................................................6
Product descripon ................................................................................................. 6
Technical data.......................................................................................................... 6
4 Scope of delivery ................................................................................................8
Seng up the device............................................................................................... 9
Assembling the device............................................................................................. 9
5 Fuel to be used .................................................................................................10
6 Filling and ring up...........................................................................................12
Filling capacity ....................................................................................................... 13
7 Cleaning ...........................................................................................................16
8 Maintenance ....................................................................................................17
9 Troubleshoong ...............................................................................................18
10 Disposal ...........................................................................................................21
11 Accessories ......................................................................................................22
12 Warranty ..........................................................................................................25
2
1 Welcome…
to the world of milling, kneading, baking, and pasta-making!
Häussler stands for doing it yourself. With our devices, you can create wonderful
delicacies with a second-to-none taste. Immerse yourself in the world of milling,
kneading, baking, barbecuing, and pasta-making.
Häussler stands for uncompromising quality – Made in Germany. Decades of
experience and thousands of devices shipped worldwide speak for themselves.
Häussler stands for customer service. Even aer you’ve made a purchase, we will not
hesitate to provide you with support. We want you to be happy with your device for
a long me, receive new helpful hints now and again, and discover fresh recipe ideas
at Häussler.
You have decided to purchase our landscape light, a re under glass for your garden.
With its contemporary look and the ame generated, the light adds an unforgeable,
appealing atmosphere to any environment.
Plenty of pleasure and always successful.
3
Welcome…
2 For your safety
Table of symbols
Symbol descripon
⚠Danger symbol
Prompt to acon
iInformaon
Bullet point
Tab. 1: Table of symbols
Intended use
The landscape light meets the prescribed, product-specic safety regulaons.
The landscape light is only intended to be used as an outdoor light. The use of any fuel
other than wood pellets is prohibited. Any other use shall be considered improper use.
Karl-Heinz Häussler GmbH shall not be liable for any damage to property or persons
resulng from improper use of the product.
The supplementary products recommended by Häussler are the only ones that may
be used.
Basic rules
Carefully read the operang instrucons before you commission the device.
Observe the safety informaon and warnings in the operang instrucons.
Only operate the device when it is in perfect condion.
Keep the operang instrucons available in the vicinity of the device.
Always include these operang instrucons when selling this device to a third party.
Conduct a visual inspecon before commissioning every me the device is used.
Safety informaon
⚠Risk of fatality from explosion
Never use easily and highly ammable liquids such as denatured alcohol, etc.
Never use an accelerant on pellets that have been red up and are warm.
4
For your safety
⚠Risk of fatality from smoke
Only use the landscape light outdoors.
⚠Risk of injury due to high weight
Transport the device with care due to its high weight.
Before picking it up, make sure that you can handle the weight.
Two people should carefully li the device.
Only set the device down on a stable surface.
⚠Risk of burns from heated components
Do not leave the device unaended during and aer operaon.
Set up the device out of the reach of children under 14 and always supervise child-
ren in the vicinity of the device. Do not leave infants, children, or animals unaen-
ded in the vicinity of the landscape light.
Let the landscape light cool down completely before touching it.
⚠Risk of burns from high ames
Do not wear loose-ng clothes.
Persons with long hair should e it back.
⚠Risk of re from high ames
Only operate the landscape light in areas without roofs.
Maintain a minimum distance of 1.5 m from ammable materials when using the
landscape light.
Risk of re from hot components
Please note that the landscape light also radiates heat
downwards. Protect the surface beneath the landscape
light by covering it with a heat-resistant plate.
5
For your safety
3 Product guide
Product descripon
You have purchased a very high-quality outdoor light: our Landscape light. This
outdoor light is simple to operate, easy-care, and requires virtually no maintenance.
With the relevant accessories, it can also be used as a barbecue.
Technical data
Name Value
Pillar diameter 323 mm
Landscape light height 940 mm
Landscape light XL height 1,212 mm
Base diameter 605 mm
Weight 29 kg
Filling capacity Max. 9 kg
Tab. 2: Technical data
6
Product guide
Firing values Value
Rated thermal input 5.2 kW/kg
Carbon content 3.49%
Exhaust mass ow rate 31.3 g/s
Dust 2.80 mg
Tab. 3: Output and emissions
7
Product guide
4 Scope of delivery
1
6
2
5
4
3
No. Designaon
1Base
2Upper secon
3Grate
4Burner cover
5Glass insert
6Glass insert XL
Tab. 4: Scope of delivery
iPlease note that the scope of delivery contains either the short glass insert or the
XL glass insert, depending on the version ordered.
8
Scope of delivery
Seng up the device
Use Table 4 “Scope of delivery” to help you check the delivery for completeness.
Two people should carefully li the device due to its high weight. Always set it down
on a stable, even work surface.
Create enough room to work on the device.
Assembling the device
Pick up the base 5 and place it on a solid, even sur-
face.
The grate 4 is already inside the base, in the burner
head.
The burner cover 3 is already on the burner head
in the base. Push the burner cover back and forth to
check whether or not it completely covers the bur-
ner.
Unpack the separately packaged upper secon 2.
iTo smoothly place the upper secon 2on the base,
5 use mul-purpose grease for high temperatures.
Use a cloth or your nger to apply a thin coat of
mul-purpose grease for high temperatures to the
notch in the frame.
Place the upper secon 2onto the base 5. Press
down onto the base unl it stops.
Unpack the separately packaged glass insert 1and
put it on the upper secon 2 . Cauon: Fragile
iYour landscape light is now set up and ready to use.
1
2
3
4
5
9
Scope of delivery
5 Fuel to be used
⚠WARNING
Risk of fatality from explosion
Darng ame
Never use easily and highly ammable liquids such as denatured alcohol,
etc.
Never use an accelerant on pellets that have been red up and are warm.
⚠CAUTION
Risk of burns from catching re
Severe burns on enre body
Do not wear loose-ng clothes.
Persons with long hair should e it back.
Use only class A1 and A2 wood pellets for private households in accordance with
European standard EN 14961-2.
What are wood pellets?
Wood pellets are standardised, cylindrical products of
compression made from dried, untreated residual wood
(sawdust, shavings, residual wood from forests) with a
diameter of approx. 6 mm. They are produced under high
pressure without the addion of any chemical binding
agents, and have a caloric value of approx. 5 kWh/kg. In
other words, the energy content of one kilogram of pellets
is approximately equal to one-half litre of heang oil.
iThe use of any other fuel is prohibited.
iThe burning of waste with this product is prohibited.
Helpful hint: Pellet class selecon
Häussler recommends that you use class A1 wood pellets,
since they have a lower ash content aer burning.
10
Fuel to be used
