Hathaway BG50360 User manual

BG50360

Ver. 07206

Please Do Not Hesitate to

Contact Our Consumer Hotline

at 800-759-0977

with Any Questions That May

Arise During Assembly or

Use of This Product!

CROSSFIRE 38-IN. FOOSBALL TABLE

WITH HANGING BASKETBALL HOOP

ASSEMBLY INSTRUCTIONS

THANK YOU!

Thank you for purchasing this product. We work around the clock and around the globe to ensure

that our products maintain the highest possible quality. However, in the rare case of issues during

assembly or use of this product, please contact our Consumer Hotline at 800-759-0977for immediate

assistance before contacting your retailer. Please read the warranty information at the back of these

assembly instructions for further details.

CARE AND USE

1. This product is intended for INDOORuse only.

2. Do NOT drag the table when moving it, as this will damage the legs.

ASSEMBLY TIPS

1. Find a clean, level surface to begin the assembly of your game table. We recommend that two adults

work together to assemble this game. You may want to carefully cut or tear the four corners of the box

so that the bottom of the box can be used as your work surface.

2. Remove all of the contents from box and verify that you have all of the parts shown on the Parts

List before you begin assembly. Note: Some parts may be pre-installed or pre-assembled.

3. Some figures or drawings may not look exactly like product.

4. When installing parts that have more than one screw orbolt, hand tighten all screws orbolts

in place before final tightening with screwdriver orwrench.

5. Electric screwdrivers may be helpful during assembly; however, please set a low torque and use

extreme caution because screws may be stripped or overtightened, resulting in damaged parts, if the

electric screwdriver’s torque is set too high.

WARNINGS!

READ AND FOLLOW ALL ASSEMBLY, OPERATION AND SAFETY INSTRUCTIONS CAREFULLY.

CHOKE HAZARD - THIS ITEM MAYCONTAIN SMALL BALLS AND PARTS

NOT SUITABLE FOR CHILDREN UNDER 3 YEARS OF AGE.

IMPORTANT! PLEASE READ THESE ASSEMBLY INSTRUCTIONS

IN ENTIRETY BEFORE ASSEMBLING YOUR PRODUCT.

CROSSFIRE 38-IN. FOOSBALL TABLE - BG50360

Parts List

Illustrations Not to Scale

7/20 3

For replacement parts please call 800-759-0977.

4,6,9,10

PARTS

12 3 4 5 6 7

SUPPORTBRACE

X4 X4

CORNER LEG

8910 11 12 13 14

X12

ROD WASHER

15 17 18 19 20

GOALIE STOPPER

X7 X7 X6 X2

ROD END CAP SLIDE SCORER

SILVER PLAYER

SIDE PANEL

END PANEL

PLAYFIELD

16B

LEG PANEL

16A

LEG LEVELER

3 HOLE ROD

X12

ROD BUMPER

ROD HANDLE

SOCCER BALL

LEG

SUPPORT BRACE

21 X18 23 X4 24 X4

25 X4 26 X10 27 X56

1/8” NUT 1/8” x1” SCREW 5/16” x 1” BOLT 5/16” WASHER 1/8” x 1-3/4” SCREW 1/8” x 1/2” SCREW

ALLEN WRENCH

1/8” x 7/8” BOLT

X14 22

HARDWARE PACK - NGP7696

15 19

16B

16A

NGP7677 NGP7678 NGP7679 NGP7680 NGP7681 NGP7682

NGP7676

GREEN PLAYER

NGP7684 NGP7685 NGP7686 NGP7687 NGP7688 NGP7689

NGP7683

NGP7691 NGP7692 NGP7693 NGP7694 NGP7695 NGP5102

NGP7690

LEG ATTACHING

PLATE LEG SUPPORT

BRACE PLATE

1/8” x 3/4” BOLT

Parts List

ASSEMBLY INSTRUCTIONS

#26

#2 #1

#26

ASSEMBLY INSTRUCTIONS (Cont.)

#27 #5

#27

ASSEMBLY INSTRUCTIONS (Cont.)

#27

#10

#6 #27

#10

#27

ASSEMBLY INSTRUCTIONS (Cont.)

#11

#11 #25 #24

#11

#26

#25 #24 #15 #16

#22

#12

#14 #13

#12

#14

#13

#29

#21

ASSEMBLY INSTRUCTIONS (Cont.)

10.

#23

#19

#17 #18

HANGING BASKETBALL HOOP - BG50360

Parts List

Illustrations Not to Scale

12/19 For replacement parts please call 800-759-0977.

PARTS

HARD

WARE PACK - NGP7704

A7 A8 A9

A1 A2 NGP7698 A3 NGP7699 A4 NGP7700 A5 NGP7701

AIR PUMP

A6 NGP7702

BASKETBALL NET HOOK

A10 NGP7703

BACKBOARD HOOK

NGP7697

X1 X1 X2 X8

X6X2 X4

BACKBOARD

BASKETBALL RIM

NET

BOLT - LONG BOLT - SHORT NUT

A6 A5

A10

ASSEMBLY INSTRUCTIONS

Step 1. Attach the 2 Backboard Hooks (A4) to

the Backboard (A1) using the Bolt - Short (A8)

and Nut (A9)

Step 2. Attach the Basketball Rim (A5) to

the Backboard (1) using the Bolt - Short (A8)

and Nut (A9)

Step 3. Attach the Basketball Net (A10) to the

Basketball Rim (A5) using the Net Hook (A6)

Step 4. The Backboard can be hooked over a

door, the back of a chair, etc. and then fixed in

place using Bolt - Long (A7) and Nut (A9)
