Harman JBL Quantum 300 User manual
300
OWNER’S MANUAL
TABLE OF CONTENTS
INTRODUCTION ........................................................................................................... 1
WHAT’S IN THE BOX..................................................................................................... 2
PRODUCT OVERVIEW ................................................................................................. 3
Controls on headset.....................................................................................................................................3
GETTING STARTED....................................................................................................... 4
Wearing your headset.................................................................................................................................4
First-time setup (for PC only)...................................................................................................................4
USING YOUR HEADSET............................................................................................... 6
With USB connection...................................................................................................................................6
With 3.5mm audio connection..............................................................................................................7
PRODUCT SPECIFICATIONS....................................................................................... 8
TROUBLESHOOTING ................................................................................................... 9
- 1 -
Introduction
Congratulations on your purchase! This manual includes information on the JBL
QUANTUM300 gaming headset. We encourage you to take a few minutes to read
this manual, which describes the product and includes step-by-step instructions to
help you to set up and get started. Read and understand all the safety instructions
before using your product.
If you have any questions about this product or its operation, please contact your
retailer or customer service, or visit us at www.JBLQuantum.com
- 2 -
What’s in the box
03
04
01 02
01 JBL QUANTUM300 headset
02 USB audio adapter
03 QSG, warranty card and safety sheet
04 Windshield foam for boom microphone
- 3 -
PRODUCT OVERVIEW
Controls on headset
04
03
01
02
01 Volume +/- dial
• Adjusts headset volume.
02 Detachable windshield foam
03 Voice focus boom microphone
• Flip up to mute, or flip down to unmute the microphone.
04 Flat-fold ear cup
- 4 -
Getting started
Wearing your headset
1. Put the side marked Lonto your left ear and the side marked Ronto your right
ear.
2. Adjust the earpads and headband for a comfortable fit.
3. Adjust the microphone as necessary.
First-time setup (for PC only)
Download from jblquantum.com/engine to gain access to
Quantum 3D audio technologies.
- 5 -
Software requirements
Platform: Windows 7 / Windows 10 (64 bit) only
500MB of free hard drive space for installation
TIP:
• QuantumSURROUND and DTS Headphone:X V2.0 available on Windows only.
Software installation required.
1. Connect the headset to your PC via USB connection (See “With USB
connection”).
2. Go to “Sound Settings” -> “Sound Control Panel”.
3. Under “Playback” highlight “JBL QUANTUM300” and select “Set Default”.
4. Under “Recording” highlight “JBL QUANTUM300” and select “Set Default”.
5. In your chat application select “JBL QUANTUM300” as the default audio device.
6. Follow the onscreen instructions to personalize your sound settings.
JBL Quantum300 JBL Quantum300
- 6 -
Using your headset
With USB connection
1. Connect the USB connector on the USB audio adapter to a USB-A port on your
PC or Mac.
2. Connect the 3.5mm connector on your headset to the USB audio adapter.
Basic operation
Controls Operation
Volume dial Adjust master volume.
- 7 -
With 3.5mm audio connection
Connect the 3.5mm connector on your headset to the 3.5mm headphone jack on
your PC, Mac, mobile or gaming console device.
Basic operation
Controls Operation
Volume dial Adjust master volume.
- 8 -
Product Specifications
• Driver size: 50 mm Dynamic drivers
• Frequency response: 20 Hz - 20 kHz
• Max input power 30 mW
• Sensitivity: 100 dB SPL @1 kHz / 1 mW
• Impedance: 32 ohm
• Microphone frequency response: 100 Hz - 10 KHz
• Microphone sensitivity: -40 dBV @1 kHz / Pa
• Microphone pickup pattern: Directional
• Microphone size: 4 mm x 1.5 mm
• Cable length: Headset (1.2 m) + USB audio adapter (1.5 m)
• Weight: 245 g
NOTE:
• Technical specifications are subject to change without prior notice.
