Hamilton Beach Eclectrics 840232100 User manual

READ BEFORE USE

LEA ANTES DE USAR

¿Preguntas?

Por favor llámenos – nuestros

amables representantes están

listos para ayudar.

MEX: 01 800 71 16 100

Le invitamos a leer cuidadosamente

este instructivo antes de usar su

aparato.

Visit www.hamiltonbeach.com.mx for

other products or to contact us.

¡Visite www.hamiltonbeach.com.mx

para ver otros productos de Hamilton

Beach o para contactarnos!

English...................... 2

Español....................13

Coffeemaker

Cafetera

840232100 ENv02.indd 1840232100 ENv02.indd 1 7/10/13 9:05 AM7/10/13 9:05 AM

IMPORTANT SAFEGUARDS

1. Read all instructions.

2. Do not touch hot surfaces. Use handles or knobs. Care must

be taken, as burns can occur from touching hot parts or from

spilled, hot liquid.

3. To protect against electric shock, do not place cord, plug, or

coffeemaker in water or other liquid.

4. Close supervision is necessary when any appliance is used by

or near children.

5. Unplug from outlet when either the coffeemaker or clock is

not in use and before cleaning. Allow to cool before putting

on or taking off parts and before cleaning the appliance.

6. Scalding may occur if the lid is lifted during the brewing cycle.

Do not open lid until coffeemaker has cooled completely.

7. Coffeemaker must be operated on a flat surface away from

the edge of counter to prevent accidental tipping.

8. Do not operate any appliance with a damaged cord or plug,

or after the appliance malfunctions or is dropped or damaged

in any manner. Call our toll-free customer service number for

information on examination, repair, or adjustment.

9. The use of accessory attachments not recommended by the

appliance manufacturer may cause injuries.

10. Do not use outdoors.

11. Do not let cord hang over edge of table or counter or touch

hot surfaces, including stove.

12. The coffee tank is designed for use with this coffeemaker. It

must never be used on a range top or in a microwave oven.

13. Do not place coffeemaker on or near a hot gas or electric

burner or in a heated oven.

14. To disconnect coffeemaker, turn controls to OFF (O) and then

remove plug from wall outlet.

15. WARNING! To reduce the risk of fire or electric shock,

do not remove the bottom cover. No user-serviceable parts

are inside. Repair should be done by authorized service

personnel only.

16. Do not use appliance for other than intended use.

When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or

injury to persons, including the following:

SAVE THESE INSTRUCTIONS!

840232100 ENv02.indd 2840232100 ENv02.indd 2 7/10/13 9:05 AM7/10/13 9:05 AM

Other Consumer Safety Information

This appliance is intended for household use only.

WARNING! Shock Hazard: This appliance has a polarized plug

(one wide blade) that reduces the risk of electric shock. The

plug fits only one way into a polarized outlet. Do not defeat the

safety purpose of the plug by modifying the plug in any way or

by using an adapter. If the plug does not fit fully into the outlet,

reverse the plug. If it still does not fit, have an electrician replace

the outlet.

The length of the cord used on this appliance was selected to

reduce the hazards of becoming tangled in or tripping over a

longer cord. If a longer cord is necessary, an approved extension

cord may be used. The electrical rating of the extension cord

must be equal to or greater than the rating of the appliance. Care

must be taken to arrange the extension cord so that it will not

drape over the countertop or tabletop where it can be pulled on

by children or accidentally tripped over.

To avoid an electrical circuit overload, do not use another high-

wattage appliance on the same circuit with your appliance.

IMPORTANT

Never use coffee tank to pour hot coffee or carry hot coffee.

Handle coffee tank when it holds only cold water or cold coffee.

Additional Information

• If overflow occurs: Let unit, coffee, and grounds cool completely before attempting any cleanup.

• Use only brand-name, high-quality filters.

• Use only 1 Tablespoon of ground coffee for each cup of water.

• Use coffeemaker cleaner to prevent hard water deposits that affect coffeemaker performance. Clean monthly.

• Read instructions before using.

840232100 ENv02.indd 3840232100 ENv02.indd 3 7/10/13 9:05 AM7/10/13 9:05 AM

Parts and Features

Filter

Basket*

Coffee Tank*

Coffee Dispenser

Bar

Water Level Guide

Drip Tray*

Coffee

Level

Guide

Water Filter

Pod*

Lid

Water

Reservoir

Keep-Warm

Plate

Control Panel/

Display

*To order parts:

Mexico:

01 800 71 16 100

Optional Accessories

Coffee Scoop*

Gold-Tone

Permanent

Coffee Filter*

Water Filter*

(handle assembly

with pod)

840232100 ENv02.indd 4840232100 ENv02.indd 4 7/10/13 9:05 AM7/10/13 9:05 AM

How to Make Coffee

1 2

4 5

Place paper filter in brew basket;

add coffee. Put grounds in the

filter with the filter basket out of

the brew tank.

BEFORE FIRST USE: Wash coffee

tank, filter basket, and drip tray in

hot, soapy water. NEVER put the

coffee tank in dishwasher.

Coffeemaker can be programmed

to automatically shut off in 0 (for

Iced Coffee), 1, 2, 3, or 4 hours

as desired. Default is 4 hours for

automatic shutoff.

Maximum Amount of Automatic

Drip Coffee to Use in Coffeemaker

Coffee Scoops Tablespoons

Regular 12 12

Decaf 12 12

Normal Amount of Coffee Per Cup

1 scoop* or 1 level tablespoon per cup

Burn Hazard.

•

Never use coffee tank to pour or carry hot coffee.

• Handle coffee tank only when holding cold water for filling water

reservoir and to clean tank after coffeemaker has been shut off and

the coffee is cool.

• If coffeemaker overflows, unplug unit. Allow unit, coffee, and

grounds to cool before cleaning unit, coffee, or grounds.

wWARNING

*Coffee scoop is optional feature on select models.

840232100 ENv02.indd 5840232100 ENv02.indd 5 7/10/13 9:05 AM7/10/13 9:05 AM

If a Brew Strength is not selected,

the coffeemaker will automatically

brew on the regular/default setting.

How to Make Coffee (cont.)

Brew Options

NOTE: BOLD and 1–4 CUPS modes will require additional time to

complete a brewing cycle. A Brew Strength must be selected prior

to pressing the ON/OFF ( ) button. The setting cannot be changed

during/in brew mode.

TO REHEAT COFFEE: Make sure unit is turned off. Press and hold

ON/OFF ( ) button for 3 seconds. This will reset the timer and keep

coffee warm up to 2 hours.

BOLD

Enhanced full/strong-flavored coffee:

Press BREW STRENGTH button until

BOLD is displayed.

1–4 CUPS

When brewing 1–4 cups of coffee:

Press BREW STRENGTH button until

1–4 CUPS is displayed.

840232100 ENv02.indd 6840232100 ENv02.indd 6 7/10/13 9:08 AM7/10/13 9:08 AM

1 2

6 7

Fill coffee tank with water. Do not

fill beyond the 6-cup line when

making iced coffee.

Fill coffee tank with ice to the

10 CUP marking line.

Press the KEEP WARM HRS button and set hours to 0. Press ON/OFF

( ) button to brew. Unit will automatically shut off when iced coffee

is ready. NOTE: Keep Warm setting is not available with the Iced

Coffee function.

To Make Iced Coffee

Brew double-strength coffee for

iced coffee. Add 2 scoops* or

2 level tablespoons of ground

coffee per cup (up to 12 scoops).

Burn Hazard.

If coffeemaker overflows, unplug unit. Allow unit, coffee, and grounds

to cool before cleaning unit, coffee, or grounds.

wWARNING

*Coffee scoop is optional feature on select models.

840232100 ENv02.indd 7840232100 ENv02.indd 7 7/10/13 9:05 AM7/10/13 9:05 AM

Programming

1234

Press Hand then M.

NOTE: Clock time must be set for

programming function to work.

To program auto brew: Press and

hold START TIME until clock flashes.

START TIME will appear in display.

Continue holding

START TIME;

then press

and

until the

desired brewing start time is

reached.

Press and release

START TIME

activate automatic brewing. A

green light will signal that the unit

is in program mode.

Water Filter (optional accessory)

Water Filter (Optional Accessory)

If using a water filter, it should be

replaced every 60 cycles for best-

tasting coffee.

840232100 ENv02.indd 8840232100 ENv02.indd 8 7/10/13 9:05 AM7/10/13 9:05 AM

Cleaning With Vinegar

1 2 3

Remove optional water filter. Pour 1 pint (2 cups/473 ml) vinegar into

water reservoir. Press ON ( ) button. Press OFF ( ) button again after 30 seconds

and wait 30 minutes. Press ON ( ) button. Press OFF ( ) button

again when finished. When cool, dispense several cups before

emptying and rinsing reservoir.

NOTE: Coffeemaker will remind you it is time for cleaning:

• Built-in residue sensor—CLEAN will appear in display when unit

senses residue buildup and remain illuminated until the end of the

cycle.

All coffeemakers should be cleaned at least once a month (once a

week for areas with hard water).

Run 2–3 more brew cycles with

CLEAN WATER only. Allow to

cool between cycles.

DISHWASHER-SAFE

DO NOT use the “SANI” setting

when washing in the dishwasher.

“SANI” cycle temperatures could

damage your product.

840232100 ENv02.indd 9840232100 ENv02.indd 9 7/10/13 9:06 AM7/10/13 9:06 AM

INSIDE OF COFFEEMAKER:

Follow steps 1–5 in “Cleaning With Vinegar.”

FILTER BASKET:

Remove the filter basket and wash by hand with warm, soapy water. Clean filter basket often.

COFFEE TANK:

To clean using denture-cleaning tablets: Fill water tank to max line. Add 3 denture-cleaning tablets to the water and allow the mixture to sit

overnight. In the morning, empty the mixture and clean the tank well, using a sponge and warm, soapy water.

OUTSIDE OF COFFEEMAKER:

Wipe outside with a soft cloth and warm, soapy water. Do not use abrasive cleaners, since they will scratch the finish of the product.

wWARNING

General Cleaning Instructions Shock Hazard.

Do not immerse cord, plug, or coffeemaker

in any liquid.

Troubleshooting

PROBLEM

CLEAN appears in display.

Coffee tastes bad.

PROBABLE CAUSE/SOLUTION

• This is a reminder to clean coffeemaker. See “Cleaning With Vinegar.”

•Coffeemaker needs cleaning.

• Coffee ground too coarsely or too finely. Set coffee grinder to automatic drip grind.

• Coffee-to-water ratio unbalanced. Adjust for personal preference.

• Poor water quality. Use water filter or bottled water to make coffee.

840232100 ENv02.indd 10840232100 ENv02.indd 10 7/10/13 9:06 AM7/10/13 9:06 AM

Table of contents

Languages:

Other Hamilton Beach Coffee Maker manuals

Hamilton Beach

Hamilton Beach 49970 User manual

Hamilton Beach

Hamilton Beach 49611 User manual

Hamilton Beach

Hamilton Beach HDC1200 User manual

Hamilton Beach

Hamilton Beach 46201 User manual

Hamilton Beach

Hamilton Beach ella HBC9453MB User manual

Hamilton Beach

Hamilton Beach 49962 User manual

Hamilton Beach

Hamilton Beach BrewStation User manual

Hamilton Beach

Hamilton Beach Percolator User manual

Hamilton Beach

Hamilton Beach 43253R User manual

Hamilton Beach

Hamilton Beach 46000 Owner's manual

Hamilton Beach

Hamilton Beach BrewStation User manual

Hamilton Beach

Hamilton Beach 40714 User manual

Hamilton Beach

Hamilton Beach Stay or Go User manual

Hamilton Beach

Hamilton Beach FlexBrew User manual

Hamilton Beach

Hamilton Beach BrewStation 47535C User manual

Hamilton Beach

Hamilton Beach 49983 User manual

Hamilton Beach

Hamilton Beach 43224C User manual

Hamilton Beach

Hamilton Beach 49992 Owner's manual

Hamilton Beach

Hamilton Beach BrewStation 6-Cup BrewStation User manual

Hamilton Beach

Hamilton Beach D45020W User manual

Hamilton Beach

Hamilton Beach 42500 User manual

Hamilton Beach

Hamilton Beach Coffee brewer User manual

Hamilton Beach

Hamilton Beach 49316 User manual

Hamilton Beach

Hamilton Beach 40405 User manual

Popular Coffee Maker manuals by other brands

Taurus

Taurus Livorno 6 manual

Delta-q

Delta-q QUICK instruction manual

Bunn

Bunn LCA-1 Installation & operating guide

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Use and care book

Saeco

Saeco Vienna Plus Sup 018M operating instructions

DeLonghi

DeLonghi DC300 Owner's instructions

INCAPTO

INCAPTO BXCO1470E Instructions for use

Bosch

Bosch TASSIMO finesse TAS16B Series user manual

Exido

Exido 245-072 Specifications

Animo

Animo OptiVend Choco user manual

Siemens

Siemens TQ505DF Series user manual

DeLonghi

DeLonghi ECI341 Instructions for use

Krups

Krups KT406511 manual

Cimbali

Cimbali M32 Classic manual

Philips

Philips HL3844N Service manual

Bosch

Bosch TES 515 SERIES instruction manual

Tekmatix

Tekmatix TMFM - 65 Operation manual

Scarlett

Scarlett SC-CM33005 instruction manual

Hamilton Beach eclectrics 840232100 User manual

Popular Coffee Maker manuals by other brands
