HAKO Scrubmaster B25 User manual

Hako Scrubmaster B25

1. Disconnect mains plug of the charger from outlet and fasten to holder 1.

2. Pull the filling opening cap 2towards you and remove it and fill the clear

water tank 3. Control the filling level by the filling level indicator 4.

3. Turn the machine on by keeping button 5pressed approx. 3 sec.

4. Adjust the height of the operating bar with the locking lever 6.

5. Switch suction turbine on with button 8 (corresponding symbol 9in the

display) and water with button 10 (corresponding symbol 11 in the display).

6. Use the starting handle 12 to switch on the cleaning functions.

7. Push the machine forwards. Use button 10 to adjust the water (if

necesssary). NOTE! Make sure that pad/brush is installed!!!

OPERATION:

Quolified persons only are authorised to operate the machine!

The machine is not designed for coarse material! Floor area sweeping before!

Use only cleaning agents suitable for authomatic machines (low-foaming)!

Please pay attention to the informations in the instruction manual!

1

3

2

5

4

6

8

12

911

10

12

Daily maintenance:

➢Empty clear water tank via the draining

opening 1.

➢Empty soiled water tank 2from hose3

and clean soiled water tank. Check and

clean tank lid and lid sealing 4.

➢Check suction filter 5in the soiled

water tank, clean if required.

➢Park the machine in the park position 6

over the floor drain and rinse suction

hose/ suction pipe 7from pipe 8.

➢Clean the squeegee 9.

➢Keep the machine in the park position

and remove brush/pad holder by keeping

button 10 pressed until brush/pad holder

has been decoupled. Check brush/pad for

wearing and clean it.

➢Park the machine in the park position 6.

Charge battery (take plug from holder and

connect with outlet).

Turn off the machine before maintenance!

Please pay attention to the informations in the instruction manual,

you can find manual by reading QR-code.

MAINTENANCE AND CARE:

Weekly maintenance:

➢Check and clean brush head /

sealing strip 12.

➢Check and clean clear water filter 13.

➢Clean the machine from outside.

➢Check squeegee 9sealing strips and

turn or replace them if necessary.

Suction result is bad:

oSuction hose7or squeegee 9is

blocked.

oLocking cap of the soiled water drain

hose 3is open.

oTank lid sealing 4of the soiled water

tank is defect or tank lid is open.

Hako Scrubmaster B25

1

3

2

5

4

6

9

13

10

811

1

2

7
