Haier HXC-936 User manual
HXC-936/576
Operation Manual
Read the Operation Manual carefully before using your appliance
.
Keep the Operation Manual in a safe place.
Appearance, color and la
y
out of the door ma
y
var
y
.
Product
Model
Volume
External panel
Internal panel
Blood bank refrigerator
HXC-936
936L
Sprayed steel sheet
Stainless steel sheet
HXC-576
576L
Insulation
Rack
Cooling
Compressor
Condenser
Evaporator
Rrfrigerant
Defrosting
Thermostat
Over-temp warning
Low-temp warning
Door warning
Spare storage parts
Lamp
Temp recorder
Accessories
Net weight
Rechargeable battery
Styrene polyurethane foam (Freon-free)
42
Air circulation
Sealed
Finned pipes
Finned pipes
R134a
Automatic
Electronic control system
Indicator blinks for buzzer and remote warning
Indicator blinks, without deferred buzzer alarm
Door warning indicator on, and buzzer signal 10 minutes later
Permanent static storage
Lamp, 35Wx2
For7days
254kg
UN7.0-8(8V7.0AH)
Key: 1 set; Recording paper: 1 box;
Operation manual: 1; Plastic bag: 1; 9V Battery: 4
LYGX (Z) No.: 2580088
YZB/LU 0028-2004
24
35Wx1
180kg
HXC-936 Diagram
Inner light
Glass door
Rack
Casters
Auto temperature
chart recorder
Light
switch
Control
pannel
Door lock
3
4
5.Rack
The racks can be loaded with 320 blood bags of 200ml.
6.Inner light
10 min later 10 min
Temperature adjusting:
Press and hold both SENSOR SELECT button and CALIB CANCEL button for more than 3s until
original setting starts flashing to indicate that it enters temperature setting mode. With each press
of CALIB CANCEL button, temperature setting increases 0.1 until reaching upper limit, which
is defaulted as 8 . If press again, it returns to lower limit, which is defaulted as 2 . It repeats the
above cycle. When it reaches your desired temperature, if you don't press the button within 5s,
the temperature setting will be saved and it automatically quits the temperature setting mode (the
temperature setting range programmed at factory is 2 - 8 ). The display returns to display inside
sensor temperature or average temperature before setting is made (not flashing).
This manual suits for next models
