Haier P32R1 User manual
MODEL: P32R1
PLASMA TELEVISION
OWNER`S MANUAL
Please READ thismanual carefully before
operating your TV, and retain it for future
reference.
Congratulations on yourpurchase, and welcome to the family !
Dear Haier product owner:
Thank you for your confidence in Haier. You`veselected one of the
best-built, best-backed products available today. We`ll do everything
in our powerto keep you happy with yourpurchase for many years to
come.
As a member of the Haier family, you`re entitled to protection by
one of themost comprehensive warranties and outstanding service
networks in theindustry.
thanks for investingin a Haier product.
""
""
CONTENTCONTENT
BEFORE OPERATING
Warning..............................................................................................................1
Important Safety Instructions..............................................................................2
Buttons and interface location........................................................................... 4
Remote controller...............................................................................................6
Remote controller key function...........................................................................7
External equipment connections........................................................................8
BASIC OPERATING
Switching on/off the TV set................................................................................13
Choose the Menu language............................................................................. 13
Choose the Input Source ................................................................................. 13
Searching Channel............................................................................................14
Watching TV Program........................................................................................17
Picture Control Functions................................................................................. .18
Sound Control Functions....................................................................................20
Timer Functions..................................................................................................22
Function Menu...................................................................................................23
Adjust Menu.......................................................................................................26
Lock Setup ........................................................................................................27
OTHERS
Others functions................................................................................................29
Stream media broadcast system.......................................................................30
Maintenance......................................................................................................43
Troubleshooting.................................................................................................44
Specifications ...................................................................................................45
Format..............................................................................................................46
Accessories
Remote controller User's manual Alkaline battery
(AAA) 2 Power cable
WARNING
*To avoid electric hazards, it is strongly suggested that the back cover not be opened, as
there is no any accessory inside the casing.
*If necessary, please contact authorized after-sales services.
*A lighting flash mark in a triangle: Apotentially hazardous situation, which, if not avoided,
could result in serious injury by high voltage.
*An exclamation mark in a triangle: Major part or accessory of which technical specifications
must be followed if it is to be replaced.
Warning:
To avoid fire or electric hazards, never place your television receiver in an area
with heavy moisture. Attention should be paid to avoid accidental scratches or
impacts onto the screen.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Caution:
Please read this manual carefully before using your television and keep this
manual in a good place for future reference.
To achieve the best performance of your television, read this User's Manual
carefully and properly store it for future reference.
Information of screen displays and figures in the User's Manual may vary due
to technical innovations.
Caution:
Unauthorized disassembly of this product is prohibited.
Warning
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL.
1
Important Safety Instructions
The product should be tightly fixed to avoid
drop damages and even fire.
To avoid fire hazards, do not use this
product under direct sunlight or closely
to heat sources.
Do not locate the product close to water
or oil, which may cause fire hazards.
Unplug the power supply and antenna of
the product when there is a rainstorm,
especially
Thunderstorm.
Do not use damaged or worn electric plugs
and keep electric cord away from heat sources
to avoid electric shocks or fire hazards.
Do not connect excessive sockets in parallel
or share the same socket by multiple plugs
to avoid fire hazards.
The product must be placed on a solid and
stable surface to avoid collapse.
Unauthorized disassembly of the television
is prohibited to avoid electric shocks or fire
hazards. Contact
authorized after-sales
service if technical
service is needed.
Keep the product away from a transformer
or heat source to avoid fire hazards.
Disconnect the product from power supply
and contact authorized after-sales service
if abnormal sound is heard in the product.
2
Important Safety Instructions
Don't use or store inflammable materials
near the product to avoid explosion or fire
hazards.
Don't place the product in a humid area to
avoid fire hazards.
The antenna of the product should be away
from electric cable to avoid
electric shocks.
Never touch the plug when your hand is wet
as this might cause electric shocks.
Always make sure that the televisionis well
plugged as poor electric
connection might cause fire.
When antenna is used, measures should be
taken to prevent water
from flowing down
along the cable into
the television.
Unplug the television, use soft fabric, never
chemicals, if you are going to make
cleaning of the product.
Make sure that no
water drops in the
product.
The plug and electric cable must be kept
clean to avoid electric
shocks or fire
hazards.
Disconnect the television from power supply
and antenna when there is a
rainstorm or thunderstorm
to avoid electric shocks
or fire hazards.
Disconnect the television from power supply
to avoid electric shocks or fire
hazards in a long
vocation.
3
Front panel Control Buttons and functions
- This is a simplified representation of front panel.
- Here shownmay be somewhat different from your TV.
Buttons and interface location
1. P-/+ :
2. V-/+ :
3.
4.
5. Remote Sensor
6.
Channel number decrease/increase
Volume decrease/increase,adjustingthe menu
TV/AV button
MENU button
Power and Indicator
4
TV/AV
MENU
VOL+
VOL-
CH+
CH-
POWER
1
2
3
4
5
6
7
Buttons and interface location
Rear panel Control
5
HDMI
PC IN
PC
AUDIO IN
YPb/Cb Pr/Cr AUDIO
L R
COMPONENT IN
AV OUT
AV IN
VIDEO L R
S-VIDEO
ANT.
Power cable jack
12346
78
5
HDMI Input Connnect a signalto HDMI/DVI
PC Input
AV
Connect the monitoroutput connector froma PC tothe jack
Input Connect a componentvideo/audiodevice to thesejacks.
Input Connect audio/video outfrom an audio/video device to thesejacks.
S-Video Input Connect S-Video out from aS-Video device to these jacks.
Video/Audio output terminal
Connect ordinary video/audioor other applianceaudio input terminals.
Component
Earphone jack Earphone Audio output terminal
Antenna Input Connect cable orantenna signals tothe TV, either directlyor
through your cablebox.
Remote controller
Precautions
Battery loading
1.Slide open the cover of the battery compartment on the back of the remote controller.
2.Load two 7# (AAA)alkaline batteries in the compartment. (plus and minus poles to
respective mark)
3.Replace the cover of the battery compartment.
Make sure that there is no obstacle
between the remote controller and
television set.
As strong light may interfere the
signals, change your position to
operate the remote controller if
the television cannot be turned
on or off as you expect.
Keep the remote controller away from
heat source or humid area to ensure
effective performance of the remote
controller.
Make sure that two AAA alkaline
batteries are loaded. The batteries must
be of the same type. The batteries must
be located properly. The batteries are not
rechargeable.
6
3
12
SELECT
HDMI
ENTER
ZOOM
HELP
PIP
SWAP
PIC.SIZE
DISPLAY
I/II
SCAN
OK
SHUTTLE
H.LOCK
SLEEP
~
MENU
DVD
TV/AV
RETURN
USB
ZOOM/MOVE
TIME.SKIP
PSM
SM
Q.VIEW
STILL
-/--
CH-
CH+
VO
L
-
VOL+
S
CH.EDIT
Keys of remote control
STILL Picture static
I/II (NICAM)(No available)
MUTE
Switches the soundon or off
Power Off/Standby
any other programmed
equipment off.
SCAN
Program scan button
DISPLAY
Display ON/OFF
SLEEP
Displaying sleep time,adjustable
PIP(No available)
Digits
Program direct option(whenedit
program, every presscan set
different sign by turns amongthe
digits and signon top ofthem)
TV/AV
Input source display
Sound UP/DOWN
Lock button
(enter the LockSet menu)
Channel list button
are not available
CHANNEL select
are not available
Note:
This User's Manualcovers the functionsof the remotecontroller, includingCH+/-,
VOL-/+, MENU, TV/AV and POWER keysfor control ofprogram up, programdown,
volume decrease, volumeincrease, menu, TV/AV and power ON/OFF.
MENU
main menu entry, menu exitor
return to nexthigher level menu.
- The remote controller cannotbe operated unlessthe batteries areproperly loaded.
Function introduction
- When usingthe remote control,aim it atthe remote control sensor on the TV.
SWAP
(No available)
USB
USB system ON/OFF.
(No available)
ZOOM/MOVE (No available)
HDMI
HDMI mode select
USB system buttons (No available)
CHANNEL UP/DOWN
Selects available channels
found with auto program.
OK button
PSM
Selects the pictureappropriate
for the program'scharacter.
SSM
Selects the soundappropriate
for the program'scharacter.
TV DVD SETBOX
Press the SELECT button repeatedly to
select one ofthe system modes in which
the remote controlcan be used.
LIGHT
Press the lightbutton, white LED will
be ON, releasethis key,white LED will
be OFF.
Q.VIEW
Switch the currentchannel to the last
channel you haveviewed, or switch
the other sourceto TV.
PICTURE SIZE
Changes the aspectratio
TIME.SKIP button
SHUTTLE button
